Product Family Data Sheet

Rev. 1.1 2016.6.01.

1#

Middle Power LED Series

Flip Chip Package

LM102A

LM102A opens up a new world of lighting design with its high output and small

form factors

Features & Benefits

•

Greater freedom of design with compact package size

•

High degree of reliability with plastic-free structure

•

Low thermal resistance

•

High efficiency providing optimized solution

•

Compact footprint (1.34 x 1.34 mm)

Applications

Indoor Lighting:

•

Downlight

LED Bulbs

LED Tubes

MR / PAR

Ambient Light

Ceiling Light

2

Table of Contents

1.

2.

3.

4.

5.

6.

7.

8.

9.

10.

Characteristics

Product Code Information

Typical Characteristics Graphs

Outline Drawing & Dimension

Reliability Test Items & Conditions

Soldering Conditions

Tape & Reel

Label Structure

Packing Structure

Precautions in Handling & Use

-----------------------

3

6

16

18

19

20

21

23

24

26

3

1. Characteristics

a) Absolute Maximum Rating

Item

Operating Temperature

Symbol

T

a

Rating

-40 ~ +85

Unit

ºC

Condition

-

Storage Temperature

T

stg

-40 ~ +120

ºC

-

LED Junction Temperature

T

j

125

ºC

-

Forward Current

I

F

250

260

<10

2

mA

ºC

s

kV

-

Assembly Process Temperature

-

ESD (HBM)

-

4

b) Electro-optical Characteristics

(I

F

= 150 mA, T

s

= 85 ºC)

Item

Unit

Rank

Bin

Min.

Typ.

Max.

Forward Voltage (V

F

)

V

3F

-

5.89

-

Reverse Voltage

(@ -10 μA)

Color Rendering Index (R

a

)

V

-10.0

-

8

80

-

Special CRI (R9)

Thermal Resistance

(junction to chip point)

Beam Angle

-

0

-

K/W

-

2

-

º

-

145

-

Note:

Samsung maintains measurement tolerance of:

forward voltage = ±0.1 V, luminous flux = ±5 %, CRI = ±3, R9 = ±6.5

5

c) Luminous Flux Characteristics

Nominal

CCT (K)

3000

3500

70

4000

5000

5700

6500

2700

Luminous

Flux (Φ

v

)

80

3000

3500

4000

5000

5700

6500

2700

90

3000

3500

(T

s

= 85 ºC)

SA

SB

Max.

Min.

Max.

Min.

SC

Max.

Min.

SD

Max.

Min.

SE

Max.

Min.

SF

Max.

Item

CRI

Min.

Current

150mA

79

87

95

103

111

119

127

Note:

1)

2)

The LM102A is tested in pulsed condition at rated test current (10 ms pulse width)

Samsung maintains measurement tolerance of:

luminous flux = ±5 %

More (Only the first 5 pages are displayed. Please Download Datasheet to view the full content.) >
