PRELIMINARY
MB95F856K, MB95F866K,
MB95F876K
New 8FX MB95850K/860K/870K Series
Datasheet
Description
The MB95850K/860K/870K Series is a series of general-purpose, single-chip microcontrollers. In addition to a compact instruction
set, the microcontrollers of these series contain a variety of peripheral functions.
Features
■
F
2
MC-8FX CPU core
■
❐
Built-in wake-up function
Instruction set optimized for controllers
❐
Multiplication and division instructions
❐
16-bit arithmetic operations
❐
Bit test branch instructions
❐
Bit manipulation instructions, etc.
■
Clock
❐
Selectable main clock source
• Main oscillation clock (up to 16.25 MHz, maximum ma-
chine clock frequency: 8.125 MHz)
• External clock (up to 32.5 MHz, maximum machine clock
frequency: 16.25 MHz)
• Main CR clock (4 MHz
2%)
• Main CR PLL clock
The main CR PLL clock frequency becomes 8 MHz
2%
when the PLL multiplication rate is 2.
The main CR PLL clock frequency becomes 10 MHz
2%
when the PLL multiplication rate is 2.5.
The main CR PLL clock frequency becomes 12 MHz
2%
when the PLL multiplication rate is 3.
The main CR PLL clock frequency becomes 16 MHz
2%
when the PLL multiplication rate is 4.
Selectable subclock source
• Suboscillation clock (32.768 kHz)
• External clock (32.768 kHz)
• Sub-CR clock (Typ: 100 kHz, Min: 50 kHz, Max: 150 kHz)
External interrupt
❐
MB95F856K: 6 channels
❐
MB95F866K: 8 channels
❐
MB95F876K: 10 channels
❐
Interrupt by edge detection (rising edge, falling edge, and
both edges can be selected)
❐
Can be used to wake up the device from different low power
consumption (standby) modes
8/10-bit A/D converter
❐
MB95F856K: 4 channels
❐
MB95F866K: 6 channels
❐
MB95F876K: 8 channels
❐
8-bit or 10-bit resolution can be selected.
Low power consumption (standby) modes
■
■
There are four standby modes as follows:
❐
Stop mode
❐
Sleep mode
❐
Watch mode
❐
Time-base timer mode
In standby mode, two further options can be selected: normal
standby mode and deep standby mode.
■
❐
■
Timer
❐
8/16-bit composite timer
• MB95F856K: 1 channel
• MB95F866K/F876K: 2 channels
❐
8/16-bit PPG
• MB95F856K: 1 channel
• MB95F866K: 2 channels
• MB95F876K: 3 channels
❐
Time-base timer
1 channel
❐
Watch counter
1 channel
❐
Watch prescaler
1 channel
UART/SIO
1 channel
❐
Full duplex double buffer
❐
Capable of clock asynchronous (UART) serial data transfer
and clock synchronous (SIO) serial data transfer
I
2
C bus interface
1 channel
I/O port
❐
MB95F856K (number of I/O ports: 21)
• General-purpose I/O ports (CMOS I/O): 17
• General-purpose I/O ports (N-ch open drain): 4
❐
MB95F866K (number of I/O ports: 29)
• General-purpose I/O ports (CMOS I/O): 25
• General-purpose I/O ports (N-ch open drain): 4
❐
MB95F876K (number of I/O ports: 45)
• General-purpose I/O ports (CMOS I/O): 41
• General-purpose I/O ports (N-ch open drain): 4
On-chip debug
❐
1-wire serial control
❐
Serial writing supported (asynchronous mode)
Hardware/software watchdog timer
❐
Built-in hardware watchdog timer
❐
Built-in software watchdog timer
Power-on reset
❐
A power-on reset is generated when the power is switched
on.
Low-voltage detection (LVD) reset circuit
■
■
■
■
■
■
Cypress Semiconductor Corporation
Document Number: 002-09305 Rev. *C
•
198 Champion Court
•
San Jose
,
CA 95134-1709
•
408-943-2600
Revised January
22,
2018
PRELIMINARY
MB95F856K, MB95F866K,
MB95F876K
❐
Built-in low-voltage detection function (The combination of
detection voltage and release voltage can be selected from
four options.)
■
Flash memory security function
❐
Protects the content of the Flash memory.
Touch sensor (TS)
❐
Adjacent Pattern Interference Suppression (APIS™)
❐
Three modes in APIS: APIS mode 1, APIS mode 2 and APIS
mode 3
❐
Configurable Automatic Impedance Calibration (AIC™)
❐
Direct output (DIO) function
Note:
APIS and AIC are registered trademarks of ATLab, Inc.,
South Korea.
Beep output unit
1 channel
■
Comparator
1 channel
❐
Built-in dedicated BGR
❐
The comparator reference voltage can be selected between
the BGR voltage and the comparator pin.
Clock supervisor counter
❐
Built-in clock supervisor counter
Dual operation Flash memory
❐
The program/erase operation and the read operation can be
executed in different banks (upper bank/lower bank) simul-
taneously.
■
■
■
■
Document Number: 002-09305 Rev. *C
Page 2 of 172
