DIALIGHT
PART NUMBER
521-9430F
521-9431F
521-9432F
LED COLOR
CHARACTERISTICS
GREEN TINTED NON-DIFFUSED
YELLOW TINTED NON-DIFFUSED
RED TINTED NON-DIFFUSED
LUMINOUS INTENSITY
OPERATING CHARACTERISTICS AT 25 $ AMBIENT
C
LED COLOR
GREEN
YELLOW
RED
GREEN
FORWARD VOLTAGE
YELLOW
RED
GREEN
MIN
32
10
8.7
29
2.1
2.1
2.0
2.8
2.8
2.8
100
100
100
565
585
635
45
45
45
Degree
nm
µA
V
R
REV
ECN NO
REVISIONS
NEW RELEASE
ADDED PART NO.'S 521-9431F AND 521-9432F
DRN CKD APP
TWC
NO
AJF KJL
NO
DATE
6-23-09
TYP
50
MAX
UNITS
TEST CONDITIONS
A
B
MES 12-7-05
50
mcd
I
F
= 10 mA
NOTES:
1. DIE TECHNOLOGY: GaP GREEN
GaAsP/GaP YELLOW AND RED
V
I
F
= 20 mA
2. LEAD SPACING MEASURED NEAR EPOXY PACKAGE.
3. PIN NUMBERS FOR REFERENCE ONLY, DESIGNATION NON-EXISTENT ON PART.
4. DIALIGHT PART NO. 521-9430F, 521-9431F, AND 521-9432F.
PIN 2
PIN 1
CATHODE
REVERSE CURRENT
YELLOW
RED
GREEN
= 5 V
LED SCHEMATIC
PEAK WAVELENGTH
5. THIS ASSEMBLY CONTAINS ELECTROSTATIC DISCHARGE SENSITIVE DEVICES
(ESDS). MAINTAIN ALL PRECAUTIONARY MEASURES DURING ASSEMBLY,
HANDLING, AND STORAGE IN ACCORDANCE WITH IPC-A-610.
YELLOW
RED
GREEN
VIEWING ANGLE
YELLOW
RED
(
.126
3.2)
.175
(4.45)
.040
(1.00)
1.00
(26.4)
MIN.
CATHODE
1
.04
(1.0)
(MIN)
.100 NOM
(2.54)
(SEE NOTE 1)
2
(
.114
2.9)
.059
(1.5)
(MAX)
.018 X .016
(.45 X .40)
RoHS Compliant 521-9430F, 521-9431F, and 521-9432F 3mm LED
Part Numbers with the "F" suffix ending are RoHS Compliant.
Example: 521-9430F
The bag packaging is marked with "RoHS Compliant" label or
equivalent markings.
Parts can be wave soldered, dip soldered or hand soldered using
typical lead-free soldering process with max 260°C temp. for 5 sec.
THIS DRAWING AND THE CONTENTS HEREIN ARE CONFIDENTIAL AND
THE SOLE PROPERTY OF DIALIGHT. REPRODUCTION OF THIS DRAWING
OR CONSTRUCTION OF ANY PARTS WITHIN THIS DRAWING ARE
FORBIDDEN WITHOUT THE WRITTEN CONSENT OF DIALIGHT.
SCALE: DRAWING SCALE
ALL DIM'S IN: INCHES (MM)
TOLERANCES:
UNLESS OTHERWISE SPECIFIED
.012
.22
#
(5.59
#
0.3)
ABSOLUTE MAXIMUM RATING AT 25°C AMBIENT
POWER DISSIPATION
CONTINUOUS FORWARD CURRENT
DERATE LINEARLY FROM 50°C
PEAK FORWARD CURRENT (1/10 DUTY CYCLE, 0.1 ms PULSE WIDTH)
LEAD SOLDERING TEMPERATURE, 5 SEC., 1/16" FROM BODY
OPERATING TEMPERATURE
STORAGE TEMPERATURE
UNITS
mW
mA
mA/°C
mA
°C
°C
°C
GREEN
100
30
0.4
120
YELLOW
60
20
0.25
80
260
-55 TO +100
-55 TO +100
RED
100
30
0.4
120
DRAWING NUMBER
REV
ATTENTION:
OBSERVE PRECAUTIONS FOR
HANDLING ELECTROSTATIC
SENSITIVE DEVICES
C-17334
TITLE
B
FRACTIONS: #
1/64
DECIMALS (.XX): #
.01
DECIMALS (.XXX): #
.005
DECIMALS (.XXXX): #
.0005
ANGLES: # $
1
3 mm LED TINTED,
NON-DIFFUSED, RoHS COMPLIANT
MATERIAL
FINISH:
1501 ROUTE 34 SOUTH
FARMINGDALE, NJ 07727
FSCM
83330
SHEET
1
OF
1
FAMILY TABLE:
