Sensor/Actuator cable - SAC-4P-MST/ 3,0-PUR SH SCO - 1424121
Please be informed that the data shown in this PDF Document is generated from our Online Catalog. Please find the complete data in the user's
documentation. Our General Terms of Use for Downloads are valid
(http://download.phoenixcontact.com)
Sensor/Actuator cable, 4-position, PUR halogen-free, Black RAL 9005, shielded, Plug straight M12 SPEEDCON,
T-coded, on Free cable end, Cable length: 3 m
Product Features
Easy and safe: 100% electrically tested plug-in components
High-performance: DC connectors for up to 12 A and 60 V DC
Protection against incorrect connection using special T-coding
Shield power reliably – 360° shielding to reduce electromagnetic loads
Save time, thanks to installation with SPEEDCON rapid interlock system
Our standard: robust halogen-free PUR cable
Packing unit
Custom tariff number
Country of origin
11
85444290
Germany
Key commercial data
Technical data
Dimensions
Length of cable
3m
Ambient conditions
Ambient temperature (operation)
Degree of protection
-25 °C ... 85 °C (Plug / socket)
IP65
IP67
General
Rated current at 40°C
Rated voltage
12 A
60 V
30.10.2013 Page 1 / 4
https://www.phoenixcontact.com/us/products/1424121
Sensor/Actuator cable - SAC-4P-MST/ 3,0-PUR SH SCO - 1424121
Technical data
General
Number of positions
Contact resistance
Insulation resistance
Coding
Standards/regulations
Status display
Surge voltage category
Pollution degree
Insertion/withdrawal cycles
Torque
4
≤ 3 mΩ
≤ 10 GΩ
T power
M12 connector
No
III
3
> 100
0.4 Nm (M12 connector)
Material
Inflammability class according to UL 94
Contact material
Contact surface material
Contact carrier material
Material of grip body
Material, knurls
VO
CuZn
Au
PA
TPU, hardly inflammable, self-extinguishing
Zinc die-cast, nickel-plated
Cable
Cable type
Cable type (abbreviation)
Cable abbreviation
Conductor cross section
AWG power supply
Core diameter including insulation
Thickness, insulation
Wire colors
Overall twist
Shielding
External sheath, color
External cable diameter D
Smallest bending radius, fixed installation
Smallest bending radius, movable installation
Number of bending cycles
Bending radius
Traversing path
Traversing rate
PUR halogen-free black shielded
PUR
LS9YC11Y-OB
4x 1.5 mm²
16
2.4 mm
1.2 mm (Outer cable sheath)
brown, white, blue, black
4 wires optimally twisted
Tinned copper-braided shield, approx. 85% covering
Black RAL 9005
9.7 mm ±0.3 mm
49 mm
73 mm
4000000
97 mm
10 m
3 m/s
30.10.2013 Page 2 / 4
https://www.phoenixcontact.com/us/products/1424121
Sensor/Actuator cable - SAC-4P-MST/ 3,0-PUR SH SCO - 1424121
Technical data
Cable
Acceleration
Torsion force
Outer sheath, material
Material conductor insulation
Conductor material
Insulation resistance
Conductor resistance
Nominal voltage, cable
Test voltage, cable
Flame resistance
Halogen-free
Resistance to oil
Ambient temperature (operation)
10 m/s²
± 25 °/m
PUR
PP
Bare Cu litz wires
≥ 10 MΩ*km (at 20 °C)
≤ 13.3 Ω/km (at 20 °C)
300 V AC
1500 V AC (5 min.)
According to EN 60332-1-2
According to UL 1581 VW1
According to VDE 0282-13 Appendix C
in accordance with DIN EN 60811-2-1
According to DIN EN 50363-10-2
-40 °C ... 90 °C (cable, fixed installation)
-30 °C ... 90 °C (cable, flexible installation)
Classifications
eCl@ss
eCl@ss 4.0
eCl@ss 4.1
eCl@ss 5.0
eCl@ss 5.1
eCl@ss 6.0
eCl@ss 7.0
eCl@ss 8.0
27140815
27140815
27143423
27143423
27143423
27449001
27449001
ETIM
ETIM 3.0
ETIM 4.0
ETIM 5.0
EC002061
EC001855
EC001855
UNSPSC
UNSPSC 6.01
UNSPSC 7.0901
UNSPSC 11
UNSPSC 12.01
31251501
31251501
31251501
31251501
30.10.2013 Page 3 / 4
https://www.phoenixcontact.com/us/products/1424121
Sensor/Actuator cable - SAC-4P-MST/ 3,0-PUR SH SCO - 1424121
Classifications
UNSPSC
UNSPSC 13.2
31251501
Drawings
Schematic diagram
4
Cable cross section
3
1
2
Pin assignment for M12 plug, 4-pos., T-coded, view of plug side
PUR halogen-free black shielded [PUR]
Dimensioned drawing
Circuit diagram
54,8
1
2
BN
WH
BK
BU
Ø15,4
4
3
M12 x 1 plug, straight
Contact assignment of the M12 plug
© Phoenix Contact 2013 - all rights reserved
http://www.phoenixcontact.com
30.10.2013 Page 4 / 4
