SQFlash
SATA DOM 630 Horizontal
SATA DOM 630 Horizontal
Datasheet
(SQF-SDMxx-xG-9xx)
Specifications subject to change without notice, contact your sales representatives for the most update information.
REV 1.0
Page 1 of 25
Apr. 1, 2016
SQFlash
SATA DOM 630 Horizontal
CONTENTS
1. Overview ............................................................................................ 4
2. Features ............................................................................................. 5
3. Specification Table ............................................................................ 6
4. General Description .......................................................................... 8
5. Pin Assignment and Description ................................................... 10
5.1 SATA DOM Interface Pin Assignments (Signal Segment) ............................................. 10
5.2 Write Protect Switch Direction ....................................................................................... 10
6. Identify Device Data ........................................................................ 11
7. ATA Command Set .......................................................................... 15
8. System Power Consumption ......................................................... 21
8.1 Supply Voltage .............................................................................................................. 21
8.2 Power Consumption ...................................................................................................... 21
9. Physical Dimension ........................................................................ 22
Appendix: Part Number Table ........................................................... 23
Specifications subject to change without notice, contact your sales representatives for the most update information.
REV 1.0
Page 2 of 25
Apr. 1, 2016
SQFlash
SATA DOM 630 Horizontal
Revision History
Rev.
Date
History
0.1
0.2
0.3
1.0
2014/4/24
2014/4/24
2015/4/2
2016/4/1
1.
1.
1.
1.
1 draft
Add write protect switch direction
Add power cable information
MLC / UMLC update to 15nm
st
Advantech reserves the right to make changes without further notice to any products or data herein to improve reliability, function, or
design. Information furnished by Advantech is believed to be accurate and reliable. However, Advantech does not assure any liability
arising out of the application or use of this information, nor the application or use of any product or circuit described herein, neither
does it convey any license under its patent rights nor the rights of others.
Copyright © 1983-2010 Advantech Co., Ltd. All rights reserved.
Specifications subject to change without notice, contact your sales representatives for the most update information.
REV 1.0
Page 3 of 25
Apr. 1, 2016
SQFlash
SATA DOM 630 Horizontal
1.
Overview
Advantech SQFlash SATA DOM combines the advantages of flash disk technology with the Serial ATA III
interface, which electrically complies with the Serial ATA International Organization Standard. SATA DOM,
consisting of a 7-pin standard SATA interface for mounting on motherboard directly, is designed to operate at a
maximum operating frequency of 300MHz with 40MHz external crystal. SQFlash SATA DOM comes with a wide
range of capacities from 1GB to 64GB for SLC, and 4GB to up to 128GB for MLC, and delivers the read / write
performance up to 500MB/s and 150MB/s, respectively based on Toshiba 24nm toggle SLC Flash IC. Given the
features of the low power consumption, small form factor, and high shock-resistance, SATA DOM are deemed to be
widely adopted storage device for embedded solutions, and will be an attractive solution to replace the conventional
[PATA-interfaced] CompactFlash card in industrial applications.
Specifications subject to change without notice, contact your sales representatives for the most update information.
REV 1.0
Page 4 of 25
Apr. 1, 2016
SQFlash
SATA DOM 630 Horizontal
2.
–
–
–
Features
Standard SATA interface
Support SATA 1.5 Gbps, 3.0 Gbps, and 6.0 Gbps interface
SATA Revision 3.0 compliant
Power management supported
–
Operating Voltage：5V
Support 72 bit ECC correct per 1K Byte data
TRIM、AHCI supported
Hardware write protect supported
Temperature Ranges
Commercial Temperature
● 0℃ to 70℃ for operating
● -40℃ to 85℃ for storage
–
Industrial Temperature
● -40℃ to 85℃ for operating
● -40℃ to 85℃ for storage
–
–
Mechanical Specification
Shock：1,500G / 0.5ms
Vibration：20G / 80~2,000Hz
–
Humidty
Humidity：5% ~ 95% under 55℃
–
Endurance :
> 2,000,000 program/erase cycles
This is a test result of the whole SQFlash drive. The test is to keep writing a fixed logical block address (LBA)
and see if any bad blocks occur after 2M cycles. With wear-levelling mechanism, although the disk was kept
writing the same LBA but the physical block changes per block writing. So this test also proves that
wear-leveling is really working, or the block would be wearout after its designated life cycles.
–
Data Retention
10 years
Acquired RoHS、WHQL、CE、FCC Certificate
Acoustic：0 dB
Dimension：44.7 mm x 22.2 mm x 1.0 mm
Specifications subject to change without notice, contact your sales representatives for the most update information.
REV 1.0
Page 5 of 25
Apr. 1, 2016
