DAS6P 0101000 Overview

COAX RG6 18AWG 75OHM

DAS6P 0101000 Parametric

Parameter NameAttribute value
Cable type-
cable set-
Wire gauge-
Number of wire strands-
Sheath (insulation) material-
Sheath (insulation) diameter-
Shield type-
length-
Casing color-
characteristic-
conductor material-
dielectric materials-
Dielectric diameter-
shielding material-
Shielding range-
Operating temperature-
Part Number:
DAS6P
Distributed Antenna System RG6 Type BC Coax, CMP
Product Description
DAS RG-6 type, 18 AWG solid .040" bare copper conductor, foamed FEP insulation, Duobond® II foil shield + tinned copper braid shield (85% coverage),
CMP rated, low smoke PVC jacket.
Technical Specifications
Product Overview
Environmental Space:
Suitable Applications:
Indoor - Plenum
Distributed Antenna System
Physical Characteristics (Overall)
Conductor
AWG Stranding
18
Solid
Material
Nominal Diameter No. of Coax
1
BC - Bare Copper 0.040 in
18 AWG
Conductor Size:
Insulation
Material
Nominal Diameter
FFEP - Foam Fluorinated Ethylene Propylene 0.168 in
Outer Shield Material
Type Layer
Tape 1
Braid 2
Material
Aluminum / Polyester /
Aluminum
TC - Tinned Copper
Material Trade Name Coverage [%]
Duobond® II
100.0 %
85.0 %
Outer Jacket Material
Material
Nominal Diameter
LS PVC - Low Smoke Polyvinyl Chloride 0.233 in
Electrical Characteristics
Conductor DCR
Nominal Conductor DCR Outer Conductor DCR
6.4 Ohm/1000ft
Capacitance
Nom. Capacitance Conductor to Shield
16.1 pF/ft
Inductance
Nominal Inductance
0.103 µH/ft
Impedance
Nominal Characteristic Impedance
75 Ohm
Return Loss (RL)
3.3 Ohm/1000ft
