INTERCONNECTS
SERIES 802 & 803 • .100” GRID (.030” DIA. PINS), STRAIGHT &
RIGHT ANGLE HEADERS AND SOCKETS • DOUBLE ROW STRIPS
•
Pin interconnects available with straight MM
#7007 or right angle MM #5005/5107 solder
tails. See page 215 for details
.200
Number of Pins
X .100" / 2
.030 DIA.
.195
•
Sockets are available with straight MM #1304
or right angle MM #1305/1306 soldertails. See
pages 177 and 179 for details
.110
.024 DIA.
.125
.118
•
MM #1304, #1305 and #1306 receptacles use
.100
.100
FIG. 1
.195
.110
Number of Pins
X .100" / 2
Hi-Rel, 6- nger BeCu #47 contact rated at 4.5
amps. Receptacles accept .030” diameter and
.025” square pins. See page 256 for details
•
Insulators are high temperature thermoplastic,
suitable for all soldering operations
ORDERING INFORMATION
.200
.100
.050
.024 DIA.
.030 DIA.
.177
.100
.100
Series 802...10-001
Straight Pin Header
04-64
.126
FIG. 1
802 XX 0_ _ 10 001000
Specify number of pins
Series 802...20-001
Right Angle Pin Header
02-64
For
Electrical, Mechanical
& Enviromental Data,
See page 264
FIG. 2
.025-.037
.025
*
.025
.200
Number of Pins
X .100" / 2
FIG. 2
RoHS - 2
802 XX 0_ _ 20 001000
Specify number of pins
XX=Plating Code
See Below
10
10
µ”
Au
2011/65/EU
.088
.240 .258
.276
SPECIFY PLATING CODE XX=
Pin Plating
90
200
µ”
Sn/Pb
40
200
µ”
Sn
.024 DIA.
.118
Series 803...10-001
.100
.100
Straight Socket
004-100
FIG. 3
.276
.228
.088
Number of Pins
X .100" / 2
FIG. 3
803 XX _ _ _ 10 001000
Specify number of pins
Series 803...20-001
Right Angle Socket
002-100
For
Electrical, Mechanical
& Enviromental Data,
See page 264
Specify number of pins
.100
.050
.024 DIA.
.126
.200
2011/65/EU
RoHS - 2
XX=Plating Code
See Below
91
10
µ”
Au
.327
.100
.100
SPECIFY PLATING CODE XX=
Sleeve (Pin)
Contact (Clip)
93
99
41
43
200
µ”
Sn
30
µ”
Au
47
200
µ”
Sn
Au Flash
200
µ”
Sn/Pb 200
µ”
Sn/Pb 200
µ”
Sn/Pb
200
µ”
Sn
FIG. 4
30
µ”
Au
100
µ”
Sn/Pb
10
µ”
Au
Mill-Max Mfg. Corp. • 190 Pine Hollow Road, P.O. Box 300, Oyster Bay, NY 11771 • 516-922-6000 • Fax: 516-922-9253 • www.mill-max.com
PAGE 55 | INTERCONNECTS
FIG. 4
803 XX _ _ _ 20 001000
