M39006/09, M39006/21
www.vishay.com
Vishay
Wet Tantalum Capacitors, Military Established Reliability,
MIL-PRF-39006/09/21 Qualified Styles CLR65, CLR69
FEATURES
• Hermetically sealed
• Metal cased
• Axial lead
• Tubular
STYLE, MILITARY SPECIFICATION
• CLR65, M39006/09 MIL-PRF-39006/09
• CLR69, M39006/21 MIL-PRF-39006/21
PERFORMANCE CHARACTERISTICS
Operating Temperature:
-55 °C to +125 °C
(above 85 °C, voltage derating is required)
Capacitance Range:
M39006/09 - 1.7 μF to 1200 μF;
M39006/21 - 6.8 μF to 2200 μF
Capacitance Tolerance:
± 5 %, ± 10 %, ± 20 %
Voltage Rating:
6 V
DC
to 125 V
DC
Established Reliability Tantalum Capacitors to Military
Specification MIL-PRF-39006:
in accordance with the
military specification MIL-PRF-39006 all capacitors are
marked with the military part number (M39006/xx-xxxx)
rather than the older style designation (CLR65, CLR69) and
should be ordered as such.
For information on the performance characteristics of these
capacitors, please refer to the latest issue of the military
specification.
Each order for military style capacitors requiring
government inspection must state whether inspection is to
be at the destination or at the Vishay plant. Orders requiring
source inspection cannot be shipped until this has been
accomplished.
ORDERING INFORMATION
M39006
BASIC DOCUMENT NUMBER
Indicates the basic specification;
in this case MIL-PRF-39006
/09
SLASH SHEET
Indicates the specification sheet
of the basic military specification
-8005
DASH NUMBER
Taken from
Standard/Extended Ratings tables
Revison: 28-Aug-17
Document Number: 40159
