M2497 SL001 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Wire/cable> M2497 SL001

M2497 SL001: DescriptionMULTI-PAIR 36COND 28AWG 1000'; CategoryWire/cable; File Size180KB，4 Pages; ManufacturerAlpha Wire; Websitehttp://www.alphawire.com/zh-CN/; Environmental Compliance

Download Datasheet Parametric Compare View All

M2497 SL001 Overview

MULTI-PAIR 36COND 28AWG 1000'

M2497 SL001 Parametric

Parameter Name	Attribute value
Cable type	Multiple pairs
Number of conductors	36 (18 twisted pairs)
Wire gauge	28 AWG
Number of wire strands	7/36
conductor material	Copper, tin plated
Sheath (insulation) material	Polyvinyl chloride (PVC)
Sheath (insulation) diameter	0.457"（11.61mm）
Shield type	foil, braided wire
length	1000.0'（304.8m）
Casing color	slate color
grade	UL Type 2919
characteristic	drain wire, drawstring
Voltage	300V
Operating temperature	-20°C ~ 80°C
use	-
Sheath (insulation) thickness	0.0350"（0.889mm）
conductor insulation	Foamed polypropylene (FPP)
shielding material	Aluminum; copper, tinned
Shielding range	100%，65%

Preview

Download Datasheet

View All

Alpha Wire | 711 Lidgerwood Avenue, Elizabeth, NJ 07207

Tel: 1-800-52 ALPHA (25742), Web: www.alphawire.com

Customer Specification

PART NO. M2497

Construction

Diameters (In)

1) Component 1

a) Conductor

b) Insulation

(1) Color Code

Pair

Color

BLUE/WHITE -

WHITE/BLUE

ORANGE/WHITE -

WHITE/ORANGE

GREEN/WHITE -

WHITE/GREEN

BROWN/WHITE -

WHITE/BROWN

SLATE/WHITE -

WHITE/SLATE

BLUE/RED -

RED/BLUE

18 X 1 PAIR

28 (7/36) AWG TC

0.0145" Wall, Nom. Polyethylene, Foam

Alpha Wire Color Code M

Pair

Color

ORANGE/RED -

RED/ORANGE

GREEN/RED -

RED/GREEN

BROWN/RED -

RED/BROWN

SLATE/RED -

RED/SLATE

BLUE/BLACK -

BLACK/BLUE

ORANGE/BLACK -

BLACK/ORANGE

Pair

Color

GREEN/BLACK -

BLACK/GREEN

BROWN/BLACK -

BLACK/BROWN

SLATE/BLACK -

BLACK/SLATE

BLUE/YELLOW -

YELLOW/BLUE

ORANGE/YELLOW -

YELLOW/ORANGE

GREEN/YELLOW -

YELLOW/GREEN

0.015

0.044

c) Pair

(1) Twists:

2) Cable Assembly

a) Twists:

3) Shield:

a) Foil Direction

b) Drain Wire

c) Braid

4) Jacket

a) Color(s)

b) Ripcord

2/Cond Cabled Together

9.6 Twists/foot (min)

18 Components Cabled

2.3 Twists/foot (min)

Alum/Mylar Tape, 25% Overlap, Min.

Foil Facing Out

28 (7/36) AWG TC

TC,65% Coverage, Min.

0.035" Wall, Nom.,PVC

SLATE

1 End 810 Denier Nylon

ALPHA WIRE-* P/N M2497 18PR 28 AWG

EXXXXXX SHIELDED 75C CM (UL) C(UL) OR

0.457 (0.482 Max.)

c) Print

AWM 2919 LOW VOLTAGE COMPUTER CABLE

CE ROHS

* = Factory Code

[Note: Product may have c(UL) or CSA markings depending upon plant of manufacture.]

Applicable Specifications

EU/China ROHS CERTIFICATE OF COMPLIANCE

To Whom It May Concern:

Alpha Wire Part Number: M2497

M2497 , RoHS-Compliant Commencing With 7/1/2005 Production

This document certifies that the Alpha part number cited above is manufactured in accordance with Directive 2011/65/EU of the European

Parliament, better known as the RoHS Directive, with regards to restrictions of the use of certain hazardous substances used in the manufacture of

electrical and electronic equipment. The reader is referred to this Directive for the specific definitions and extents of this Directive. No Exemptions

are required for RoHS Compliance on this item. It should be noted that this product does not fall within the scope of Directive 2011/65/EU, but this

Certificate is offered for cases where this product will be used within EEE that does fit within the Directive's scope. Additionally, Alpha certifies that

the listed part number is in compliance with China RoHS “Marking for Control of Pollution by Electronic Information Products” standard SJ/T 11364-

2006.

Substance

Lead

Mercury

Cadmium

Hexavalent Chromium

Polybrominated Biphenyls (PBB)

Polybrominated Diphenyl Ethers (PBDE) ,

Including Deca-BDE

0.1% by weight (1000 ppm)

The information provided in this document and disclosure is correct to the best of Alpha Wire's knowledge, information and belief at the date of its

release. The information provided is designed only as a general guide for the safe handling, storage, and any other operation of the product itself or

the one that it will become part of. The intent of this document is not to be considered a warranty or quality specification. Regulatory information is

for guidance purposes only. Product users are responsible for determining the applicability of legislation and regulations based on their individual

usage of the product.

Authorized Signatory for the Alpha Wire Company:

Maximum Control Value

0.1% by weight (1000 ppm)

0.01% by weight (100 ppm)

0.1% by weight (1000 ppm )

0.1% by weight (1000 ppm)

Dave Watson, Director of Engineering & QA

5/13/2013

M2497 SL001 Related Products

	M2497 SL001	M2497 SL005	M2497 SL002
Description	MULTI-PAIR 36COND 28AWG 1000'	MULTI-PAIR 36COND 28AWG 100'	MULTI-PAIR 36COND 28AWG 500'
Cable type	Multiple pairs	Multiple pairs	Multiple pairs
Number of conductors	36 (18 twisted pairs)	36 (18 twisted pairs)	36 (18 twisted pairs)
Wire gauge	28 AWG	28 AWG	28 AWG
Number of wire strands	7/36	7/36	7/36
conductor material	Copper, tin plated	Copper, tin plated	Copper, tin plated
Sheath (insulation) material	Polyvinyl chloride (PVC)	Polyvinyl chloride (PVC)	Polyvinyl chloride (PVC)
Sheath (insulation) diameter	0.457"（11.61mm）	0.457"（11.61mm）	0.457"（11.61mm）
Shield type	foil, braided wire	foil, braided wire	foil, braided wire
length	1000.0'（304.8m）	100.0'（30.5m）	500.0'（152.4m）
Casing color	slate color	slate color	slate color
grade	UL Type 2919	UL Type 2919	UL Type 2919
characteristic	drain wire, drawstring	drain wire, drawstring	drain wire, drawstring
Voltage	300V	300V	300V
Operating temperature	-20°C ~ 80°C	-20°C ~ 80°C	-20°C ~ 80°C
Sheath (insulation) thickness	0.0350"（0.889mm）	0.0350"（0.889mm）	0.0350"（0.889mm）
conductor insulation	Foamed polypropylene (FPP)	Foamed polypropylene (FPP)	Foamed polypropylene (FPP)
shielding material	Aluminum; copper, tinned	Aluminum; copper, tinned	Aluminum; copper, tinned
Shielding range	100%，65%	100%，65%	100%，65%
