P
OLYFUSE
®
R
ESETTABLE
F
USES
This product is not recommended
for new designs. Please refer to
Littelfuse No. 1206L.
SMD1206
SMD Type, 6 V - 30 V
Standard
UL 1434 1 Edition
CSA C22.2 No. 0 CSA TIL No. CA-3A
st
Specifications
Packaging
A
Blistertape and reel Ø 178 mm
Approvals
Materials
cULus Recognition
TÜV
Features
This product line enables installation in limited
space applications. These devices offer wide
range in hold currents from 0.125 A to 1.50 A and
voltages from 6 V to 30 V . The SMD1206 product
line is suitable for high density circuit board
applications in computers, cellular phone and
general electronics.
Suitable for reflow soldering
Dimensions (mm)
Solder pad Layout (mm)
1.80
Solder-plated copper
TS: Solder Material: 63/37 SnPb
TF: Lead free plating on request
Max. Device Surface Temperature in Tripped State
125 °C
Operating / Storage Temperature
-40 ºC to +85 ºC (consider derating)
Humidity Ageing
+85 °C, 85% R.H., 1000 hours, ± 5 % typical
resistance change
Vibration
MIL-STD-883C, Method 2007.1, Condition A,
no change
Thermal Shock
MIL-STD-202F, Method 107G
+85 °C to -40 °C 20 times, -30 % typical resistance
change
Solderability
Meets EIA Specification RS186-9E,
ANSI/J-STD-002, Category 3
Reflow only
Solvent Resistance
MIL-STD-202, Method 215, no change
Marking
“P”, Part Code
Terminals:
1.8
*
*
1.0
1.0
* only type "TF"
D
Min
0.10
0.10
0.10
0.10
0.10
0.10
0.10
0.10
0.10
0.10
Dimensions (mm)
Model
SMD1206P012TS/TF
SMD1206P016TS/TF
SMD1206P020TS/TF
SMD1206P025TS/TF
SMD1206P035TS/TF
SMD1206P035TS/TF/15
SMD1206P050TS/TF
SMD1206P075TS/TF
SMD1206P100TS/TF
SMD1206P150TS/TF
A
Min Max
3.00
3.00
3.00
3.00
3.00
3.00
3.00
3.00
3.00
3.00
3.50
3.50
3.50
3.50
3.50
3.50
3.50
3.50
3.50
3.50
B
Min Max
1.50
1.50
1.50
1.50
1.50
1.50
1.50
1.50
1.50
1.50
1.80
1.80
1.80
1.80
1.80
1.80
1.80
1.80
1.80
1.80
C
Min Max
0.65
0.65
0.50
0.50
0.45
0.45
0.45
0.45
0.75
1.00
1.45
1.45
1.00
1.00
0.75
0.75
0.75
1.25
1.25
1.60
E
Min Max
0.20
0.20
0.20
0.20
0.20
0.20
0.20
0.20
0.20
0.20
0.45
0.45
0.45
0.45
0.45
0.45
0.45
0.45
0.45
0.45
packaging quantity
tape
3.000
3.000
4.000
4.000
4.000
4.000
4.000
3.000
3.000
2.000
cURus
•
•
•
•
•
•
•
•
•
•
SMD1206P012TS/TF
SMD1206P016TS/TF
SMD1206P020TS/TF
SMD1206P025TS/TF
SMD1206P035TSTF
SMD1206P035TS/TF/15
SMD1206P050TS/TF
SMD1206P075TS/TF
SMD1206P100TS/TF
SMD1206P150TS/TF
NOTE:
I
hold
=
I
trip
=
V
max
=
I
max
=
0.125
0.160
0.200
0.250
0.350
0.350
0.500
0.750
1.000
1.500
0.29
0.37
0.40
0.50
0.75
0.75
1.00
1.50
1.80
3.00
30
30
16
16
6
15
6
6
6
6
40
40
40
40
40
40
40
40
40
40
0.20 @ 1.00
0.30 @ 1.00
0.05 @ 8.00
0.08 @ 8.00
0.10 @ 8.00
0.10 @ 8.00
0.10 @ 8.00
0.20 @ 8.00
0.30 @ 8.00
1.00 @ 8.00
0.6
0.6
0.6
0.6
0.6
0.6
0.6
0.6
0.6
0.8
1.500
1.200
0.600
0.550
0.300
0.300
0.150
0.090
0.055
0.040
3.600
2.800
1.550
1.400
0.750
0.750
0.400
0.200
0.110
0.080
6.000
4.500
2.500
2.300
1.200
1.200
0.700
0.290
0.210
0.120
Please choose TS for SnPb and
TF
for Sn plating
Hold current: maximum current device will pass without tripping in 20 °C still air.
Trip current: minimum current at which the device will trip in 20 °C still air.
Maximum voltage device can withstand without damage at rated current (I
max
)
Maximum fault current device can withstand without damage at rated voltage (V
max
)
P
d
=
Power dissipated from device when in the tripped state at 20 °C still air.
Minimum resistance of device in initial (un-soldered) state.
R
min
=
R
1max
= Maximum resistance of device at 20 °C measured one hour after tripping for 20 s.
Caution: Operation beyond the specified rating may result in damage and possible arcing and
fl
ame.
Specifications are subject to change without notice
