SMD12HE
THRU
SMD120HE
1
Amp
Schottky Rectifiers
20
-
200
Volts
SOD-123HE
A
B
Features
•
Halogen
free available upon request by adding suffix "-HF"
•
Lead Free Finish/RoHS Compliant (Note1)("P"Suffix designates
Compliant. See ordering information)
•
•
•
•
•
•
High surge forward current capability
Epoxy meets UL 94 V-0 flammability rating
Moisture Sensitivity Level 1
Operating Temperature:
SMD12HE~SMD14HE:
-55°C to +125°C
SMD15HE~SMD120HE:
-55°C to +150°C
Storage Temperature: -55°C to +150°C
Typical Thermal Resistance:
15°C/W
Junction to
Lead
MCC
Catalog
Number
SMD12HE
SMD13HE
SMD14HE
SMD15HE
SMD16HE
SMD18HE
SMD110HE
SMD115HE
SMD120HE
Device
Marking
S12L
S13L
S14L
S15L
S16L
S18L
S110L
S115L
S120L
Maximum
Maximum
Recurrent
RMS
Peak
Reverse
Voltage
Voltage
20V
14V
30V
21V
40V
28V
50V
35V
60V
42V
80V
56V
100V
70V
150V
105V
200V
140V
I
F(AV)
I
FSM
V
F
12~14
15~16
18~110
115~120
0.50V
0.70V
Maximum
DC
Blocking
Voltage
20V
30V
40V
50V
60V
80V
100V
150V
200V
C
D
E
F
G
Electrical Characteristics @ 25°C Unless Otherwise Specified
Average Forward
Current
Peak Forward Surge
Current
Maximum
Instantaneous
Forward Voltage
Maximum DC
Reverse Current At
Rated DC Blocking
Voltage
1.0A
30A
T
a
=100
o
C
H
J
8.3ms, half sine
DIM
DIMENSIONS
INCHES
MM
MIN
MAX
MIN
MAX
.140
.156
3.55
3.95
.100
.112
2.55
2.85
.035
.043
0.90
1.10
.067
.075
1.70
1.90
.028
.035
0.70
0.90
.004
.008
0.10
0.20
.001
.002
0.02
0.05
.067
.098
1.70
2.50
.016
.047
0.40
1.20
NOTE
I
FM
=
2.0A;
T
a
=25
o
C
0.85V
0.90V
I
R
0.5mA
T
a
= 25°C
A
B
C
D
E
F
G
H
J
Note: 1. High Temperature Solder Exemption Applied, see EU Directive Annex 7.
www.mccsemi.com
Revision:
A
1 of
3
2016/01/09
MCC
Micro Commercial Components
R
Ordering Information :
Device
Part Number-TP
Note : Adding "-HF" suffix for halogen free, eg. Part Number-TP-HF
Packing
Tape&Reel:
3Kpcs/Reel
