BCM8155
®
Multirate Low-Power 10G RZ/NRZ/Duo-binary Transceiver with 10G Clock
FEATURES
•
Fully integrated multirate CDR, DEMUX, MUX, CMU
•
300-pin Multisource Agreement (MSA) compatible
•
Compliant with ITU GR-253, XFP, and SFP+ specifications
•
16-bit LVDS interface compliant with Optical
Internetworking Forum (OIF) SFI-4
•
Programmable RZ/NRZ/Duo-binary modes
•
Adjustable duty cycle in RZ mode
•
RX equalization for ISI compensation
•
Limiting amplifier
•
RX phase adjustment
•
Adaptable RX decision threshold adjustment
•
10G serial transmit clock output with adjustable phase
•
10G serial TX preemphasis
•
PRBS generator/checker for built-in self-test (BIST)
•
Line and system loopback modes
•
Receiver and transmitter serial data polarity inversion
•
LVDS polarity inversion and bit order reversal
•
Analog loss-of-signal output (ALOSB) and loss-of-signal input
(LOSIB)
•
CMU and CDR lock detect
•
FIFO overflow alarm
•
Reference clock: 1/16 or 1/64 of the line data rate
•
Selectable RX clock and RX data squelch
•
Selectable timing modes/cleanup are field-configurable
•
Internal phase detector and charge pump for cleanup phase-
locked loop
(PLL)
(external VCXO required)
•
Broadcom Serial Control (BSC) interface compatible with
Philips
®
I
2
C standard
•
Optional SPI interface
•
Core voltage, 1V
•
Low power: 600 mW
SUMMARY OF BENEFITS
•
Enhanced capability for long haul transmission with the
ability to enable RZ modulation on the transmitter
•
Compliant with OIF, Telcordia
®
, ITU-T, XFI specification,
and IEEE 802.3ae standards
•
Input sensitivity 10 mV peak-to-peak
•
Rates supported from 8.5 Gbps to 11.352 Gbps
•
Fault isolation with loopbacks, pattern generator, and
checker
•
Reduces design cycle and time-to-market
•
High-level of integration allows for higher port density
solutions.
•
Lowest power SFI-4 to 10G serial transceiver
•
Standard CMOS 65 nm fabrication process
APPLICATIONS
•
OC-192/STM-64/10-GbE/FEC transmission equipment
•
SONET/SDH/10-GbE/10FC/FEC for RZ, NRZ or duo-
binary optical modules
•
ADD/DROP multiplexers
•
Digital cross-connects
•
ATM switch backbone
•
SONET/SDH/10-GbE/10FC/FEC for NRZ, RZ, or duo-
binary test equipment
•
Terabit and edge routers
OVERVIEW
System Interface
TXREFCLKP/N
RXREFCLKP/N
VCXOP/N
TXPCLKP/N
TXMCLKP/N
RXMCLKP/N
TXPICLKP/N
TXDIN[15:0]P/N
RXPOCLKP/N
RXDOUT[15:0]P/N
TXVCP/N
RXVCP/N
RDINCM
OFFSETP/N
PHDOUT
RB_CAL
RB_CAL_VSS
TXFIFOERRB
TXLOCKERRB
PHDLOCKERRB
ALOSB
RXFIFOERRB
RXLOCKERRB
+1.0V Differential
Externally AC-Coupled
Internally Biased
+1.0V LVDS
Line Interface
Reference
Clock Inputs
Reference
Clock Outputs
Transmitter
Parallel Inputs
Receiver
Parallel Outputs
Filter and
Bias Inputs
Clean-up PLL
Charge Pump Output
Resistor Calibration
Reference
+1.8V/2.3V LVDS
+1.0V LVDS
+1.0V Differential CML
Externally AC-Coupled
TSDP/N
TSCLKP/N
Transmit
Serial
Outputs
+1.0V Analog
+3.3V Analog
Connect 4.75-k resistor
between these two pins
+1.0V Differential CML
Externally AC-Coupled
Internally Biased
Receive
Serial
Input
RDINP/N
Status
Outputs
+3.3V CMOS
Control
Inputs
RESETB
LOSIB
TXREFSEL
SPI_SEL
SDA
SCL
ADR[2:0]
+3.3V CMOS
+1.0V Differential CML
Externally AC-Coupled
Internally Biased
AUXP/N
Auxillary
Input
Bypass
BSC
Open Drain CMOS
+1.0V
+1.8V
+3.3V
VSS
BCM8155 Interface Block Diagram
The BCM8155 is a fully integrated MSA-compatible multirate SONET/
SDH/10-GbE/Fibre-Channel/FEC transceiver operating at 8.5 Gbps,
9.1 Gbps, 9.953 Gbps, 10.3125 Gbps, 10.519 Gbps, 10.664 Gbps, 10.709
Gbps, 11.095 Gbps, 11.318 Gbps, or 11.352 Gbps. It supports RZ, NRZ,
and duo-binary modulation formats.
On-chip clock synthesis is performed by a high-frequency, low-jitter
PLL, allowing the use of a low-frequency reference clock selectable to
the line rate divided by 16 or 64. The 10G TX clock phase adjusts for
clocked driver applications.
An on-chip phase detector and charge pump, plus external VCXO,
implements a cleanup PLL. This can attenuate jitter on the CDR-
recovered clock for loop timing applications, or provide a low-jitter
reference from a noisy system clock. SONET timing modes can employ
the new BCM8155 architecture, making timing mode and cleanup
functions user-selectable in the field rather than during manufacturing.
This simplifies engineering and manufacturing requirements.
The low-jitter LVDS interface guarantees compliance with the bit error
rate requirements of the Telcordia (formerly Bellcore), ANSI, and ITU-
T standards.
New features added to the BCM8155 include:
•
Selectable RZ, NRZ and DB modulation
•
Rates from 8.5 Gbps to 11.352 Gbps
•
PRBS generator/checker for BIST
•
Adaptive decision threshold adjustment
•
Adjustable 10G TX clock phase
•
10G RX equalization for ISI compensation
•
10G TX preemphasis
•
Differential duo-binary precoder
•
BSC interface (compatible with Philips I
2
C standard) or optional SPI
interface
The BCM8155 is offered in two different packages:
1. 12 mm x 12 mm, 196-pin BGA (0.8 mm ball pitch)
2. 15 mm x 15 mm, 196-pin BGA (1 mm ball pitch)
