STM8-SK/RAIS STM8-D/RAIS
ST7-SK/RAIS ST7-D/RAIS
Raisonance’s complete, low-cost starter kits for STM8 and ST7
Data brief
Features
•
Embedded RLink
– USB interface to host PC
– In-circuit debugging and programming
– Application board connection via ST SWIM,
ICC or JTAG
•
REva motherboard
– 1 standard SO-DIMM connector to plug in
daughterboards
– Digital and analog I/O evaluation features,
including on-board LEDs, buttons,
switches, external analog connector,
temperature sensor and potentiometer
– I²C EEPROM and bus
– RS-232 driver and 2 DB9 connectors
– Prototype area
– VDD settings for 1.8 V, 3.3 V and 5 V
microcontrollers
– USB powered, no external power required
•
Interchangeable REva daughterboard
– Features different STM8 and ST7 MCUs to
permit application development for a wide
range of devices and may include
additional device specific features
•
Raisonance software
– Ride7: Editor, SIMICE simulator, Rbuilder,
C compiler, debugger, Project manager,
and CodeCompressor
– RFlasher7 device programming interface
Description
The REva starter kits are Raisonance’s complete,
cost-effective solutions for starting application
development and evaluating STM8x, ST7LITEx,
ST7Fox, ST7232x, ST7234x and ST7236x
microcontrollers.
Kits contain all the hardware and software
required to develop applications for
microcontrollers, including the REva evaluation
board, target STM8 and ST7 microcontrollers,
embedded RLink for in-circuit debugging and in-
circuit programming and the raisonance
integrated development environment (Ride7) with
application builder.
July 2014
DocID11271 Rev 7
1/8
www.st.com
For further information contact your local STMicroelectronics sales office.
Contents
STM8-SK/RAIS STM8-D/RAIS ST7-SK/RAIS ST7-D/RAIS
Contents
1
2
3
4
Architecture . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
REva starter kits . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Ordering information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Revision history . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
2/8
DocID11271 Rev 7
STM8-SK/RAIS STM8-D/RAIS ST7-SK/RAIS ST7-D/RAIS
Architecture
1
Architecture
Embedded RLink:
In-circuit debugging and programming tool that uses SWIM for the
STM8, in-circuit communication (ICC) for the ST7 and supports the JTAG protocol. It
interfaces with the host PC via a USB connection.
REva mother board:
Universal evaluation board designed for quick and easy evaluation of
a complete range of features (I/Os, ADC, SPI, CAN, I2C...) for a variety of STM8 and ST7s.
It is powered from the RLink’s USB connection to the host PC.
REva daughterboards:
Interchangeable boards featuring different STM8 and ST7
microcontrollers, make it easy to evaluate and develop applications for a complete range of
MCUs from a single evaluation platform. All boards have a clock source selection jumper,
and an oscillator footprint. See
Table 1
and
Table 2
for details.
Raisonance’s software:
RLink can be driven by Raisonance’s Ride7 or RFlasher7.
•
Ride7:
Drives the RLink and offers seamless control of software development tools
(project manager, editor, compiler, assembler, linker, debugger, etc.) from an intuitive
graphical interface. It offers full integration of the relevant C/C++ toolsets, project
management, code editor and SIMICE instruction set simulator. Ride7 includes:
–
RBuilder
allows users to rapidly configure device peripherals in a GUI and
generate the C source code for peripherals at the click of a button without writing a
single line of code
SIMICE
simulator
Raisonance STM8 and ST7 C compiler, free download version allows compiling
up to 2 Kbytes code (Effective Date: April 1st, 2013).
High-level language debugging
Project manager
Color syntax highlighting editor
Free downloads of evaluation versions with unlimited debugging from
www.raisonance.com
The optional CodeCompressor allows post-link optimization of the entire
applications code using optimizations like in-lining, factorizing and peepholing,
which can reduce application code by 5 to 15%.
–
–
–
–
–
–
–
•
RFlasher7:
Raisonance’s easy-to-use device programming interface drives RLink and
allows users to erase, program, view and verify microcontroller memory. RFlasher7
also includes automated mode for automatic execution of programming sequences for
mass programming and project mode that allows users to save their programming
configurations. In this operating mode, tasks become intuitive and can be achieved with
only a few clicks such as:
–
–
–
–
Flash memory erasing and programming,
Flash or RAM memory dumping,
blank check, programming verifications,
mass programming process.
DocID11271 Rev 7
3/8
8
REva starter kits
STM8-SK/RAIS STM8-D/RAIS ST7-SK/RAIS ST7-D/RAIS
2
REva starter kits
REva boards can be purchased in the starter kit format, as shown in
Table 1.
REva standalone daughterboards are also available independently from
STMicroelectronics, as shown in
Table 2.
Table 1. Raisonance starter kits for the STM8 and ST7
Starter kit
(order code)
Daughterboard
ID marking
STM8S105
STM8/128-SK/RAIS
STM8S208RB
STM8S903
ST7LITEU0
ST7LITE0
ST7FLITE-SK/RAIS
ST7LITE1B
ST7LITE3
ST72321B
ST7232X-SK/RAIS
ST72325
ST72345
ST72F34X-SK/RAIS
ST72264
ST2F36X-SK/RAIS
ST72361
-
-
ST7226x
ST72361
ST7256X
ST72F264G2
ST72F361AR9
S028
LQFP64
-
-
ST72324/5
ST7234x
ST72F325AR9
ST72F345C4
LQFP64
LQFP48
-
-
-
ST7FLIT1xB
ST7FLITE3
ST72321
ST7FLIT19BF1
ST7FLITE39F2
SO20
SO20
Additional
features
(1)
-
-
-
-
-
MCU family
supported
STM8S103/5
STM8S207/8
STM8S903
ST7Ultralite0
ST7FLITE0
MCU device
STM8S105C6
STM8S208RB
STM8S903K3
ST7FLITEU0
ST7FLITE09Y0
MCU
package
LQFP48
LQFP64
LQFP32
DIP16
SO16
ST72F321BAR9 LQFP64
1. All kits have a clock source selection jumper, and an oscillator footprint unless stated otherwise.
4/8
DocID11271 Rev 7
STM8-SK/RAIS STM8-D/RAIS ST7-SK/RAIS ST7-D/RAIS
REva starter kits
Table 2. Raisonance standalone daughterboards for the STM8 and ST7
Standalone
daughterboard
(order code)
STM8S/32-D/RAIS
STM8/128-D/RAIS
STM8S/8-D/RAIS
ST7FLIT1B-D/RAIS
ST7FLITU0-D/RAIS
ST7FLI49-D/RAIS
ST7FLI49M-D/RAIS
ST72321B-D/RAIS
ST72325-D/RAIS
ST72345-D/RAIS
ST7FOXA0-D/RAIS
ST7FOXK2-D/RAIS
Daughterboard
ID marking
STM8S105
STM8S208RB
STM8S903
ST7LITE1B
ST7LITEU0
ST7FLI49
ST7LITE4M
ST72321B
ST72325
ST72345
ST7FOXA0
ST7FOXK2
Additional
features
(1)
-
-
-
-
-
-
-
-
-
-
-
-
MCU family
supported
STM8S103/5
STM8S207/8
STM8S903
ST7FLIT1xB
ST7Ultralite0
ST7FLITE4
ST7FLITE4M
ST72321
ST72324/25
ST7234x
ST7FOXA0
ST7FOXK2
MCU device
STM8S105C6
STM8S208RB
STM8S903K3
ST7FLIT19BF1
ST7FLITEU0
ST7FLITE49K2
ST7FLI49MK1
MCU
package
LQFP48
LQFP64
LQFP32
SO20
DIP16
LQFP32
LQFP32
ST72F321BAR9 LQFP64
ST72F325AR9
ST72F345C4
ST7FOXA0
ST7FOXK2
LQFP64
LQFP48
DIP16
LQFP32
1. All kits have a clock source selection jumper, and an oscillator footprint unless stated otherwise.
DocID11271 Rev 7
5/8
8
