Ordering number : EN8992
SS3003CH
SANYO Semiconductors
DATA SHEET
SS3003CH
Applications
•
Low VF Schottky Barrier Diode
30V, 3.0A Rectifier
High frequency rectification (switching regulators, converters, choppers).
Features
•
•
•
Small switching noise.
Low forward voltage (IF=3A, VF max=0.42V).
Ultrasmall package permitting applied sets to be small and slim.
Specifications
Absolute Maximum Ratings
at Ta=25°C
Parameter
Repetitive Peak Reverse Voltage
Nonrepetitive Peak Reverse Surge Voltage
Average Output Current
Surge Forward Current
Junction Temperature
Storage Temperature
Symbol
VRRM
VRSM
IO
IFSM
Tj
Tstg
50Hz sine wave, 1 cycle
Conditions
Ratings
30
30
3.0
20
--55 to +125
--55 to +125
Unit
V
V
A
A
°C
°C
Electrical Characteristics
at Ta=25°C
Parameter
Reverse Voltage
Forward Voltage
Reverse Current
Interterminal Capacitance
Reverse Recovery Time
Thermal Resistance
Symbol
VR
VF
IR
C
trr
Rth(j-a)
IR=2.0mA
IF=2.0A
IF=3.0A
VR=15V
VR=10V, f=1MHz
IF=IR=100mA
Mouted on a ceramic board (900mm
2
!0.8mm)
Conditions
Ratings
min
30
0.335
0.37
90
20
50
0.385
0.42
1.4
typ
max
Unit
V
V
V
mA
pF
ns
°C
/ W
Marking : SG
Any and all SANYO Semiconductor products described or contained herein do not have specifications
that can handle applications that require extremely high levels of reliability, such as life-support systems,
aircraft's control systems, or other applications whose failure can be reasonably expected to result in
serious physical and/or material damage. Consult with your SANYO Semiconductor representative
nearest you before usingany SANYO Semiconductor products described or contained herein in such
applications.
SANYO Semiconductor assumes no responsibility for equipment failures that result from using products
at values that exceed, even momentarily, rated values (such as maximum ratings, operating condition
ranges, or other parameters) listed in products specifications of any and all SANYO Semiconductor
products described or contained herein.
TOKYO OFFICE Tokyo Bldg., 1-10, 1 Chome, Ueno, Taito-ku, TOKYO, 110-8534 JAPAN
72606 / 32406SB MS IM TB-00002130 No.8992-1/3
SS3003CH
140
Tc -- IO
Interterminal Capacitance, C -- pF
(1)Rectangular wave
θ
=60
°
(2)Rectangular wave
θ
=120
°
(3)Rectangular wave
θ
=180
°
(4)Sine wave
θ
=180
°
7
5
C -- VR
120
Case Temperature, Tc --
°C
100
3
2
80 *When mounted in reliability
operaion board,
Rth(J-a)=50°C/W
60
Rectangular
wave
40
100
7
5
θ
360°
20
0
0
Sine
wave
180°
360°
0.5
1.0
1.5
2.0
(1)
(2) (4)
(3)
2.5
3.0
3.5
IT10608
3
0.1
2
3
5
7 1.0
2
3
5
7 10
2
3
5
Average Output Current, IO -- A
24
IFSM -- t
I
S
Reverse Voltage, VR -- V
IT09871
Surge Forward Current, IFSM(Peak) -- A
Current waveform 50Hz sine wave
20
16
20ms
t
12
8
4
0
7 0.01
2
3
5
7 0.1
2
3
5
7 1.0
2
3
Time, t -- s
ID00523
