SPECIFICATIONS
PARAMETERS
RATED VOLTAGE
OPERATING VOLTAGE RANGE
RATED CURRENT (MAX)
MINIMUM SPL @ 10 CM
RESONANT FREQUENCY
TONE OR PULSE RATE
OPERATING TEMPERATURE
STORAGE TEMPERATURE
HOUSING MATERIAL
TERMINAL MATERIAL
WEIGHT
VALUES
12
3 ~ 20
13
UNITS
Vdc
Vdc
mA
THIS DOCUMENT CONTAINS DATA PROPRIETARY
TO PROJECTS UNLIMITED, INC. ANY USE OR
REPRODUCTION, IN ANY FORM, WITHOUT PRIOR
WRITTEN PERMISSION OF PROJECTS
UNLIMITED, INC. IS PROHIBITED.
©2003, Projects Unlimited Inc.
LTR
-
A
REVISION HISTORY
DESCRIPTION
RELEASED FROM ENGINEERING
REVISED TO INVENTOR 3-D DRAWING TEMPLATE
DATE
6/30/2006
12/20/2007
APPROVED
B.R.
85
dBA
3200 ± 500
Hz
0 pulse /sec
CONTINUOUS
-30 ~ +100
°C
-40 ~ +120
°C
-
PBT
-
Sn PLATED COPPER
grams
3
9.7
n
23.4
n
3.7 SOUND
EMISSION HOLE
n
0.8 (2)
17.5
WASH TAB
6.5
NOTES:
1. ALL DIMENSIONS ARE IN MILLIMETERS.
2. SPECIFICATIONS SUBJECT TO CHANGE OR WITHDRAWL
WITHOUT NOTICE.
3. THIS PART IS RoHS 2002/95/EC COMPLIANT.
UNLESS OTHERWISE
SPECIFIED:
DIMENSIONS ARE IN
MILLIMETERS,
TOLERANCES
ARE ±0.5 AND
ANGLES ARE ±3°.
Designed by
Date
Checked by
Date
Approved by
Date
Drawn Date
SIZE
J.D.
6/30/2006
E.P.
7/1/2006
B.R.
7/1/2006 12/20/2007
A3
AI-2332-TWT-12V-2-R
Indicator
Edition
AI-2332-TWT-12V-2-R.idw
-
Sheet
1/1
