LAMINATED TRANSFORMERS
Type EE20 / 6.1
- 0.35VA
AGENCY
APPROVALS
1.
UL 506, File E113449
2.
UL 1585, File E175197
3.
EN61558
Class 2/3
Primary
(V)
230
230
230
230
230
230
230
V
DE
Secondary
(V / mA)
6 / 58.0
9 / 39.0
12 / 29.0
15 / 23.0
18 / 19.0
24 / 14.0
2x6 / 29.0
2x9 / 19.0
2x12 / 14.0
2x15 / 12.0
2x18 / 9.5
2x24 / 7.0
6 / 58.0
9 / 39.0
12 / 29.0
15 / 23.0
18 / 19.0
24 / 14.0
2x6 / 29.0
2x9 / 19.0
2x12 / 14.0
2x15 / 12.0
2x18 / 9.5
2x24 / 7.0
No-Load Schematic
Voltage
(V)
No.
10.80
16.50
21.90
27.00
31.50
41.70
2x10.95
2x15.60
2x20.70
2x26.00
2x31.20
2x41.90
10.80
16.50
21.90
27.00
31.50
41.70
2x10.95
2x15.60
2x20.70
2x26.00
2x31.20
2x41.90
1
1
1
1
1
1
2
2
2
2
2
2
1
1
1
1
1
1
2
2
2
2
2
2
Part
Number
020-5423.0
020-5424.0
020-5425.0
020-5426.0
020-5427.0
020-5428.0
020-5429.0
020-5430.0
020-5431.0
020-5432.0
020-5433.0
020-5434.0
020-5411.0
020-5412.0
020-5413.0
020-5414.0
020-5415.0
020-5416.0
020-5417.0
020-5418.0
020-5419.0
020-5420.0
020-5421.0
020-5422.0
Agency
Approvals
1/2/3*
1/2/3*
1/2/3*
1/2/3*
1/2/3*
1/2/3*
1/2/3*
1/2/3*
1/2/3*
1
1
1
1/2/3*
1/2/3*
1/2/3*
1/2/3*
1/2/3*
1/2/3*
1/2/3*
1/2/3*
1/2/3*
1
1
1
Frequency 50/60Hz
Potted under vacuum
Split-bobbin
Temperature class ta 70°C/B
Short-circuit-proof (where noted:
1/2/3* under Agency Approvals)
Weight: 0.024kg
Packaging unit: 40 pieces (tray)
Mechanical
230
230
230
230
230
115
115
115
115
115
115
115
115
115
115
115
115
22
(0.87)
15
(0.60)
4,5
(0.177)
*NOTE:
When checking the approval status of this product with VDE, add the prefix
"BV" and the suffix "M" to the orderable Part Number (these letters will also be found
on the part label).
The prefix and suffix are not part of the orderable Part Number.
15
(0.60)
5
23
(0.90)
6
7
8
4
3
2
1
Pin Ø 0,6 mm
(Pin DIA. 0.024)
3x5
(3 x 0.20)
Schematics
No. 1
4
6
No. 2
4
5
6
7
1
7
1
8
USA 858 674 8100
•
Germany 49 7032 7806 0
•
Singapore 65 6287 8998
•
Shanghai
86 21 54643211 / 2
•
China 86 769 85538070
•
Taiwan 886 3 4641811
www.pulseeng.com
3
LT2007 (9/07)
