INTERCONNECTS
SERIES 860 & 861 • 1mm GRID HEADERS AND SOCKETS •
SINGLE ROW STRIPS
•
Series 860 headers and Series 861 sockets are single
(Number of Pins
X 1mm) + .0256
row, 1mm pitch interconnects rated at 2 amps
•
Series 860 headers have .015” diameter solder tails
.087
.0435
1mm
and .011” diameter pluggable pins (MM #3039)
See page 208 for details
tails (MM #0439). See page 156 for details
in 2-50 position strips
(TYP)
•
Series 861 sockets have .014” diameter solder
•
Both 860 headers and 861 sockets are available
.087
.011 DIA.
.075
•
The header and socket provide a mated height of
.196” for board stacking applications
.098 (.265)
•
Insulators are high temperature thermoplastic,
.015 DIA.
suitable for most soldering processes, and feature
stando s to promote solder ow
.092
ORDERING INFORMATION
1mm
Series 860...002
Single Row 1mm Header
860 10 0_ _ 10 002000
02-50
FIG. 1
(Number of Pins
X 1mm) + .0256
FIG. 1
Specify number of pins
.0435
1mm
.087
(TYP)
2011/65/EU
RoHS - 2
XX=Plating Code
See Below
10
10
µ”
Au
For
Electrical, Mechanical
& Enviromental Data,
See page 264
.008-.013
.087
SPECIFY PLATING CODE XX=
Pin Plating
.055
.075
.098
.190
Series 861...002
Single Row 1mm Socket
861 13 0_ _ 10 002000
02-50
.014 DIA.
FIG. 2
1mm
Specify number of pins
FIG. 2
2011/65/EU
RoHS - 2
XX=Plating Code
See Below
13
10
µ”
Au
30
µ”
Au
For
Electrical, Mechanical
& Enviromental Data,
See page 264
SPECIFY PLATING CODE XX=
Sleeve (Pin)
Contact (Clip)
Mill-Max Mfg. Corp. • 190 Pine Hollow Road, P.O. Box 300, Oyster Bay, NY 11771 • 516-922-6000 • Fax: 516-922-9253 • www.mill-max.com
PAGE 33 | INTERCONNECTS
