PANEL, TYPICAL
MATCHING FLATS
DATA-CON-X PANEL CONNECTOR,
TYPICAL
(PURCHASED SEPARATELY)
0.63
16.0
SEE NOTE 2
A
SEAL CAP
WASHER
(1.405 x 1.195 x 0.01)
[35.7 x 30.4 x 0.25]
GASKET
(SUPPLIED WITH CONNECTOR)
CUSTOMER DRAWING
FIGURE D
FIGURE A
HEX NUT
(SUPPLIED WITH CONNECTOR)
MATCHING KEY AND KEYWAY
CAP MUST BE PRESSED
FLAT AGAINST PANEL
CONNECTOR TO SEAL.
FIGURE B
FIGURE C
3.52
89.3
0.49
12.5
0.05
1.3
NOTES:
1. D24295-WA CONTAINS ONE SEAL CAP AND ONE FLAT WASHER.
2. THE DIMENSION DOES NOT INCLUDE GASKET COMPRESSION.
3. INSTALL SEAL CAP ON THE CONNECTOR AS SHOWN IN FIGURE A.
HEX NUT RECOMMENDED TORQUE: 8-10 lb-in [0.90 - 1.13 N-m].
4. MATERIAL: SEAL CAP - THERMOPLASTIC ELASTOMER, BLACK
WASHER - MYLAR, WHITE
5. UNLESS OTHERWISE SPECIFIED TOLERANCES:
TWO PLACE DECIMALS 0.02 [ 0.5]
1.14
28.8
0A
JGK
8/27/15
DATE
REV. INIT.
DESCRIPTION
ORIG. DRAWN BY:
ALL INFORMATION ILLUSTRATED IS
THE PROPERTY OF "CONXALL
CORPORATION." UNAUTHORIZED
DUPLICATION OR DISTRIBUTION OF
THIS DOCUMENT IS PROHIBITED.
ALL UNITS ARE IN FEET,
INCHES, FRACTION OF INCHES
AND DECIMALS.
UNLESS OTHERWISE SPECIFIED
TOLERANCES:
3 PLACE DECIMALS ±.005
ANGLES ±1°
FRACTIONS ±1/16
= CRITICAL CHARACTERISTIC
FLAG PER SPEC. XXXX
DETAIL A
SCALE 2 : 1
D24295-WA
2.12 REF
53.8
1.42
36.1
0.20
5.1
1.38
34.9
PART
NUMBER:
CUSTOMER DRAWING
DRAWING CREATED FOR DATA-CON-X IP CAP.
JGK
DATE:
1.16
29.5
DATA-CON-X LOGO,
STANDARD
DIMENSIONS SHOWN FOR REFERENCE ONLY
DIMENSIONS IN BRACKET [ ] ARE METRIC.
8/27/15
601 E. WILDWOOD VILLA PARK, IL 60181
CHECKED BY:
APPROVED BY:
TITLE:
RoHS COMPLIANT
SCALE
1:1
SIZE
B
1 OF 1
DIRECTORY:
SHEET
CUSTOMER:
DATA-CON-X SERIES
IP RATED
STANDARD PRODUCT
PANEL SEAL CAP
FILE:
SAME AS P/N
SLW
PART
NUMBER:
D24295-WA
0A
REV
