PIC32MM0016GPL020T-I/ML datasheet, PDF

Datasheet> All Categories > The embedded processor and controller> Microcontrollers and processors> PIC32MM0016GPL020T-I/ML

Preview

PIC32MM0016GPL020T-I/ML: DescriptionIC MCU 32BIT 16KB FLASH 20QFN; CategoryThe embedded processor and controller Microcontrollers and processors; File Size777KB，2 Pages; ManufacturerMicrochip; Websitehttps://www.microchip.com

Download Datasheet Download user manual Parametric View All

PIC32MM0016GPL020T-I/ML Overview

IC MCU 32BIT 16KB FLASH 20QFN

PIC32MM0016GPL020T-I/ML Parametric

Parameter Name	Attribute value
Is it lead-free?	Lead free
package instruction	HVQCCN,
Reach Compliance Code	compliant
Has ADC	YES
Other features	ADC ALSO AVAILABLE WITH 10-BIT
Address bus width
bit size	32
maximum clock frequency	25 MHz
DAC channel	YES
DMA channel	NO
External data bus width
JESD-30 code	S-PQCC-N20
length	4 mm
Number of I/O lines	16
Number of terminals	20
On-chip program ROM width	8
Maximum operating temperature	85 °C
Minimum operating temperature	-40 °C
PWM channel	YES
Package body material	PLASTIC/EPOXY
encapsulated code	HVQCCN
Package shape	SQUARE
Package form	CHIP CARRIER, HEAT SINK/SLUG, VERY THIN PROFILE
ROM programmability	FLASH
Filter level	TS 16949
Maximum seat height	1 mm
speed	25 MHz
Maximum supply voltage	3.6 V
Minimum supply voltage	2 V
Nominal supply voltage	3.3 V
surface mount	YES
technology	CMOS
Temperature level	INDUSTRIAL
Terminal form	NO LEAD
Terminal pitch	0.5 mm
Terminal location	QUAD
width	4 mm
uPs/uCs/peripheral integrated circuit type	MICROCONTROLLER, RISC
Base Number Matches	1

User Manual

Preview

Download Datasheet

View All

32-bit MCUs

PIC32MM Family

Summary

eXtreme Low Power (XLP) Technology, Low-Cost 32-bit Microcontrollers

The PIC32MM family consisting of the GPL and GPM series is Microchip’s lowest-power and most cost-effective family of 32-bit

PIC32 microcontrollers. The PIC32MM XLP family of devices bridges the gap between our popular PIC24F XLP and PIC32MX

families. For applications demanding increased connectivity with longer battery life and small form factors, the PIC32MM devices

offer sleep modes as low as 500 nA and packages as small as 4 × 4 mm. Designed to offload the CPU and increase efficiency,

the PIC32MM family features a rich set of Core Independent Peripherals (CIPs) making this family ideal for a wide variety of

low-power applications. In addition, this family also takes advantage of the microAptiv™ UC core that uses compact microMIPS™

instructions and a shadow register set enabling a 79 CoreMark™ score at 25 MHz. The microMIPS ISA combines 16-bit and

32-bit instructions for compact code size reducing Flash usage.

Key Attributes

PIC32MM0064GPL036 Family

ECC Program Flash (KB)

RAM (KB)

Pin Count

XLP - Sleep Mode with RAM

retention

Core Independent Peripherals

USB

Hardware DMA

16–64

4–8

20–36

450 nA

ADC, Comparators, RTCC, WDT, Configurable Logic Cells (CLC),

Flexible PWMs/IC/OC/Timers- MCCP and SCCP, CRC

20-pin: QFN, SSOP

28-pin: UQFN (4 x 4), QFN (6 x 6), SOIC, SSOP, SPDIP

36-pin: QFN (6 x 6)

40-pin: UQFN (5 x 5) with 36 I/O

PIC32MM0256GPM064 Family

64–256

16–32

28–64

650 nA

ADC, Comparators, RTCC, WDT, Configurable Logic Cells (CLC),

Flexible PWMs/IC/OC/Timers- MCCP and SCCP, CRC

Yes

4-Channel DMA

28-pin: UQFN (4 x 4), QFN (6 x 6), SSOP

36-pin: QFN (6 x 6)

40-pin: UQFN (5 x 5) with 36 I/O

48-pin: UQFN (6 x 6), TQFP (7 x 7)

64-pin: QFN (9 x 9), TQFP (10 x 10)

Packages

PIC32MM0064GPL036 Family

MIPS32

microAptiv™ UC Core

microMIPS™ Instruction Set

79 CoreMark @ 25 MHz

14 Channels 10/12-bit ADC (300/200 ksps)

5-bit DAC

Analog Comparators (2)

Peripheral Pin Select (PPS)

Dedicated Timer (1) / Total Timers (7)

32-bit ALU

Vectored Interrupt

Controller

5-Stage Pipeline

32-bit MPY/DIV

2.0–3.6V

Operation

MCCP (6-PWM/IC/OC/Timer) (1)

PIC32MM0256GPM064 Family

MIPS32® microAptiv™ UC Core

microMIPS™ Instruction Set

79 CoreMark @ 25 MHz

PIC32MM0256GPM064 Family

24 Channels 10/12 bit ADC (300/200 Ksps)

5-bit DAC

Analog Comparators (3)

USB OTG (Low Speed & Full Speed)

32-bit ALU

Vectored Interrupt

Controller

5-Stage Pipeline

32-bit MPY/DIV

2.0 - 3.6 V

Operation

Total 16-bit Timers (21)

Peripheral Pin Select (PPS)

Dedicated General Purpose Timer (3)

PERIPHERAL BUS

2 x Register Files

SCCP (1-PWM/IC/OC/Timer) (2)

UART with LIN (2)

SPI with I²S (2)

Configurable Logic Cell (CLC) (2)

RTCC

CRC

WDT & BOR

20-pin: QFN, SSOP

2 x Register Files

PERIPHERAL BUS

MCCP (6-PWM/IC/OC/Timer) (3)

SCCP (1-PWM/IC/OC/Timer) (6)

UART with LIN (3)

SPI with I

S (3)

C™ (3)

Configurable Logic Cell (CLC) (4)

RTCC

WDT & BOR

28-pin: UQFN (4x4), QFN (6x6), SSOP

36-pin: QFN (6x6) / 40-pin: UQFN (5x5)

48-pin: UQFN (6X6), TQFP (7x7)

64-pin: QFN (9x9), TQFP (10x10)

MEMORY BUS

16–64 KB

ECC Flash

4–8 KB

RAM

64 - 256 KB

ECC Flash

16 - 32 KB

RAM

Low Voltage Sleep Mode 650nA

Sleep Mode 6uA

DMA/CRC

Low Voltage Sleep Mode 500 nA

Sleep Mode 5 µA

28-pin: UQFN (4 x 4), QFN (6 x 6), SOIC, SSOP, SPDIP

36-pin: QFN (6 x 6)

40-pin: UQFN (5 x 5) with 36 I/O

www.microchip.com/PIC32MM
