1424353: DescriptionSLEEVE HOUSING SZD15 SGL LOCK LA; CategoryThe connector Connector bracket; File Size56KB，3 Pages; ManufacturerPHOENIX CONTACT; Websitehttps://www.phoenixcontact.com; Environmental Compliance

Download Datasheet Parametric View All

1424353 Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	1424353	-	-	View	Buy Now

1424353 Overview

SLEEVE HOUSING SZD15 SGL LOCK LA

1424353 Parametric

Parameter Name	Attribute value
Is it Rohs certified?	conform to
Maker	PHOENIX CONTACT
Reach Compliance Code	compliant
Connector bracket type	CONNECTOR ACCESSORY

Preview

Download Datasheet

View All

https://www.phoenixcontact.com/pi/products/1424353

Housing - HC-STA-D15-HHFS-1TTP16-ELC-AL - 1424353

Please be informed that the data shown in this PDF Document is generated from our Online Catalog. Please find the complete data in the user's

documentation. Our General Terms of Use for Downloads are valid

(http://phoenixcontact.com/download)

Sleeve housing D15, for single locking latch, material: Die-cast aluminum, salt water resistant, cable outlets:

1, straight, height: 68 mm, cable gland: none, support sleeve: no, 1x Pg16, Standard

Key Commercial Data

Packing unit

GTIN

4055626370897

1 pc

Technical data

Dimensions

Height

Width

Length

68 mm

30 mm

63.5 mm

Ambient conditions

Degree of protection of housing (IP)

Ambient temperature (operation)

IP66

IP67

-40 °C ... 125 °C

General

Note

Size

Housing type

Color

Locking type

No. of cable outlets

Cable outlet

Screw connection

Type of the screw connection

For contact inserts HC-D15, A10

D15

Sleeve housing

gray aluminum

for single locking latch

1

straight

none

1x Pg16

10/21/2018 Page 1 / 3
