Ground modular terminal block - UT 10-PE/S - 3215054
Please be informed that the data shown in this PDF Document is generated from our Online Catalog. Please find the complete data in the user's
documentation. Our General Terms of Use for Downloads are valid
(http://phoenixcontact.com/download)
Ground modular terminal block, with screwfix, connection method: Screw connection, number of connections:
2, cross section:0.5 mm² - 16 mm², AWG: 20 - 6, width: 10.2 mm, height: 46.9 mm, color: green-yellow,
mounting type: NS 35/7,5, NS 35/15
The figure shows a similar product
Key Commercial Data
Packing unit
Minimum order quantity
GTIN
GTIN
4046356633703
50 pc
50 pc
Technical data
General
Number of levels
Number of connections
Nominal cross section
Color
Insulating material
Flammability rating according to UL 94
Rated surge voltage
Degree of pollution
Overvoltage category
Insulating material group
Open side panel
Oscillation, broadband noise test result
Test specification, oscillation, broadband noise
Test spectrum
Test frequency
ASD level
1
2
10 mm²
green-yellow
PA
V0
8 kV
3
III
I
Yes
Test passed
DIN EN 50155 (VDE 0115-200):2008-03
Service life test category 2, bogie-mounted
f
1
= 5 Hz to f
2
= 250 Hz
6.12 (m/s ) /Hz
10/19/2018 Page 1 / 5
2 2
https://www.phoenixcontact.com/pi/products/3215054
Ground modular terminal block - UT 10-PE/S - 3215054
Technical data
General
Acceleration
Test duration per axis
Test directions
Shock test result
Test specification, shock test
Shock form
Acceleration
Shock duration
Number of shocks per direction
Test directions
Relative insulation material temperature index (Elec., UL 746 B)
Temperature index of insulation material (DIN EN 60216-1 (VDE
0304-21))
Static insulating material application in cold
Behavior in fire for rail vehicles (DIN 5510-2)
Flame test method (DIN EN 60695-11-10)
Oxygen index (DIN EN ISO 4589-2)
NF F16-101, NF F10-102 Class I
NF F16-101, NF F10-102 Class F
Surface flammability NFPA 130 (ASTM E 162)
Specific optical density of smoke NFPA 130 (ASTM E 662)
Smoke gas toxicity NFPA 130 (SMP 800C)
Calorimetric heat release NFPA 130 (ASTM E 1354)
Fire protection for rail vehicles (DIN EN 45545-2) R22
Fire protection for rail vehicles (DIN EN 45545-2) R23
Fire protection for rail vehicles (DIN EN 45545-2) R24
Fire protection for rail vehicles (DIN EN 45545-2) R26
3.12 g
5h
X-, Y- and Z-axis
Test passed
DIN EN 50155 (VDE 0115-200):2008-03
Half-sine
30g
18 ms
3
X-, Y- and Z-axis (pos. and neg.)
130 °C
130 °C
-60 °C
Test passed
V0
>32 %
2
2
passed
passed
passed
28 MJ/kg
HL 1 - HL 3
HL 1 - HL 3
HL 1 - HL 3
HL 1 - HL 3
Dimensions
Width
End cover width
Length
Height
Height NS 35/7,5
Height NS 35/15
10.2 mm
2.2 mm
47.7 mm
46.9 mm
47.5 mm
55 mm
Connection data
Note
Connection method
Connection in acc. with standard
Note
Please observe the current carrying capacity of the DIN rails.
Screw connection
IEC 60947-7-2
Note: Product releases, connection cross sections and notes on
connecting aluminum cables can be found in the download area.
10/19/2018 Page 2 / 5
https://www.phoenixcontact.com/pi/products/3215054
Ground modular terminal block - UT 10-PE/S - 3215054
Technical data
Connection data
Conductor cross section solid min.
Conductor cross section solid max.
Conductor cross section AWG min.
Conductor cross section AWG max.
Conductor cross section flexible min.
Conductor cross section flexible max.
Min. AWG conductor cross section, flexible
Max. AWG conductor cross section, flexible
Conductor cross section flexible, with ferrule without plastic sleeve min.
Conductor cross section flexible, with ferrule with plastic sleeve min.
Conductor cross section flexible, with ferrule with plastic sleeve max.
Connection in acc. with standard
Conductor cross section solid min.
Conductor cross section solid max.
Conductor cross section AWG min.
Conductor cross section AWG max.
Conductor cross section flexible min.
Conductor cross section flexible max.
Stripping length
Internal cylindrical gage
Screw thread
Tightening torque, min
Tightening torque max
0.5 mm²
16 mm²
20
6
0.5 mm²
16 mm²
20
6
0.5 mm²
0.5 mm²
10 mm²
IEC/EN 60079-7
0.5 mm²
16 mm²
20
6
0.5 mm²
10 mm²
10 mm
A6
M4
1.5 Nm
1.8 Nm
Conductor cross section flexible, with ferrule without plastic sleeve max. 10 mm²
Standards and Regulations
Connection in acc. with standard
Flammability rating according to UL 94
Fire protection for rail vehicles (DIN EN 45545-2) R22
Fire protection for rail vehicles (DIN EN 45545-2) R23
Fire protection for rail vehicles (DIN EN 45545-2) R24
Fire protection for rail vehicles (DIN EN 45545-2) R26
IEC 60947-7-2
V0
HL 1 - HL 3
HL 1 - HL 3
HL 1 - HL 3
HL 1 - HL 3
Environmental Product Compliance
REACh SVHC
China RoHS
Lead 7439-92-1
Environmentally Friendly Use Period = 50
For details about hazardous substances go to tab “Downloads”,
Category “Manufacturer's declaration”
Drawings
10/19/2018 Page 3 / 5
https://www.phoenixcontact.com/pi/products/3215054
Ground modular terminal block - UT 10-PE/S - 3215054
Circuit diagram
Approvals
Approvals
Approvals
EAC / CSA / UL Recognized / cUL Recognized / EAC / cULus Recognized
Ex Approvals
Approval details
EAC
B
20-6
EAC-Zulassung
CSA
mm²/AWG/kcmil
http://www.csagroup.org/services-industries/product-listing/
C
20-6
13631
UL Recognized
mm²/AWG/kcmil
D
20-6
http://database.ul.com/cgi-bin/XYV/template/LISEXT/1FRAME/index.htm
B
20-6
C
20-6
FILE E 60425
cUL Recognized
mm²/AWG/kcmil
D
20-6
http://database.ul.com/cgi-bin/XYV/template/LISEXT/1FRAME/index.htm
B
20-6
C
20-6
FILE E 60425
EAC
RU C-
DE.A*30.B.01742
10/19/2018 Page 4 / 5
https://www.phoenixcontact.com/pi/products/3215054
Ground modular terminal block - UT 10-PE/S - 3215054
Approvals
cULus Recognized
http://database.ul.com/cgi-bin/XYV/template/LISEXT/1FRAME/index.htm
