FACTSHEET F-201
FTR–115–52–G–D
FTR–120–02–S–S
FTR–130–02–S–D
Surface
SMT
Mount
(1,27
mm
) .050" HEADER
Mates with:
RSM, SMS, SLM
Single and
double row
FTR
SERIES
SPECIFICATIONS
Materials:
Insulator Material:
Black Liquid Crystal
Polymer or Nylon 4/6
Terminal Material:
Phosphor Bronze
Current Rating:
1A
Operating Temp Range:
-65°C to +105°C with Tin;
-65°C to +125°C with Gold
Plating:
Au or Sn over
50µ" (1,27µm) Ni
OPTIONS
(2,54mm) .100"
–P OPTION
Important Note:
Style -02
with -S plating should not be
mated with SLM
Surface
Mount
Micro pitch
(1,27mm) .050"
Available with optional
pick-and-place pad
A
VI
NG
SO
L
UT
Note:
Some sizes, styles and
options are non-standard,
non-returnable.
ST
S
IONS
Processing:
Max Processing Temp:
230°C for 60 seconds
SMT Lead Coplanarity:
(0,10mm) .004" max (02-20)
(0,15mm) .006" max (21-40)
Suggested Paste
Thickness:
For most applications add
(0,05mm) .002" to max SMT
lead coplanarity
Suggested PCB Layouts:
Your specific layout may vary
(2,54)
.100
-A=
(1,27 -0,00 )
+0,08
.050 -.000
+.003
DIA (2)
FTR
1
NO. PINS
PER ROW
LEAD
STYLE
PLATING
OPTION
ROW
OPTION
02 thru 40
(1,27) .050 X
No. of Positions
(10,16)
.400
X
01
(5,08)
.200
(2,48)(5,03)
.098 .198
Specify
LEAD
STYLE
from
chart
=10
µ
" (0,25
µ
m) Gold
post Gold flash tail
=30
µ
" (0,76
µ
m) Gold
post 150
µ
" (3,81
µ
m)
Tin tail
–G
–S
–S
= Single
Row
CO
OPTION
–“XXX”
= Polarized
–D
= Double
Row
–A
= Alignment Pin
(5 positions
minimum
–D only)
(Metal or plastic
at Samtec
discretion)
40
(1,27)
.050
(1,27)
.050
=150
µ
" (3,81
µ
m) Tin
LEAD
STYLE
–01
–02
–03
–51
–52
–53
–54
–55
–56
–57
–T
(1,27)
.050 TYP
02
80
–LC
= Locking Clip
(6 positions min.
–D only)
(1,02)
.040
(1,09)
.043 DIA
–P OPTION
(9,53) (9,91)
.375 X .390
(4,98) (7,52)
.196 .296
(1,27)
.050
B
(5,84) .230
(2,54) .100
(3,18) .125
(4,83) .190
(5,21) .205
(7,24) .285
(8,51) .335
(9,91) .390
(10,29) .405
(10,92) .430
(1,27)
.050
(0,46)
.018
SQ
(1,40)
.055
(8,28)
.326
(0,71)
.028
-LC=
(1,19) .047
DIA (2)
(2,54)
.100
–P
= Plastic Pick
& Place Pad
(–D= 5 positions
minimum)
(–S= 9 positions
minimum)
01
79
–A OPTION
(5,59)
.220
(0,46)
.018
SQ
(1,27)
.050
–P OPTION
B
(1,27)
.050
(1,27)
.050
–TR
= Tape & Reel
(Required for 5
and 6 positions)
B
(0,51)
.020
(3,05)
.120
(2,54)
.100
(0,46)
.018
SQ
(0,74)
.029
–S OPTION
–D OPTION
–LC OPTION
