INTERCONNECTS
SERIES 712 • .100” GRID CARRIER WITH SOLDER TAIL •
SINGLE AND DOUBLE ROW STRIPS
•
Standard solder tail receptacles can be
mounted as a low pro le receptacle or by the
solder tail for use in smaller diameter holes
•
Series 712 use MM #0255 pins. See page 165
for details
•
Hi-Rel, 4- nger BeCu #30 contact is rated at
3 amps. See page 253 for details
.015-.025
.010 * .018
.072 DIA.
.053 DIA.
.031
•
Insulators are high temperature thermoplastic,
suitable for all soldering operations
.103
.150 .173
ORDERING INFORMATION
Single Row (.028” or .055” min. mounting holes)
.020 DIA.
.124
FIG. 1
FIG. 1
FIG. 2
712 XX 1_ _ 41 001000
Specify number of pins
01-64
Double Row (.028” or .055” min. mounting holes)
712 XX 2_ _ 41 001000
Specify number of pins
04-64
.015-.025
.010 * .018
.072 DIA.
.053 DIA.
.031
.103
.020 DIA.
.124
2011/65/EU
RoHS - 2
XX=Plating Code
See Below
11
10
µ”
Au
10
µ”
Au
For
Electrical, Mechanical
& Enviromental Data,
See page 264
.100
SPECIFY PLATING CODE XX=
13
30
µ”
Au
91
10
µ”
Au
93
30
µ”
Au
41
10
µ”
Au
43
200
µ”
Sn
30
µ”
Au
FIG. 2
Sleeve (Pin)
Contact (Clip)
10
µ”
Au
200
µ”
Sn/Pb 200
µ”
Sn/Pb
200
µ”
Sn
Mill-Max Mfg. Corp. • 190 Pine Hollow Road, P.O. Box 300, Oyster Bay, NY 11771 • 516-922-6000 • Fax: 516-922-9253 • www.mill-max.com
PAGE 75 | INTERCONNECTS
