BZG05B-M-Series
www.vishay.com
Vishay Semiconductors
Zener Diodes
FEATURES
• High reliability
• Voltage range includes 37 breakdown
voltages from 3.3 V to 100 V with ± 2 % for
BZG05B-M-series
• Fits onto 5 mm SMD footpads
SMA
(DO-214AC)
• Wave and reflow solderable
• AEC-Q101 qualified available
• Base P/N-M3 - halogen-free, RoHS-compliant, and
commercial grade
UNIT
V
mA
V
V
W
°C
PRIMARY CHARACTERISTICS
PARAMETER
V
Z
range nom.
Test current I
ZT
V
BR
V
WM
P
PPM
T
J
max.
V
Z
specification
Circuit configuration
Polarity
VALUE
3.3 to 100
2.7 to 80
5.49 to 98
4.7 to 90
40
150
Pulse current
Single
Uni-directional
• Base P/NHM3 - halogen-free, RoHS-compliant, and
AEC-Q101 qualified
• Material categorization: for definitions of compliance
please see
www.vishay.com/doc?99912
APPLICATIONS
• Voltage stabilization
ORDERING INFORMATION
DEVICE NAME
BZG05B-M-series
BZG05B-M-series
BZG05B-M-series
BZG05B-M-series
ORDERING CODE
BZG05Bxxx-M3-08
BZG05Bxxx-M3-18
BZG05Bxxx-HM3-08
BZG05Bxxx-HM3-18
TAPED UNITS PER REEL
1500 per 7" reel
6000 per 13" reel
1500 per 7" reel
6000 per 13" reel
MINIMUM ORDER QUANTITY
6000/box
6000/box
6000/box
6000/box
PACKAGE
PACKAGE NAME
SMA (DO-214AC)
WEIGHT
73 mg
MOLDING COMPOUND
FLAMMABILITY RATING
UL 94 V-0
MOISTURE SENSITIVITY
LEVEL
MSL level 1
(according J-STD-020)
SOLDERING CONDITIONS
260 °C/10 s at terminals
ABSOLUTE MAXIMUM RATINGS
(T
amb
= 25 °C, unless otherwise specified)
PARAMETER
Power dissipation
Non repetitive peak surge power dissipation
Junction to lead
Mounted on epoxy-glass hard tissue, fig. 1a
Junction to ambient air
Mounted on epoxy-glass hard tissue, fig. 1b
Mounted on Al-oxide-ceramic (Al
2
O
3
), fig. 1b
Junction temperature
Storage temperature range
Forward voltage (max.)
I
F
= 0.2 A
TEST CONDITION
R
thJA
< 30 K/W, T
amb
= 60 °C
R
thJA
< 100 K/W, T
amb
= 25 °C
t
p
= 100 μs sq. pulse, T
j
= 25 °C prior to surge
SYMBOL
P
tot
P
tot
P
ZSM
R
thJL
R
thJA
R
thJA
R
thJA
T
j
T
stg
V
F
VALUE
3000
1250
60
30
150
125
100
150
-65 to +150
1.2
UNIT
mW
mW
W
K/W
K/W
K/W
K/W
°C
°C
V
Rev. 1.0, 13-Oct-17
Document Number: 86136
1
For technical questions within your region:
DiodesAmericas@vishay.com, DiodesAsia@vishay.com, DiodesEurope@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
BZG05B-M-Series
www.vishay.com
Vishay Semiconductors
REVERSE
LEAKAGE
CURRENT
I
R
at V
R
μA
MAX.
80
60
60
50
45
45
45
35
35
35
25
25
25
20
20
20
15
15
15
10
10
10
8
8
8
8
6
6
4
4
4
4
4
4
2.7
2.7
2.7
1
1
1
1
1
1
1
1
1
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
40
20
10
3
3
1
1
1
1
1
1
1
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
1
1
1
1
1
1.5
2
3
4
4.5
6.2
6.8
7
8.2
9.1
10
11
12
13
15
16
18
20
22
24
27
30
33
36
39
43
47
51
56
62
68
75
V
MAX.
20
20
15
13
13
10
7
4
3.5
3
5
5
7
8
9
10
15
15
20
24
25
25
30
30
35
40
50
50
90
115
120
125
130
135
200
250
350
ELECTRICAL CHARACTERISTICS
(T
amb
= 25 °C, unless otherwise specified)
ZENER VOLTAGE RANGE
PART NUMBER
V
Z
at I
ZT1
V
MIN.
BZG05B3V3-M
BZG05B3V6-M
BZG05B3V9-M
BZG05B4V3-M
BZG05B4V7-M
BZG05B5V1-M
BZG05B5V6-M
BZG05B6V2-M
BZG05B6V8-M
BZG05B7V5-M
BZG05B8V2-M
BZG05B9V1-M
BZG05B10-M
BZG05B11-M
BZG05B12-M
BZG05B13-M
BZG05B15-M
BZG05B16-M
BZG05B18-M
BZG05B20-M
BZG05B22-M
BZG05B24-M
BZG05B27-M
BZG05B30-M
BZG05B33-M
BZG05B36-M
BZG05B39-M
BZG05B43-M
BZG05B47-M
BZG05B51-M
BZG05B56-M
BZG05B62-M
BZG05B68-M
BZG05B75-M
BZG05B82-M
BZG05B91-M
BZG05B100-M
3.23
3.53
3.82
4.21
4.61
5.00
5.49
6.08
6.66
7.35
8.04
8.92
9.80
10.78
11.76
12.74
14.70
15.68
17.64
19.60
21.56
23.52
26.46
29.40
32.34
35.28
38.22
42.14
46.06
49.98
54.88
60.76
66.64
73.50
80.36
89.18
98.00
NOM.
3.3
3.6
3.9
4.3
4.7
5.1
5.6
6.2
6.8
7.5
8.2
9.1
10
11
12
13
15
16
18
20
22
24
27
30
33
36
39
43
47
51
56
62
68
75
82
91
100
MAX.
3.37
3.67
3.98
4.39
4.79
5.20
5.71
6.32
6.94
7.65
8.36
9.28
10.20
11.22
12.24
13.26
15.30
16.32
18.36
20.40
22.44
24.48
27.54
30.60
33.66
36.72
39.78
43.86
47.94
52.02
57.12
63.24
69.36
76.50
83.64
92.82
102.00
TEST CURRENT
I
ZT1
mA
I
ZT2
mA
DYNAMIC
RESISTANCE
Z
Z
at I
ZT1
Z
Z
K at I
ZT2
MAX.
400
500
500
500
600
500
400
300
300
200
200
200
200
300
350
400
500
500
500
600
600
600
750
1000
1000
1000
1000
1000
1500
1500
2000
2000
2000
2000
3000
3000
3000
MIN.
-0.08
-0.08
-0.07
-0.07
-0.03
-0.01
0
0.01
0.015
0.02
0.03
0.035
0.04
0.045
0.045
0.05
0.055
0.055
0.06
0.06
0.06
0.06
0.06
0.06
0.06
0.07
0.07
0.07
0.07
0.08
0.08
0.08
0.08
0.08
0.08
0.08
0.08
TEMPERATURE
COEFFICIENT
TC
VZ
at I
ZT1
%/K
MAX.
-0.05
-0.05
-0.02
-0.01
0.04
0.04
0.045
0.055
0.06
0.065
0.07
0.075
0.08
0.08
0.085
0.085
0.09
0.09
0.09
0.09
0.095
0.095
0.095
0.095
0.095
0.11
0.11
0.11
0.11
0.12
0.12
0.12
0.12
0.12
0.12
0.12
0.12
Rev. 1.0, 13-Oct-17
Document Number: 86136
2
For technical questions within your region:
DiodesAmericas@vishay.com, DiodesAsia@vishay.com, DiodesEurope@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
BZG05B-M-Series
www.vishay.com
BASIC CHARACTERISTICS
(T
amb
= 25 °C, unless otherwise specified)
3.0
a)
b)
Vishay Semiconductors
2
1.5
10
2
I
F
- Forward Current (A)
5
2.5
2.0
1.5
1.0
0.5
0.0
25
94 9313
1
25
0.0
0.5
1.0
1.5
2.0
22294
V
F
- Forward
Voltage
(V)
Fig. 1 -
Boards for R
thJA
Definition (Copper Overlay 35 μ)
Fig. 3 -
Forward Current vs. Forward Voltage
P
ZSM
-
Non-Repetitive
Surge Power
Dissipation (W)
3.5
1000
Single
half
square
wave pulse
P
tot
- Total Power Dissipation (W)
3
2.5
2
1.5
1
0.5
0
R
thJA
= 30K/W
Databook Limit
100
R
thJA
= 100K/W
10
T
amb
= 25 °C
1
0.01
0.1
1
10
0
25
50
75
100
125
150
22295
22822
T
amb
- Ambient Temperature (°C)
t
p
- Pulse Length (ms)
Fig. 2 -
Typ. Total Power Dissipation vs. Ambient Temperature
Fig. 4 -
Non Repetitive Surge Power Dissipation vs. Pulse Length
Z
thp
- Thermal Resistance for Pulse Cond. (K/W)
1000
100
t
p
/T = 0.5
t
p
/T = 0.2
t
p
/T = 0.1
t
p
/T = 0.05
t
p
/T = 0.02
t
p
/T = 0.01
10
1
10
-5
94 9583
10
-4
10
-3
10
-2
10
-1
10
0
10
1
10
2
t
p
- Pulse Length (s)
Fig. 5 -
Thermal Response
Rev. 1.0, 13-Oct-17
Document Number: 86136
3
For technical questions within your region:
DiodesAmericas@vishay.com, DiodesAsia@vishay.com, DiodesEurope@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
BZG05B-M-Series
www.vishay.com
PACKAGE DIMENSIONS
in millimeters (inches):
SMA (DO-214AC)
Vishay Semiconductors
5.5 (0.217)
4.9 (0.193)
4.5 (0.176)
4.2 (0.164)
2.3 (0.090)
2.0 (0.078)
0.2 (0.008)
3.3 (0.130)
2.5 (0.098)
1.7 (0.066)
1.4 (0.055)
2.8 (0.109)
2.3 (0.090)
Foot print recommendation:
2.3 (0.091) max.
0.1 (0.004)
Document no.:S8-V-3848.01-003 (4)
Created - Date: 18.February.1997
Rev. 8 - Date: 10.November 2006
19628
2.2 (0.087) max.
6.7 (0.264) ref.
Rev. 1.0, 13-Oct-17
Document Number: 86136
4
For technical questions within your region:
DiodesAmericas@vishay.com, DiodesAsia@vishay.com, DiodesEurope@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
2.21 (0.087)
Legal Disclaimer Notice
www.vishay.com
Vishay
Disclaimer
ALL PRODUCT, PRODUCT SPECIFICATIONS AND DATA ARE SUBJECT TO CHANGE WITHOUT NOTICE TO IMPROVE
RELIABILITY, FUNCTION OR DESIGN OR OTHERWISE.
Vishay Intertechnology, Inc., its affiliates, agents, and employees, and all persons acting on its or their behalf (collectively,
“Vishay”), disclaim any and all liability for any errors, inaccuracies or incompleteness contained in any datasheet or in any other
disclosure relating to any product.
Vishay makes no warranty, representation or guarantee regarding the suitability of the products for any particular purpose or
the continuing production of any product. To the maximum extent permitted by applicable law, Vishay disclaims (i) any and all
liability arising out of the application or use of any product, (ii) any and all liability, including without limitation special,
consequential or incidental damages, and (iii) any and all implied warranties, including warranties of fitness for particular
purpose, non-infringement and merchantability.
Statements regarding the suitability of products for certain types of applications are based on Vishay’s knowledge of
typical requirements that are often placed on Vishay products in generic applications. Such statements are not binding
statements about the suitability of products for a particular application. It is the customer’s responsibility to validate that a
particular product with the properties described in the product specification is suitable for use in a particular application.
Parameters provided in datasheets and / or specifications may vary in different applications and performance may vary over
time. All operating parameters, including typical parameters, must be validated for each customer application by the customer’s
technical experts. Product specifications do not expand or otherwise modify Vishay’s terms and conditions of purchase,
including but not limited to the warranty expressed therein.
Except as expressly indicated in writing, Vishay products are not designed for use in medical, life-saving, or life-sustaining
applications or for any other application in which the failure of the Vishay product could result in personal injury or death.
Customers using or selling Vishay products not expressly indicated for use in such applications do so at their own risk.
Please contact authorized Vishay personnel to obtain written terms and conditions regarding products designed for
such applications.
No license, express or implied, by estoppel or otherwise, to any intellectual property rights is granted by this document
or by any conduct of Vishay. Product names and markings noted herein may be trademarks of their respective owners.
© 2017 VISHAY INTERTECHNOLOGY, INC. ALL RIGHTS RESERVED
Revision: 08-Feb-17
1
Document Number: 91000
京公网安备 11010802033920号
EEWORLD
