USB to RS-485
Mini-Converters
485USBTB-2W & 485USBTB-4W
www.advantech-bb.com
PRODUCT FEATURES
•
•
•
•
•
•
•
•
•
Connect RS-485 devices to your USBport
Perfect for Field Service Applications
Compact
USB port-powered
USB 2.0 (12 Mbps)compatible
RS-485 data rates up to 921.6 Kbps
Removable terminal block for easy wiring
High retention USB connector
Supports Windows 98, ME, 2000, XP, Vista,
7 (32/64 bit), 8 (32/64 bit)
Universal Serial Bus (USB) has become the connectivity workhorse of today’s
PCs, replacing the familiar serial ports. However, many commercial and
industrial devices still use the RS-485 interface. To connect these devices
to modern PCs, you need a simple and reliable conversion solution. The
485USBTB-2W and 485USBTB-4W offer this solution in a space saving, USB
Port powered package.
Simply install the drivers supplied on CD ROM and plug the converter into
an available USB port on your computer or USB hub. The device will show
up as an additional COM port in the Windows Device Manager which is
fully compatible with your Windows applications. Select the 485USBTB-2W
for RS-485 2-wire applications or the 485USBTB-4W for RS-485 4-wire
applications. Locked serial number versions are also available (see the
installation notes in the driver section). A USB cable is included.
ORDERING INFORMATION
MODEL NUMBER
485USBTB-2W
485USBTB-4W
485USBTB-2W-LS
485USBTB-4W-LS
DESCRIPTION
USB to RS-485 2-Wire Converter
USB to RS-485 4-Wire Converter
USB to RS-485 2-Wire Converter (Locked Serial Number)
USB to RS-485 4-Wire Converter (Locked Serial Number)
ACCESSORIES
USBAMBM-3F - 3 ft. (1 M) USB Cable (one included)
Locked Serial Numbers Explained
We configure our single-port USB to serial converters in two ways. In standard
format, each product has a unique serial number. “Locked serial” format uses the
same serial number that is associated with a model type.
If your converter will always be used with the same computer, the standard
serialized model is all you need. If the converter is shared among several
computers, like field service laptops, the locked serial number model lets you plug
and play without having to worry about matching the two.
Locked
Serial
Number
-
✔
Description
Every unit is assigned a unique COM port
Same type model numbers shares the same COM port
Ideal applications
Serialized
✔
-
Fixed
Locations
Field
Service
When ordering Locked Serial Number versions, add a “-LS” to the item number.
Serialized and Lock Serial Number versions sell for the same price.
All product specifications are subject to change without notice.
485USBTB-2W & 485USBTB-4W_2716ds
orders@advantech-bb.com
support@advantech-bb.com
Corporate Headquarters: 707 Dayton Road, PO Box 1040 Ottawa, IL 61350 USA 815-433-5100 Fax 433-5104
European Office: Westlink Commercial Park, Oranmore Co. Galway Ireland +353 91 792444 Fax +353 91 792445
USB to RS-485
Mini-Converters
485USBTB-2W & 485USBTB-4W
SPECIFICATIONS
SERIAL TECHNOLOGY
RS-485 2-Wire
Data A(-), Data B(+), Ground
RS-485 4-Wire
TDA(-), TDB(+), RDA(-), RDB(+), Ground
Connector
Removable Terminal Block (28 to 16 AWG)
Data Rate
Up to 921.6 Kbps
USB TECHNOLOGY
Connector
USB Type B Female (High Retention)
Standard
2.0 (Backward Compatible)
Data Rate
12 Mbps
POWER
Source
USB Port
Input Voltage
5 VDC
Consumption
~ 0.5 W (Low power device, draws less than 100 mA)
SOFTWARE
Windows 98, ME, 2000, XP, Vista, 7 (32/64 bit),
Driver CD
8 (32/64 bit)
MECHANICAL
Dimensions
6.5 x 3.2 x 1.6 cm (2.6 x 1.3 x 0.6 in)
Enclosure
In-line mounted, plastic
Weight
0.23 lbs (104.3 g) with USB Cable
ENVIRONMENTAL
Operating Temperature 32 to 158 °F (0 to 70 °C)
Storage Temperature -40 to 185 °F (-40 to 85 °C)
Operating Humidity
0 to 95 % (Non-condensing)
MTBF
1869313 hours
MTBF Method
Parts Count Reliability Prediction
REGULATORY
Approvals
FCC, CE
CERTIFICATIONS
2004/108/EC
2011/65/EU
EN 55022: +AC
EN 61000-6-1
EN 61000-4-2
EN 61000-4-3: +A2
EN 61000-4-4
EN 61000-4-6
Electromagnetic Compatibility Directive
Reduction of Hazardous Substances Directive
Information technology equipment - Class B RF Emissions
Generic immunity standard for residential, commercial and light
-industrial environments
ESD Immunity
Radiated Immunity
EFT/Burst Immunity
RF Conducted Immunity
3.2 cm
1.3 in
1.6 cm
0.6 in
6.5 cm
2.6 in
MECHANICAL DIAGRAM
3.2 cm
1.3 in
1.6 cm
0.6 in
6.5 cm
2.6 in
