Cooper Bussmann
Limiter
Very Fast-Acting
Dimensional Data
0.88"
(±0.005)
(22.2mm)
ANN
Time-Current Characteristic Curves–Average Melt
80
100
125
150
200
250
300
400
500
600
800
AMPERE
RATING
35
100
0.34"
(8.7mm)
2.44"
(±0.015)
(61.0mm)
3.19"
(±0.015)
(81.0mm)
10
0.88"
(22.2mm)
0.34"
(±0.005)
(8.7mm)
TIME IN SECONDS
1
Catalog Symbol:
ANN
Very Fast-Acting
Ampere Rating:
10 to 800A
Voltage Rating:
125Vac (or less)
80Vdc (or less)
Interrupting Rating:
2,500A ac,
2,700A dc
Agency Information:
UL Recognized, 35-400A, 500A dc
only, Guide JFHR2, File E56412
Electrical Ratings (Catalog Symbol and Amperes)
125Vac, IR 2500A @ 125V
ANN-10
ANN-35
ANN-40
ANN-50
ANN-60
ANN-80
ANN-90
ANN-100
ANN-125
ANN-150
ANN-175
ANN-200
ANN-225
ANN-250
ANN-275
ANN-300
ANN-325
ANN-350
ANN-400
ANN-500
ANN-600
ANN-700
ANN-800
—
.1
.01
10
100
1,000
10,000
Form No. ANN
Page 1 of 1
Data Sheet: 2023
Fuse Block No. 4164
General Information:
• Very fast-acting (high speed of responses to short-circuit
currents).
• An open link element is visible through a mica window.
• Stud mounts in Buss fuseblock 4164.
• CSA component acceptance, 35-400A, 500A dc only,
Class 1422-30, file 53787.
The only controlled copy of this Data Sheet is the electronic read-only version located on the Cooper Bussmann Network Drive. All other copies of this document are by definition uncontrolled. This bulletin
is intended to clearly present comprehensive product data and provide technical information that will help the end user with design applications. Cooper Bussmann reserves the right, without notice, to
change design or construction of any products and to discontinue or limit distribution of any products. Cooper Bussmann also reserves the right to change or update, without notice, any technical infor-
mation contained in this bulletin. Once a product has been selected, it should be tested by the user in all possible applications.
8-25-05
N03055
50
60
CURRENT IN AMPERES
