M52894 SL001 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Wire/cable> M52894 SL001

M52894 SL001: DescriptionMULTI-PAIR 4COND 24AWG 1000'; CategoryWire/cable; File Size179KB，3 Pages; ManufacturerAlpha Wire; Websitehttp://www.alphawire.com/zh-CN/; Environmental Compliance

Download Datasheet Parametric Compare View All

M52894 SL001 Overview

MULTI-PAIR 4COND 24AWG 1000'

M52894 SL001 Parametric

Parameter Name	Attribute value
Cable type	Multiple pairs
Number of conductors	4 (2 twisted pairs)
Wire gauge	24 AWG
Number of wire strands	7/32
conductor material	Copper, tin plated
Sheath (insulation) material	Polyvinyl chloride (PVC)
Sheath (insulation) diameter	0.155"（3.94mm）
Shield type	foil
length	1000.0'（304.8m）
Casing color	slate color
grade	-
characteristic	drain wire
Voltage	300V
Operating temperature	-20°C ~ 75°C
use	-
Sheath (insulation) thickness	0.0150"（0.381mm）
conductor insulation	Fluorinated ethylene-propylene (FEP)
shielding material	aluminum
Shielding range	100%

Preview

Download Datasheet

View All

Alpha Wire | 711 Lidgerwood Avenue, Elizabeth, NJ 07207

Tel: 1-800-52 ALPHA (25742), Web: www.alphawire.com

Customer Specification

PART NO. M52894

Construction

Diameters (In)

1) Component 1

a) Conductor

b) Insulation

(1) Color Code

Pair

c) Pair

(1) Twists:

2) Cable Assembly

a) Twists:

b) Core Wrap

3) Shield:

a) Foil Direction

b) Drain Wire

4) Jacket

a) Color(s)

Color

BLACK-RED

2 X 1 PAIR

24 (7/32) AWG TC

0.006" Wall, Nom. FEP

Alpha Wire Color Code K

Pair

Color

BLACK-WHITE

Pair

Color

0.024

0.036

2/Cond Cabled Together

12.0 Twists/foot (min)

2 Components Cabled

6.9 Twists/foot (min)

Clear Mylar Tape, 25% Overlap, Min.

Alum/Mylar Tape, 25% Overlap, Min.

Foil Facing In

24 (7/32) AWG TC

0.015" Wall, Nom.,PVC, Plenum Rated

SLATE

ALPHA WIRE-* P/N M52894 2PR 24 AWG

SHIELDED 75C CMP(UL) C(UL) ROHS

* = Factory Code

0.155 (0.165 Max.)

b) Print

[Note: Product may have c(UL) or CSA markings depending upon plant of manufacture.]

Applicable Specifications

1) UL

2) CSA International

CMP

FT6

75°C

Environmental

1) EU Directive 2002/95/EC(RoHS):

All materials used in the manufacture of this part are in compliance with EU Directive

2002/95/EU regarding the restriction of use of certain hazardous substances in electrical and

electronic equipment. Consult Alpha Wire's web site for compliance Date of Manufacture.

2) California Proposition 65:

The outer surface materials used in the manufacture of this part meet the requirements of

California Proposition 65.

Properties

EU/China ROHS CERTIFICATE OF COMPLIANCE

To Whom It May Concern:

Alpha Wire Part Number: M52894

M52894 , RoHS-Compliant Commencing With 1/5/2009 Production

This document certifies that the Alpha part number cited above is manufactured in accordance with Directive 2011/65/EU of the European

Parliament, better known as the RoHS Directive, with regards to restrictions of the use of certain hazardous substances used in the manufacture of

electrical and electronic equipment. The reader is referred to this Directive for the specific definitions and extents of this Directive. No Exemptions

are required for RoHS Compliance on this item. It should be noted that this product does not fall within the scope of Directive 2011/65/EU, but this

Certificate is offered for cases where this product will be used within EEE that does fit within the Directive's scope. Additionally, Alpha certifies that

the listed part number is in compliance with China RoHS “Marking for Control of Pollution by Electronic Information Products” standard SJ/T 11364-

2006.

Substance

Lead

Mercury

Cadmium

Hexavalent Chromium

Polybrominated Biphenyls (PBB)

Polybrominated Diphenyl Ethers (PBDE) ,

Including Deca-BDE

0.1% by weight (1000 ppm)

The information provided in this document and disclosure is correct to the best of Alpha Wire's knowledge, information and belief at the date of its

release. The information provided is designed only as a general guide for the safe handling, storage, and any other operation of the product itself or

the one that it will become part of. The intent of this document is not to be considered a warranty or quality specification. Regulatory information is

for guidance purposes only. Product users are responsible for determining the applicability of legislation and regulations based on their individual

usage of the product.

Authorized Signatory for the Alpha Wire Company:

Maximum Control Value

0.1% by weight (1000 ppm)

0.01% by weight (100 ppm)

0.1% by weight (1000 ppm )

0.1% by weight (1000 ppm)

Dave Watson, Director of Engineering & QA

5/14/2013

M52894 SL001 Related Products

	M52894 SL001	M52894 SL005
Description	MULTI-PAIR 4COND 24AWG 1000'	MULTI-PAIR 4COND 24AWG SHLD 100'
Cable type	Multiple pairs	Multiple pairs
Number of conductors	4 (2 twisted pairs)	4 (2 twisted pairs)
Wire gauge	24 AWG	24 AWG
Number of wire strands	7/32	7/32
conductor material	Copper, tin plated	Copper, tin plated
Sheath (insulation) material	Polyvinyl chloride (PVC)	Polyvinyl chloride (PVC)
Sheath (insulation) diameter	0.155"（3.94mm）	0.155"（3.94mm）
Shield type	foil	foil
length	1000.0'（304.8m）	100.0'（30.5m）
Casing color	slate color	slate color
characteristic	drain wire	drain wire
Voltage	300V	300V
Operating temperature	-20°C ~ 75°C	-20°C ~ 75°C
Sheath (insulation) thickness	0.0150"（0.381mm）	0.0150"（0.381mm）
conductor insulation	Fluorinated ethylene-propylene (FEP)	Fluorinated ethylene-propylene (FEP)
shielding material	aluminum	aluminum
Shielding range	100%	100%
