3021060-02M datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > The connector> Connector bracket> 3021060-02M

3021060-02M: DescriptionUSB 2.0 A MALE TO USB 2.0 A MALE; CategoryThe connector Connector bracket; File Size318KB，1 Pages; ManufacturerQualtek Electronics Corporation; Websitehttp://www.qualtekusa.com/; Environmental Compliance

Download Datasheet Parametric View All

3021060-02M Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	3021060-02M	-	-	View	Buy Now

3021060-02M Overview

USB 2.0 A MALE TO USB 2.0 A MALE

3021060-02M Parametric

Parameter Name	Attribute value
Is it Rohs certified?	conform to
Maker	Qualtek Electronics Corporation
Reach Compliance Code	unknown
Is Samacsys	N
Connector bracket type	CABLE ASSEMBLY
Base Number Matches	1

3021060-02M Preview

THESE DRAWINGS ARE THE PROPERTY OF QUALTEK

ELECTRONICS AND NOT TO BE REPRODUCED FOR

OR COMMUNICATED TO A THIRD PARTY WITHOUT

THE EXPRESS WRITTEN PERMISSION OF AN OFFICER

OF QUALTEK ELECTRONICS.

2000 ± 40mm

REV.

REVISION

DESCRIPTION

DATE

APPROVED

CN1

36.7REF

CN2

11.75MIN

NOTES:

1. CABLE: UL2725

28AWGx1PR+24AWGx2C+ AEB(AL) 65%

OUTER JACKET: BLACK, OD: 4.5 ± 0.2mm

2. CONNECTOR: USB 2.0 A TYPE MALE

INSULATOR: WHITE PBT

PIN G/F

NICKEL PLATED SHELL

3. CONNECTOR: USB 2.0 A TYPE MALE

INSULATOR: WHITE PBT

PIN G/F

NICKEL PLATED SHELL

4. PVC MOLDED: COLOR 45P BLACK

5. ELECTRICAL TEST:

<1>.100% OPEN SHORT & MISS WIRE TEST

<2>. INSULATION RESISTANCE: DC300V 10M ohm MIN.

<3>. CONDUCTOR RESISTANCE: 2 ohm MAX.

6. PACKING: 1PC/POLYBAG W/ LABEL

Dim

range

(mm)

0-1

1-6

6-18

18-50

50-120

120-250

250-500

Tolerance

+/-

(mm)

0.15

0.20

0.30

0.50

0.70

0.90

1.20

WCI DIVISION

Part Number:

3021060-02M

Description:

CONTROLLED

Qualtek Electronics Corp.

USB 4P(A)/M - USB 4P(A)/M

UNIT: mm

Drawn / Date

R. Nuti

09-25-17

Checked / Date

09-25-17

Approved / Date

LY / 09-25-17

More (Only the first 5 pages are displayed. Please Download Datasheet to view the full content.) >
