SPN2054

N-Channel Enhancement Mode MOSFET

DESCRIPTION

The SPN2054 is the N-Channel logic enhancement mode

power field effect transistors are produced using high cell

density , DMOS trench technology.

This high density process is especially tailored to

minimize on-state resistance. These devices are

particularly suited for low voltage application, such as

DC/DC converter and Desktop computer power

management.

The package is universally preferred for commercial

industrial surface mount applications

FEATURES

20V/12A,R

DS(ON)

=40mΩ@V

=10V

20V/ 7A,R

DS(ON)

=45mΩ@V

=4.5V

20V/ 4A,R

DS(ON)

=50mΩ@V

=2.5V

20V/ 2A,R

DS(ON)

=60mΩ@V

=1.8V

Super high density cell design for extremely low

RDS (ON)

Exceptional on-resistance and maximum DC

current capability

TO-252-2L package design

APPLICATIONS

Power Management in Desktop Computer

DC/DC Converter

LCD Display inverter

PIN CONFIGURATION(TO-252-2L)

PART MARKING

2006/08/16

Ver.3

Page 1
