• 1N4614-1THRU 1N4627-1 AVAILABLE IN
JAN, JANTX, JANTXV AND JANS
PER MIL-PRF-19500/435
• LOW CURRENT OPERATION AT 250
µ
A
• LOW REVERSE LEAKAGE AND LOW NOISE CHARACTERISTICS
• DOUBLE PLUG CONSTRUCTION
• METALLURGICALLY BONDED
1N4614 thru 1N4627
and
1N4614-1 thru 1N4627-1
MAXIMUM RATINGS
Operating Temperature: -65°C to +175°C
DC Power Dissipation: 500mW @ +50°C
Power Derating: 4 mW / °C above +50°C
Forward Voltage @ 200 mA: 1.1 Volts maximum
* ELECTRICAL CHARACTERISTICS
@ 25°C, unless otherwise specified.
JEDEC
TYPE
NUMBER
NOMINAL
ZENER
VOLTAGE
V @I
Z
ZT
(Note 1)
VOLTS
ZENER
TEST
CURRENT
I
ZT
MAXIMUM
ZENER
IMPEDANCE
Z
@I
ZT
ZT
(Note 2)
MAXIMUM REVERSE
LEAKAGE CURRENT
1 @V
R
R
MAXIMUM
DC ZENER
CURRENT
lZM
MAXIMUM
NOISE
DENSITY
ND
µ
A
250
250
250
250
250
250
250
250
250
250
250
250
250
250
OHMS
1200
1250
1300
1400
1500
1600
1650
1700
1650
1600
1550
1500
1400
1200
µ
A
7.5
5.0
4.0
2.0
1.0
0.8
7.5
7.5
5.0
4.0
10.0
10.0
10.0
10.0
VOLTS
1
1
1
1
1
1
1.5
2
2
2
3
3
4
5
mA
120
110
100
95
90
87
85
83
80
77
75
70
65
61
µ
V/
1
1
1
1
1
1
1
1
1
1
1
2
4
5
Hz
1N4614
1N4615
1N4616
1N4617
1N4618
1N4619
1N4620
1N4621
1N4622
1N4623
1N4624
1N4625
1N4626
1N4627
1.8
2.0
2.2
2.4
2.7
3.0
3.3
3.6
3.9
4.3
4.7
5.1
5.6
6.2
FIGURE 1
DESIGN DATA
CASE:
Hermetically sealed glass
case. DO – 35 outline.
LEAD MATERIAL:
Copper clad steel.
LEAD FINISH:
Tin / Lead
THERMAL RESISTANCE: (R
OJEC):
250 ˚C/W maximum at L = .375 inch
THERMAL IMPEDANCE: (Z
OJX): 35
˚C/W maximum
POLARITY:
Diode to be operated with
the banded (cathode) end positive.
MOUNTING POSITION:
ANY.
* JEDEC Registered Data.
NOTE 1
The JEDEC type numbers shown above have a Zener voltage tolerance of + 5% of
the nominal Zener voltage. Vz is measured with the device junction in thermal equilib-
rium at an ambient themperature of 25°C + 3°C. A “C” suffix denotes a + 2%
tolerance and a “D” suffix denotes a + 1% tolerance.
Zener impedance is derived by superimposing on l ZT A 60Hz rms a.c. current equal
to 10% of l ZT (25
µ
A a.c.)
NOTE 2
22 COREY STREET, MELROSE, MASSACHUSETTS 02176
PHONE (781) 665-1071
FAX (781) 665-7379
WEBSITE: http://www.cdi-diodes.com
E-mail: mail@cdi-diodes.com
thru
1N4627
INCLUDING -1 VERSIONS
400
0JL, Junction to Lead
Thermal Resistance (°C/W)
1N4614
300
200
100
0
0.2
0.4
0.6
0.8
1.0
L, lead Length to Heat Sink (iNCHES)
FIGURE 2
TYPICAL THERMAL RESISTANCE
1000
500
400
300
200
ZENER IMPEDANCE Z
ZT
(OHMS)
100
50
40
30
20
10
5
4
3
2
1
.1
.2
.5
1
2
5
10
20
50
100
OPERATING CURRENT I
ZT
(mA)
3.3 VOLT
5.1 VOLT
6.2 VOLT
FIGURE 3
ZENER IMPEDANCE VS. OPERATING CURRENT
