COMPONENTS / ACCESSORIES
Front panels, HanDles
micro-switch
With cable and connector
For “live insertion” applications.
Installation in injector/extractor handles, types IV,
IVs and VII.
supply includes:
Micro-switch, connector type Molex 51021-
0300,
mounting clips, 3 cables,
25 mm x #32 AWG,
fully assembled.
1
Lever not depressed
3
2
Packs of
1 set
order no.
3686.536
1 2
2
Lever hinge
3
1
1
3
Lever contact point
3
2
~25
2
2
3.7
321
(6.6)
1-2 micro-switch levers depressed
Injector/extractor handle in latch position
1-3 micro-switch levers not depressed
Injector/extractor handle unlatched
3
1
2
3
(2)
7.25
1
(5.5)
8.5
micro-switch mounting clip
For mounting micro-switches in handles.
Packs of
10
order no.
3684.411
plastic covers
For pcBs
For mechanical protection of the component
side and of the EMC gaskets.
Attachment holes as per CPCI or VME-speci-
fications. Optionally available as perforated or
solid version.
material:
0.3 mm plastic, anti-static
Maximum temperature up to 65°C
mm plastic, transparent, anti-static
UL 94-V0, maximum temperature up to 65°C
2)
0.5
1)
0.5
mm plastic, black, anti-static UL 94-V0,
maximum temperature up to 120°C
order no.
For PCBs
Packs of
perforated
1)
3 U x 160 mm
3 U x 220 mm
6 U x 80 mm
6 U x 160 mm
1
5
1
5
1
1
1
5
6 U x 220 mm
1
5
3687.932
–
–
–
3687.933
3687.934
9905.574
2)
–
–
–
for CPCI
solid
1)
3686.572
–
–
–
3686.573
3686.574
9905.990
2)
–
–
–
solid
3685.966
–
–
–
3686.037
3685.967
–
–
–
–
for VME
solid
3685.626
3685.279
3685.805
3685.266
3686.146
3685.627
–
3685.280
3685.824
3685.000
!
also required:
Required for mounting the perforated CPCI
covers:
Mounting clips, Packs of = 100
order no. 3687.955
