DP7007G
is an intelligent, fully
programmable step-down point-of-load DC-DC
converter integrating digital power conversion and
intelligent power management. It works with the
DM7300 Series Digital Power Managers (DPM)
which provides for synchronizing all system Power-
On-Load regulators, for an elegant, flexible, low
noise power system solution.
All key parameters, sequencing, tracking, fault
protection, and compensation parameters of the
DP7007G are programmable via I
2
C based GUI. All
settings can be changed by a user at any time
during product development and service. Once
programmed, the DPM remembers all settings and
configures the DP7007G through a self-clocking
single wire communication bus. FLASH memory in
the DPM allows changes to be made without the
need to solder or rewire the regulator.
Input voltage range: 8 V–14 V
Output voltage range: 0.7 V–5.5 V at 0 – 7 A.
Programmable dynamic output voltage positioning
for better load transient response
Choice of 500 KHz switching for highest efficiency
or 1MHz for lowest ripple noise.
Flexible Fault Response features
Multiple turn-on/off slew rates and delays
Digital Filter Compensation
Synchronous operation with other supplies
Real time performance monitoring
GUI based configuration for short development
time.
Small footprint SMT package: 12.5 x 22.2 x 6.5 mm.
Approved to the latest edition and amendment of
ITE Safety standards, UL/CSA 60950-1 and
IEC60950-1
North America
+1-866.513.2839
Asia-Pacific
+86.755.29885888
Europe, Middle East
+353 61 225 977
tech.support@psbel.com
© 2015 Bel Power Solutions, Inc.
BCD.00255_AB
DP7007G
DP
PRODUCT FAMILY
70
SERIES
07
OUTPUT
CURRENT
7A
G
RoHS
COMPLIANCE
G
- RoHS compliant
for all six substances
–
DASH
zz
PACKAGING OPTIONS
1
R100
- 100pc T&R
R200
– 200pc T&R
Sample
quantity orders have
no suffix.
d-pwer
®
Intelligent dPOL Converter
Example:
DP7007G-R200:
A 200-piece reel of RoHS compliant dPOL converters. Each dPOL converter is labelled DP7007G.
Reference Documents
DM7300 Digital Power Manager Data Sheet
DM7300 Digital Power Manager Programming Manual
Bel Power Solutions I
2
C Graphical User Interface
DM00056-KIT USB to I
2
C Adapter Kit. User Manual
Stresses in excess of the absolute maximum ratings may cause performance degradation, adversely affect long term reliability, and
cause permanent damage to the converter.
PARAMETER
Inductor or Printed Circuit Board
(PCB) Temperature
Input Voltage
Output Current
CONDITIONS / DESCRIPTION
Input Voltage applied
250 ms Transient
(See Output Current De-rating Curves)
-6
MIN
-40
MAX
125
15
7
UNITS
C
VDC
ADC
Specifications apply at the input voltage from 8 V to 14 V, output load from 0 to 7 A, ambient temperature from -40°C to 85°C. Test
conditions include an output filter with 2 x 330
F
20 mΩ solid electrolytic, plus 1 x 22
F
X7R ceramic output capacitors, unless
otherwise noted.
3.1 INPUT SPECIFICATIONS
PARAMETER
Input voltage (V
IN
)
Input Current (at no load)
Undervoltage Lockout
VLDO Input Current
V
IN
= 14.0 V, V
OUT
= 3.3 V
Ramping Up
Ramping Down
Current drawn from the external low voltage supply at
VLDO = 8 V
5
50
CONDITIONS / DESCRIPTION
MIN
8
50
7.5
NOM
MAX
14
UNITS
VDC
mADC
VDC
VDC
mADC
1
Packaging option is used only for ordering and not included in the part number printed on the dPOL converter label.
+1.866.513.2839
tech.support@psbel.com
© 2015 Bel Power Solutions, Inc.
BCD.00255_AB
DP7007G
3.2 OUTPUT SPECIFICATIONS
PARAMETER
Output Voltage Range (V
OUT
)
Output Voltage Setpoint Resolution
Output Voltage Setpoint Accuracy
Output Current (I
OUT
)
Line Regulation
Load Regulation
Dynamic Regulation
Peak Deviation
Settling Time
2
nd
Vo Loop Enabled
V
IN MIN
to V
IN MAX
V
IN MIN
to V
IN MAX
0 to I
OUT MAX
Slew rate 1A/s, 50 -75% load step
F
SW
= 500 kHz to 10% of peak deviation
See Output Load Transient Section
V
IN
= 8.0 V, V
OUT
= 0.7 V
V
IN
= 8.0 V, V
OUT
= 2.5 V
Output Voltage Peak-to-Peak Ripple
and Noise
Scope BW = 20 MHz
Full Load
V
IN
= 8.0 V, V
OUT
= 5.5 V
V
IN
= 14 V, V
OUT
= 0.7 V
V
IN
= 14 V, V
OUT
= 2.5 V
V
IN
= 14 V, V
OUT
= 5.5 V
Temperature Coefficient
Switching Frequency
V
IN
= 12 V, I
OUT
= 0.5×I
OUT MAX
Default
Programmable to
Default
Programmable, 1.56% steps
3.125
-5.5
2
±0.3
±0.2
50
60
10
20
40
18
35
50
20
500
500 / 1000
90.5
100
CONDITIONS / DESCRIPTION
MIN
0.7
NOM
MAX
5.5
2.5 mV (1 LSB)
±(0.6% + 5 mV)
7
ADC
%V
OUT
%V
OUT
mV
s
mV
mV
mV
mV
mV
mV
ppm/°C
kHz
kHz
%
%
UNITS
VDC
Duty Cycle Limit
3.3 PROTECTION SPECIFICATIONS
PARAMETER
CONDITIONS / DESCRIPTION
MIN
NOM
MAX
UNITS
Output Overcurrent Protection
Type
Threshold
Threshold Accuracy
Default
Programmable
Default
Programmable in 11 steps
36
-20
Default
Programmable
Default
Programmable in 10% steps
Measured at V
O.SET
= 2.5 V
From instant when threshold is exceeded until the
turn-off command is generated
Default
Programmable to
110
-2
6
Emergency Off
Critical Off / Emergency Off
Non-Latching, 130 ms period
Latching/Non-Latching
132
132
+20
%
IOUT
%
IOUT
%I
OCP.SET
Output Overvoltage Protection
Type
Threshold
Threshold Accuracy
Delay
Turn Off Behavior
3
Non-Latching, 130 ms period
Latching/Non-Latching
130
130
2
%V
O.SET
%V
O.SET
%V
OVP.SET
μs
2
At negative (sink) output current (bus terminator mode) the efficiency of the DP7007 degrades resulting in increased internal power dissipation and
switching noise. Therefore maximum allowable negative current under specific conditions is lower than the current determined from the de-rating
curves shown in paragraph.
3
Sequenced Off: The turn-off follows the turn-off delay and slew-rate settings; Critical Off: At turn-off both low and high switches are immediately
disabled; Catastrophic Off: At turn-off the high side switch is disabled and the low side switch is enabled.
+1.866.513.2839
tech.support@psbel.com
© 2015 Bel Power Solutions, Inc.
BCD.00255_AB
DP7007G
Output Undervoltage Protection
Type
Threshold
Threshold Accuracy
Delay
Turn Off BehaviorError! Bookmark
not defined.
Default
Programmable
Default
Programmable in 5% steps
Measured at V
O.SET
= 2.5 V
From instant when threshold is exceeded until the
turn-off command is generated
Default
Programmable to
Default
Programmable
Temperature is increasing
Temperature is decreasing after the module was
shut down by OTP
4
-5
From instant when threshold is exceeded until the
turn-off command is generated
Default
Programmable to
Default
Programmable
Enabled during output voltage ramping up
-50
From instant when threshold is exceeded until the
turn-off command is generated
Always enabled, reported in Status register (TW bit)
5
From Nominal Set Point
-5
1.7
V
OUT
is inside the PG window
V
OUT
is outside the PG window
Default
Programmable in 5% steps
Default
Programmable in 5% steps
Measured at V
O.SET
=2.5V
Default
Programmable at
Default
PG Off Delay
Programmable same as PG On Delay
105
-2
0
0, 10, 50, 150
90
110
110
2
High
Low
90
95
%V
O.SET
%V
O.SET
%V
O.SET
%V
O.SET
%V
O.SET
ms
6
6
Sequenced Off
Sequenced / Critical Off
Disabled
Latching/Non-Latching, 130ms
250
50
mVDC
mVDC
μs
C
+5
C
C
75
-2
6
Sequenced Off
Sequenced / Critical Off
Non-Latching, 130 ms period
Latching/Non-Latching
120
110
5
C
C
C
μs
Non-Latching, 130 ms period
Latching/Non-Latching
75
90
2
%V
O.SET
%V
O.SET
%V
OVP.SET
μs
Overtemperature Protection
Type
Turn Off Threshold
Turn On Threshold
Threshold Accuracy
Delay
Turn Off BehaviorError! Bookmark
not defined.
Tracking Protection (when Enabled)
Type
Threshold
Threshold Accuracy
Delay
Overtemperature Warning
Threshold
Threshold Accuracy
Hysteresis
110
Power Good Signal (PG pin)
Logic
Lower Threshold
Upper Threshold
Threshold Accuracy
PG On Delay
6
PG disabled when V
OUT
≤
V
UV
threshold
PG disabled at turn-off command
(Reset function)
4
5
OTP clears when Overtemp Warning (Status Register TW bit) turns off.
Temp Warning error same sign and proportional with OTP error.
6
From instant when threshold is exceeded until status of PG signal changes high
+1.866.513.2839
tech.support@psbel.com
© 2015 Bel Power Solutions, Inc.
BCD.00255_AB
DP7007G
3.4 FEATURE SPECIFICATIONS
PARAMETER
CONDITIONS / DESCRIPTION
MIN
NOM
MAX
UNITS
Current Share
Type
Maximum Number of Modules
Connected in Parallel
Current Share Accuracy
Active, Single Line
I
OUT
≥
0
I
OUT
≥
20% I
OUT NOM
4
±20
%I
OUT
Interleave
Interleave (Phase Shift)
Default
Programmable in 22.5 steps
0
0
337.5
Degree
Degree
Sequencing
7
Turn ON Delay
Default
Programmable in 1ms steps
Default
Programmable in 1ms steps
0
0
0
63
0
225
ms
ms
ms
ms
Turn OFF Delay
Tracking
Turn ON Slew Rate
Default
Programmable in 8 steps
Default
Programmable in 8 steps
-0.05
0.05
-0.05
-2.0
8
0.05
2.0
8
V/ms
V/ms
V/ms
V/ms
Turn OFF Slew Rate
Optimal Voltage Positioning
Load Regulation
Default
Programmable in 7 steps
0
0
2.45
mV/A
mV/A
Feedback Loop Compensation
Proportional (Kr)
Integral (Ti)
Differential (Td)
Differential Roll-Off (Tv)
Programmable
Programmable
Programmable
Programmable
0.01
1
1
1
2
100
100
100
µs
µs
µs
Monitoring
Voltage Monitoring Accuracy
Current Monitoring Accuracy
Temperature Monitoring Accuracy
12 Bit Resolution over 0.5…5.5V
20% I
OUT NOM
< I
OUT
< I
OUT NOM
Junction temperature of dPOL controller
-0.5
-20
-5
0.5
+20
+5
%
%I
OUT
C
Remote Voltage Sense (+VS and –VS pins)
9
Voltage Drop Compensation
Voltage Drop Compensation
Between +VS and VOUT
Between -VS and PGND
300
100
mV
mV
7
8
9
Timing based on SD clock and subject to tolerances of SD.
Achieving fast slew rates under specific line and load conditions may require feedback loop adjustment. See Rising and Falling Slew Rates.
For remote sense, it is recommended to place a 0.01-0.1μF ceramic capacitor between +VS and –VS pins as close to the dPOL converter as
possible.
+1.866.513.2839
tech.support@psbel.com
© 2015 Bel Power Solutions, Inc.
BCD.00255_AB
