RSMN-2016L Overview

LINE FILTER 250VDC/VAC 16A CHASS

RSMN-2016L Parametric

Parameter Name	Attribute value
filter type	Simplex
Configuration	Single-stage
Voltage - Rated DC	250V
Voltage - AC rated	250V
current	16A
Frequency - work	-
application	Universal
Approval	CSA，EN，UL
Operating temperature	-25°C ~ 85°C
Installation type	Base installation
Terminal type	Termination block
inductance	-

Preview

Download Datasheet

View All

RSMN Series

3A to 60A, 250VAC EMI Filters

Features



High Voltage Pulse Attenuation



Two Stage Filter for Better Performance



DIN Rail Mount Option (Up 30A)



Low Earth Leakage Current Option (Up to 30A)



Conforms to UL, CSA and EN Safety Agency Certiﬁcations

Speciﬁcations

Model

Rated Voltage (AC, DC)

Rated Current

Withstand Voltage

Isolation Resistance

Leakage Current (max)

DC Resistance (total)

RSMN-2003

RSMN-2003D

RSMN-2003L

V

A

V

MΩ

A

mΩ

3A

RSMN-2010

RSMN-2016

RSMN-2010D

RSMN-2016D

RSMN-2010L

RSMN-2016L

250V

6A

10A

16A

Terminals to Case: 2500VAC (1 Minute)

100MΩ minimum (500VDC, 1 Minute)

RSMN-20xx 1mA; RSMN20xxL 10uA (250VAC, 60Hz)

140

60

35

RSMN-2040

RSMN-2050

RSMN-2060

RSMN-2006

RSMN-2006D

RSMN-2006L

RSMN-2020

RSMN-2020D

RSMN-2020L

20A

350

RSMN-2030

RSMN-2030D

RSMN-2030L

22

Model

Rated Voltage (AC, DC)

Rated Current

Withstand Voltage

Isolation Resistance

Leakage Current (max)

DC Resistance (total)

Operating Temperature

Storage Temperature

Safety Agency Certiﬁcations

Weight

Warranty

V

A

V

MΩ

A

mΩ

°C

-

g

yr

30A

12

250V

40A

50A

60A

Terminals to Case: 2500VAC (1 Minute)

100MΩ minimum (500VDC, 1 Minute)

RSMN-20xx 1mA; RSMN20xxL 10uA (250VAC, 60Hz)

10

8

6

-25 to +85°C (Derate above 55°C, see derating curve)

-25 to +85°C

Up to 30A Models - UL1283, CSA C22.2 No.8, EN60939

190g to 960g model dependant (See weights chart on website)

5 Year

Derating

Circuit

Options

Chassis Mount & Standard Leakage Current

DIN Rail Mount & Standard Leakage Current

Chassis Mount & Low Leakage Current

RSMN-20xx

RSMN-20xxD

RSMN-20xxL

1-800-526-2324 • www.us.tdk-lambda.com/lp/

284

Disclaimer: us.tdk-lambda.com/lp/legal.htm
