Feed-through terminal block - PT 2,5 BK - 3212330
Please be informed that the data shown in this PDF Document is generated from our Online Catalog. Please find the complete data in the user's
documentation. Our General Terms of Use for Downloads are valid
(http://phoenixcontact.com/download)
Feed-through terminal block, Connection method: Push-in connection, Number of positions: 1, Cross section:
0.14 mm² - 4 mm², AWG: 26 - 12, Width: 5.2 mm, Color: black, Mounting type: NS 35/7,5, NS 35/15
Product Features
The Push-in connection terminal blocks are characterized by the system features of the CLIPLINE complete system and by easy and tool-free wiring
of conductors with ferrules or solid conductors
The compact design and front connection enable wiring in a confined space
In addition to the testing facility in the double function shaft, all terminal blocks provide an additional test connection
Packing unit
Minimum order quantity
1 pc
50 pc
6.4 g
85369010
Germany
Key Commercial Data
Weight per Piece (excluding packing)
Custom tariff number
Country of origin
Technical data
General
Number of levels
Number of connections
Nominal cross section
Color
Insulating material
Flammability rating according to UL 94
Area of application
1
2
2.5 mm²
black
PA
V0
Railway industry
Mechanical engineering
12/15/2015 Page 1 / 5
https://www.phoenixcontact.com/us/products/3212330
Feed-through terminal block - PT 2,5 BK - 3212330
Technical data
General
Plant engineering
Process industry
Rated surge voltage
Pollution degree
Overvoltage category
Insulating material group
Connection in acc. with standard
Maximum load current
Nominal current I
N
Nominal voltage U
N
Open side panel
Number of positions
6 kV
3
III
I
IEC 60947-7-1
30 A (with 4 mm² conductor cross section)
24 A (at 2.5 mm²)
800 V
ja
1
Dimensions
Width
End cover width
Length
Height NS 35/7,5
Height NS 35/15
5.2 mm
2.2 mm
48.5 mm
36.5 mm
44 mm
Connection data
Connection method
Connection in acc. with standard
Conductor cross section solid min.
Conductor cross section solid max.
Conductor cross section AWG min.
Conductor cross section AWG max.
Conductor cross section flexible min.
Conductor cross section flexible max.
Min. AWG conductor cross section, flexible
Max. AWG conductor cross section, flexible
Conductor cross section flexible, with ferrule without plastic sleeve min.
Conductor cross section flexible, with ferrule without plastic sleeve max.
Conductor cross section flexible, with ferrule with plastic sleeve min.
Conductor cross section flexible, with ferrule with plastic sleeve max.
Push-in connection
IEC 60947-7-1
0.14 mm²
4 mm²
26
12
0.14 mm²
2.5 mm²
26
14
0.14 mm²
2.5 mm²
0.14 mm²
2.5 mm²
2 conductors with same cross section, stranded, TWIN ferrules with plastic
0.5 mm²
sleeve, max.
Connection in acc. with standard
Conductor cross section solid min.
IEC/EN 60079‑7
0.14 mm²
12/15/2015 Page 2 / 5
https://www.phoenixcontact.com/us/products/3212330
Feed-through terminal block - PT 2,5 BK - 3212330
Technical data
Connection data
Conductor cross section solid max.
Conductor cross section AWG min.
Conductor cross section AWG max.
Conductor cross section flexible min.
Conductor cross section flexible max.
Stripping length
Internal cylindrical gage
4 mm²
26
12
0.14 mm²
2.5 mm²
8 mm ... 10 mm
A3
Standards and Regulations
Connection in acc. with standard
Flammability rating according to UL 94
CSA
IEC 60947-7-1
V0
Classifications
eCl@ss
eCl@ss 4.0
eCl@ss 4.1
eCl@ss 5.0
eCl@ss 5.1
eCl@ss 6.0
eCl@ss 7.0
eCl@ss 8.0
eCl@ss 9.0
27141121
27141121
27141120
27141120
27141120
27141120
27141120
27141120
ETIM
ETIM 3.0
ETIM 4.0
ETIM 5.0
EC000897
EC000897
EC000897
UNSPSC
UNSPSC 6.01
UNSPSC 7.0901
UNSPSC 11
UNSPSC 12.01
UNSPSC 13.2
30211811
39121410
39121410
39121410
39121410
12/15/2015 Page 3 / 5
https://www.phoenixcontact.com/us/products/3212330
Feed-through terminal block - PT 2,5 BK - 3212330
Approvals
Approvals
Approvals
CSA / UL Recognized / cUL Recognized / GL / RS / ABS / VDE Zeichengenehmigung / IECEE CB Scheme / EAC / cULus Recognized
Ex Approvals
ATEX / IECEx / EAC Ex
Approvals submitted
Approval details
CSA
mm²/AWG/kcmil
Nominal current IN
Nominal voltage UN
B
26-12
20 A
600 V
C
26-12
20 A
600 V
UL Recognized
mm²/AWG/kcmil
Nominal current IN
Nominal voltage UN
B
26-12
20 A
600 V
C
26-12
20 A
600 V
cUL Recognized
mm²/AWG/kcmil
Nominal current IN
Nominal voltage UN
B
26-12
20 A
600 V
C
26-12
20 A
600 V
12/15/2015 Page 4 / 5
https://www.phoenixcontact.com/us/products/3212330
Feed-through terminal block - PT 2,5 BK - 3212330
Approvals
GL
RS
ABS
VDE Zeichengenehmigung
mm²/AWG/kcmil
Nominal current IN
Nominal voltage UN
0.2-2.5
24 A
800 V
IECEE CB Scheme
mm²/AWG/kcmil
Nominal voltage UN
0.2-2.5
800 V
EAC
cULus Recognized
Drawings
Circuit diagram
Phoenix Contact 2015 © - all rights reserved
http://www.phoenixcontact.com
12/15/2015 Page 5 / 5
