M4786 SL002

Description
MULTI-PAIR 6COND 20AWG SHLD 500'
CategoryWire/cable
File Size180KB,4 Pages
ManufacturerAlpha Wire
Websitehttp://www.alphawire.com/zh-CN/
Environmental Compliance
Download Datasheet Parametric Compare View All

M4786 SL002 Overview

MULTI-PAIR 6COND 20AWG SHLD 500'

M4786 SL002 Parametric

Parameter NameAttribute value
Cable typeMultiple pairs
Number of conductors6 (3 twisted pairs)
Wire gauge20 AWG
Number of wire strands7/28
conductor materialCopper, tin plated
Sheath (insulation) materialPolyvinyl chloride (PVC)
Sheath (insulation) diameter0.319"(8.10mm)
Shield typefoil
length500.0'(152.4m)
Casing colorslate color
gradeUL Type 2464
characteristicdrain wire, drawstring
Voltage300V
Operating temperature-20°C ~ 80°C
use-
Sheath (insulation) thickness0.0320"(0.813mm)
conductor insulationPolyvinyl chloride (PVC)
shielding materialaluminum
Shielding range100%
Alpha Wire | 711 Lidgerwood Avenue, Elizabeth, NJ 07207
Tel: 1-800-52 ALPHA (25742), Web: www.alphawire.com
Customer Specification
PART NO. M4786
Construction
Diameters (In)
1) Component 1
a) Conductor
b) Insulation
(1) Color Code
Pair
1
c) Pair
(1) Twists:
2) Cable Assembly
a) Twists:
b) Core Wrap
3) Shield:
a) Foil Direction
b) Drain Wire
4) Jacket
a) Color(s)
b) Ripcord
Color
BLACK-RED
3 X 1 PAIR
20 (7/28) AWG TC
0.016" Wall, Nom. PVC
Alpha Wire Color Code A
Pair
2
Color
BLACK-WHITE
Pair
3
Color
BLACK-GREEN
0.038
0.070
2/Cond Cabled Together
6.0 Twists/foot (min)
3 Components Cabled
3.4 Twists/foot (min)
Clear Mylar Tape, 25% Overlap, Min.
Alum/Mylar Tape, 25% Overlap, Min.
Foil Facing In
20 (7/28) AWG TC
0.032" Wall, Nom.,PVC
SLATE
1 End 810 Denier Nylon
ALPHA WIRE-* P/N M4786 3PR 20 AWG
EXXXXXX SHIELDED 75C CMG (UL) C(UL) OR
0.319 (0.333 Max.)
c) Print
AWM 2464 CE ROHS
* = Factory Code
[Note: Product may have c(UL) or CSA markings depending upon plant of manufacture.]
Applicable Specifications
1) UL
CMG
AWM/STYLE 2464
2) CSA International
C(UL) TYPE CMG
FT4
3) CE:
EU Low Voltage Directive 2006/95/EC
75°C
80°C / 300 VRMS
75°C
Environmental
