PERFORMANCE SPECIFICATIONS SUMMARY AND ORDERING GUIDE
Output
Model Number
Input
Efficiency
(%)
Package
(mm)
Vo
Io
Power R/N Max. Regulation (Max.) Vin typ. Range Iin, no load Iin, full load
(Vdc) (A,Max.) (W) (mV p-p) Line (%) Load (%) (Vdc)
(Vdc)
Typ.(mA)
Typ.(A)
5-25
(typ.:24V)
MYSGK02506BRSR
6
150
50
±2.0
±2.0
36
13.5-42
22
4.06
98
14.7 x 16.3 x 7.5
1.All specifications are at typical line voltage, Vo = typ. and full load, +25degC unless otherwise noted. Output capacitors are 4.7uF ceramic and 68uF conductive polymer hybrid
aluminum electrolytic capacitor. Input capacitors is 4.7uFx 4 ceramic and plenty electrolytic capacitors. See detailed specifications. Input and output capacitors are necessary for
our test equipment.
2.Use adequate ground plane and copper thickness adjacent to the converter.
PART NUMBER STRUCTURE
MY
SGK
025
06
BRSR
Murata products
Internal Code
Series Name
Maximum Output Current
06 = 6A
Maximum Output Voltage
025 = 25V
PRODUCT MARKING
Layout
□□□□□□□□
Codes
******
Item
□□□□□□□□
Contents
Lot No. (8-digit alphanumeric)
Product Code
Internal code
EB
###
EB
###
1pin
http://www.murata.com/products/power
MYSGK02506BRSR A04 Page 2 of 18
MYSGK02506BRSR
DC-DC converter
FUNCTIONAL SPECIFICATIONS
ABSOLUTE MAXIMUM RATINGS
Conditions
Minimum
Typical / Nominal
Maximum
Units
Input Voltage, Continuous
-0.3
50
Vdc
EN/UVLO
-0.3
8.8
Vdc
VAR pin
Source ONLY
Storage Temperature Range
Vin = Zero (no power)
-40
125
degC
Absolute maximums are stress ratings. Exposure of devices to greater than any of these conditions may adversely affect long-term reliability. Proper operation under conditions other
than those listed in the Performance/Functional Specifications Table is not implied or recommended.
INPUT
Conditions
Minimum
Typical / Nominal
Maximum
Units
Operating Voltage Range (Vin)
Vin>Vo * 1.17
13.5
36
42
Vdc
Rising input voltage
Startup threshold
8.82
Vdc
RUVLO1 = OPEN, RUVLO2 = OPEN
Shutdown input voltage
Shutdown threshold
4.42
Vdc
RUVLO1 = OPEN, RUVLO2 = OPEN
Input current
Full Load Conditions
Vin = 36V, Vo = 24V, Io =6A
4.06
A
No Load Current
Vin = 36V, Vo = 24V, Io = 0A
22
mA
1
8
Vdc
Power ON
EN/UVLO pin Voltage
OPEN
Power OFF
-0.3
0.1
Vdc
GENERAL
Conditions
Minimum
Typical / Nominal
Maximum
Units
Efficiency
Vin = 36V, Vo = 24V, Io = 6A
98
%
DYNAMIC CHARACTERISTICS
Conditions
Minimum
Typical / Nominal
Maximum
Units
Fixed Switching Frequency
380
kHz
Startup Time (Vin ON)
24
ms
Startup Time (EN ON)
24
ms
OUTPUT
Conditions
Minimum
Typical / Nominal
Maximum
Units
Voltage
RVER = 0Ω
24.12
25
25.88
Vdc
RVER = 86.7Ω
23.16
24
24.84
Vdc
RVER = 888Ω
17.37
18
18.63
Vdc
Output Voltage (Vo)
RVER = 1.65kΩ
14.47
15
15.53
Vdc
RVER = 3.068kΩ
11.58
12
12.42
Vdc
RVER = OPEN
4.82
5
5.18
Vdc
Current
Vin > 36V and Vo > 15.53V
0
5
A
Output Current Range (Io)
0
6
A
Vin≦36V or Vo
≦15.53V
Short circuit protection method
Hiccup current limiting
Non-latching
Vin = 36V, Vo = 24V, Io = 6A
Ripple Voltage
50
mV p-p
20 MHz BW
External Output Capacitive
60
150
uF
MECHANICAL
Conditions
Minimum
Typical / Nominal
Maximum
Units
Outline Dimensions
14.7(typ.) x 16.3(typ.) x 7.5(max.)
mm
Weight
3.7
grams
ENVIRONMENTAL
Conditions
Minimum
Typical / Nominal
Maximum
Units
degC
Operating Ambient Temperature Range
-40
85
Moisture Sensitivity Level
3
(1)All models are tested and specified with external 4.7uF ceramic and
