9
8
7
6
5
4
DATE
2017.04.10
2017.05.09
3
REV
A
B
2
DESCRIPTION
1
CHANGER
SKUMAR06
SKUMAR06
INITIAL RELEASE.
Document type change from RSD to SD
E
L1
L2
4
1
E
P1
1
P2
4
A
D
B
C
D
SEE DETAIL A
B
A
D
TABLE A
PART NUMBER
C
151320400
151320401
151320402
151320403
151320405
151320406
L1
50
±
5
100
±
8
150
±
10
300
±
10
450
±
15
600
±
15
L2
18REF
44REF
69REF
144REF
219REF
294REF
TITLE
Cable-Assy Picolock 4 Circuit 50MM
Cable-Assy Picolock 4 Circuit 100MM
Cable-Assy Picolock 4 Circuit 150MM
Cable-Assy Picolock 4 Circuit 300MM
Cable-Assy Picolock 4 Circuit 450MM
Cable-Assy Picolock 4 Circuit 600MM
P/N:15132XXXX
MOLEX
Batch WK/YR
MOLEX PN
C
DETAIL A
B
NOTES
1. This product must meet 2011/65/EC ROHS compliance.
2. Cable assembly to be tested 100% for continuity and polarity.
3. Label text must be 2mm max. In height with Arial font.
4. Connector view shown is from mating side.
D
C
B
A
ITEM
2017/05/09
2017/05/09
Blank White label 12.7x25.4 mm
1X24AWG DISC PVC BK 1.10MM UL1061 HOOKUP
1.5 W/B REC TERMINAL AWG#24-28
1.5W/B CONN. REC HOUSING (4P)
DESCRIPTION
1
A/R
B
8
2
L(MM)
Q'TY
EC NO:
116698
DRWN:
SKUMAR06
CHK'D:
APPR:
MNARAYAN01
A
WIRING CHART
P1
P2
COLOR
4
1
2
3
BLACK
3
2
4
1
QUALITY THIS DRAWING CONTAINS INFORMATION THAT IS PROPRIETARY TO MOLEX ELECTRONIC TECHNOLOGIES, LLC AND SHOULD NOT BE USED WITHOUT WRITTEN PERMISSION
DIMENSION UNITS
SCALE
SYMBOLS
GENERAL
=
=
=
=
=
=
=
C
0
0
0
0
0
0
0
0
TOLERANCES
(UNLESS SPECIFIED)
ANGULAR TOL ±
°
MM
DRWN BY
DATE
NTS
4 PLACES
3 PLACES
2 PLACES
1 PLACE
0 PLACES
±
±
±
SKUMAR06
CHK'D BY
DATE
2017/04/25
CABLE-ASSY PICOLOCK 4 CIRCUIT
A
APPR BY
DATE
±
±
PRODUCT CUSTOMER DRAWING
2017/05/02
SERIES
MATERIAL NUMBER
CUSTOMER
MNARAYAN01
DRAWING SIZE
THIRD ANGLE PROJECTION
RELEASE STATUS
FORMAT: master-tb-prod-A3
REVISION: G
DATE: 2015/12/14
P1
RELEASE DATE
09.05.2017
12:07:45
=
B
REV
DRAFT WHERE APPLICABLE
MUST REMAIN
WITHIN DIMENSIONS
15132
DOCUMENT NUMBER
SEE TABLE
GENERAL MARKET
DOC TYPE
DOC PART
SHEET NUMBER
A3
3
151320400
PSD
000
1 OF 1
9
8
7
6
5
4
2
1
