M4520 SL001

Description
CABLE 12COND 20AWG SLATE 1000'
CategoryWire/cable
File Size180KB,4 Pages
ManufacturerAlpha Wire
Websitehttp://www.alphawire.com/zh-CN/
Environmental Compliance
Download Datasheet Parametric Compare View All

M4520 SL001 Overview

CABLE 12COND 20AWG SLATE 1000'

M4520 SL001 Parametric

Parameter NameAttribute value
Cable typemulti-core
Number of conductors12
Wire gauge20 AWG
Number of wire strands7/28
conductor materialCopper, tin plated
Sheath (insulation) materialPolyvinyl chloride (PVC)
Sheath (insulation) diameter0.370"(9.40mm)
Shield type-
length1000.0'(304.8m)
Casing colorslate color
gradeUL Type 2343
characteristicdrawstring
Voltage300V
Operating temperature-20°C ~ 80°C
use-
Sheath (insulation) thickness0.0630"(1.600mm)
conductor insulationPolyvinyl chloride (PVC)
shielding material-
Shielding range-
Alpha Wire | 711 Lidgerwood Avenue, Elizabeth, NJ 07207
Tel: 1-800-52 ALPHA (25742), Web: www.alphawire.com
Customer Specification
PART NO. M4520
Construction
Diameters (In)
1) Component 1
a) Conductor
b) Insulation
(1) Color Code
Cond
1
2
3
4
2) Cable Assembly
a) Twists:
b) Core Wrap
3) Jacket
a) Color(s)
b) Ripcord
Color
BLACK
BROWN
RED
ORANGE
12 X 1 COND
20 (7/28) AWG TC
0.010" Wall, Nom. PVC, Semi Rigid
Alpha Wire Color Code E
Cond
5
6
7
8
12 Components Cabled
4.4 Twists/foot (min)
Clear Mylar Tape, 25% Overlap, Min.
0.063" Wall, Nom.,PVC
SLATE
1 End 810 Denier Nylon
ALPHA WIRE-* P/N M4520 12C 20 AWG
EXXXXXX 75C CMG (UL) C(UL) OR AWM 2343
c) Print
CE ROHS
* = Factory Code
[Note: Product may have c(UL) or CSA markings depending upon plant of manufacture.]
0.370 (0.388 Max.)
Color
YELLOW
GREEN
BLUE
VIOLET
Cond
9
10
11
12
Color
SLATE
WHITE
WHITE/BLACK
WHITE/BROWN
0.038
0.058
Applicable Specifications
1) UL
AWM/STYLE 2343
CMG
2) CSA International
C(UL) TYPE CMG
FT4
3) CE:
EU Low Voltage Directive 2006/95/EC
80°C / 300 VRMS
75°C
75°C
Environmental

M4520 SL001 Related Products

M4520 SL001 M4520 SL005 M4520 SL002
Description CABLE 12COND 20AWG SLATE 1000' CABLE 12COND 20AWG SLATE 100' CABLE 12COND 20AWG SLATE 500'
Cable type multi-core multi-core multi-core
Number of conductors 12 12 12
Wire gauge 20 AWG 20 AWG 20 AWG
Number of wire strands 7/28 7/28 7/28
conductor material Copper, tin plated Copper, tin plated Copper, tin plated
Sheath (insulation) material Polyvinyl chloride (PVC) Polyvinyl chloride (PVC) Polyvinyl chloride (PVC)
Sheath (insulation) diameter 0.370"(9.40mm) 0.370"(9.40mm) 0.370"(9.40mm)
length 1000.0'(304.8m) 100.0'(30.5m) 500.0'(152.4m)
Casing color slate color slate color slate color
grade UL Type 2343 UL Type 2343 UL Type 2343
characteristic drawstring drawstring drawstring
Voltage 300V 300V 300V
Operating temperature -20°C ~ 80°C -20°C ~ 80°C -20°C ~ 80°C
Sheath (insulation) thickness 0.0630"(1.600mm) 0.0630"(1.600mm) 0.0630"(1.600mm)
conductor insulation Polyvinyl chloride (PVC) Polyvinyl chloride (PVC) Polyvinyl chloride (PVC)
