RoHS Compliant
ALUMINIUM ELECTROLYTIC CAPACITOR
FEATURES
◆
◆
SS Series
7mm height to meet the requirement of smaller, thinner electronic products
Applications for VTR, calculators, micro video and audio products, etc.
OUTLINE
mm
D
F
d
4
1.5
5
2.0
6.3
2.5
8
3.5
0.45
0.50
SPECIFICATIONS
Items
Capacitance Tolerance
(120Hz, 25°C)
Rated Working Voltage Range
Operation Temperature
Characteristics
±
20% (M)
4 ~ 63Vdc
-40°C ~ +85°C
(After 2 minutes applying the Dc working voltage)
Leakage Current (25°C)
◆
I
≤
0.01CV or 3 (u A)
I : Leakage Current (u A)
W.V.
4
5
4
0.35
4
7
15
6.3
8
6.3
0.24
6.3
4
8
◆
C : Rated Capacitance (u F)
10
13
10
0.20
10
3
6
16
20
16
0.16
16
2
4
25
32
25
0.14
25
2
4
◆
V : Working Voltage (V)
35
44
35
0.12
35
2
3
50
63
50
0.10
50
2
3
63
79
63
0.10
63
2
3
Surge Voltage (25°C)
S.V.
W.V.
Dissipation Factor (120Hz, 25°C)
tan
δ
W.V.
- 25°C / + 25°C
Temperature Characteristics
- 40°C / + 25°C
◆
Impedance ratio at 120Hz
After 1000 hours application of WV at +85°C, the capacitor shall meet the following limits:
Capacitance Change
Load Test
tan
δ
Leakage Current
≤ ±
20% of initial value
≤
200% of initial specified value
≤
initial specified value
After 500 hours, no voltage applied at + 85°C, the capacitor shall meet the following limits:
Capacitance Change
Shelf Test
tan
δ
Leakage Current
≤ ±
20% of initial value
≤
200% of initial specified value
≤
200% of initial specified value
