TECHNICAL DATA SHEET
ADAPTOR
SMA JACK – DIN 41626 PLUG
32K145-S00L5
All dimensions are in mm; tolerances according to ISO 2768 m-H
Interface
According to
SMA side:
DIN 41626 side:
IEC 60169-15; EN 122110; MIL-STD-348
DIN 41626/2, BS 9525 F0011
Documents
N/A
Material and plating
Connector parts
Center contact
Outer contact SMA side
Outer contact DIN 41626 side
Dielectric
Clip
Material
CuBe
CuBe or equiv.
Brass
PTFE
CuBe
Plating
AuroDur®, gold plated
AuroDur®, gold plated
AuroDur®, gold plated
Nickel, 2.5-5 µm
RF_35/12.04/3.0
Rosenberger Hochfrequenztechnik GmbH & Co. KG
P.O.Box 1260
D-84526 Tittmoning
Germany
www.rosenberger.de
Tel.: +49 8684 18-0
email: info@rosenberger.de
Page
1/2
TECHNICAL DATA SHEET
ADAPTOR
SMA JACK – DIN 41626 PLUG
Electrical data
Impedance
Frequency
VSWR
50
Ω
DC to 4 GHz
≤
1.06, DC to 1 GHz
≤
1.10, 1 to 2 GHz
≤
1.22, 2 to 4 GHz
≤
0.03 x
f(GHz)
dB
≥
5 x10
3
MΩ
≤
3 mΩ, SMA side
≤
2 mΩ, SMA side
750 V rms
250 V rms
≥
80 dB up to 0.5 GHz
≥
65 dB up to 1.5 GHz
32K145-S00L5
Insertion loss
Insulation resistance
Center contact resistance
Outer contact resistance
Test voltage
Working voltage
RF-leakage
≤
10 mΩ, DIN 41626 side
≤
3 mΩ, DIN 41626 side
Mechanical data
Mating cycles
Center contact captivation: axial
Coupling test torque
Recommended torque
Engaging and disengaging force
SMA side
min. 500
≥
27 N
max. 1.7 Nm
0.8 Nm to 1.1 Nm
N/A
DIN 41626 side
min. 500
≥
27 N
N/A
N/A
≤
10
Environmental data
Temperature range
Thermal shock
Corrosion
Vibration
Shock
Moisture resistance
RoHS
-55°C to +155°C
MIL-STD-202, Meth.
MIL-STD-202, Meth.
MIL-STD-202, Meth.
MIL-STD-202, Meth.
MIL-STD-202, Meth.
compliant
107,
101,
204,
213,
106
Cond.
Cond.
Cond.
Cond.
B
B
D
I
Tooling
N/A
Suitable cables
N/A
Weight
Weight
30.9 g/pce
While the information has been carefully compiled to the best of our knowledge, nothing is intended as representation or warranty on
our part and no statement herein shall be construed as recommendation to infringe existing patents. In the effort to improve our
products, we reserve the right to make changes judged to be necessary.
RF_35/12.04/3.0
Draft
Rong Fang
Date
21/09/04
Approved
J_Krautenbacher
Date
21.07.16
Rev.
e00
Engineering change number
15-1629
Name
I_Wallner
Date
21.07.16
Rosenberger Hochfrequenztechnik GmbH & Co. KG
P.O.Box 1260
D-84526 Tittmoning
Germany
www.rosenberger.de
Tel.: +49 8684 18-0
email: info@rosenberger.de
Page
2/2
