LPH92B99-BTHR datasheet, PDF - EEWORLD Datasheet

EEWORLDEEWORLD

Datasheet

Datasheet> All Categories > Thermal management products> LPH92B99-BTHR

Preview

LPH92B99-BTHR: DescriptionFAN AXIAL 92X25.5MM 100-240VAC; CategoryThermal management products; File Size420KB，1 Pages; ManufacturerMechatronics Fan Group; Environmental Compliance

Download Datasheet Parametric Compare View All

LPH92B99-BTHR Overview

FAN AXIAL 92X25.5MM 100-240VAC

LPH92B99-BTHR Parametric

Parameter Name	Attribute value
Voltage - Rated	100 ~ 240VAC
size/dimensions	Square - 92mm long x 92mm high
width	25.50mm
airflow	56.0 CFM（1.57m³/min）
static pressure	0.270 inches water column (67.2 Pa)
Bearing type	ball
Fan type	Tube shaft type
characteristic	Automatic restart, electronic commutation (EC)
noise	44.0 dB（A）
Power (W)	6.30W
RPM	3500 RPM
Termination	2 terminals
Intrusion protection	-
Operating temperature	-40 ~ 158°F（-40 ~ 70°C）
Approval	CE，cUL，TUV，UL
weight	0.234 lbs (106.14g)
Rated current	0.060A
voltage range	90 ~ 264VAC
Material - Frame	plastic
Material - Blade	plastic
Service life at different temperatures	-

Preview

Download Datasheet

View All

12.20.19

AC

AXIAL FANS

AC SERIES

UF, UM, UX, LPT, LPH, ... etc.

AXIAL FANS

[ PART NUMBERING SYSTEM ]

AC

UF 12 A R 12 - B T H NS R - _

FRAME SIZE

60 ............. 60mm

80 ............. 80mm

92 ............ 92mm

12 ............. 120mm

13 ............. 127mm

16 ............. 160mm

15 ............. 172x150mm

17 ............. 172mm dia.

18 ............. 180mm

20 ............ 205mm

25 ............ 254mm dia.

CC ............ Conformal Coating

F ............... High Temperature

B1.............. Tachometer Output

B2.............. Locked Rotor Output

2EM........... IP68

EX.............. ATEX Rated

ROHS COMPLIANT

OPTIONS

N .............. IP55

NS ........... IP55 & Salt Fog

Protection

FRAME THICKNESS

A .............. 38mm

B .............. 25mm

D .............. 30mm

F .............. 62mm

G .............. 89mm

H .............. 107mm

J ............... 90mm

K .............. 55mm

P .............. 51mm

AIR FLOW LEVEL

SL

S

L

M

H

E

CONNECTION

T ............... Terminal

W ............. Leadwire

FEATURES

C .............. Permanent Split Capacitor Motor

M ............. Metal Impeller

CR ............ Permanent Split Capacitor & Reverse Flow

R .............. Reverse Airflow

E .............. Frameless Motor

MR ........... Metal Impeller & Reverse Flow

BEARINGS

B .............. Ball

S .............. Sleeve

VOLTAGE

12 ............ 115 VAC

23 ........... 230 VAC

12/23 ....... 115/230 VAC Dual Voltage

99 ........... 90 ~ 264 VAC

02 ............ 24 VAC

w w w.mechatronic s.com

E - mail: S ales @ M echatronic s.com

Fa x : 425 -2 2 2- 515 5

Tel: 425 -2 2 2- 5 9 0 0

800-453-4569

Cooling Simplified

LPH92B99-BTHR Related Products

	LPH92B99-BTHR	UF12A23-BTHR-CC	UF25HC12-BWHR	UF12B23-BTLR
Description	FAN AXIAL 92X25.5MM 100-240VAC	FAN AXIAL 120X38MM 230VAC TERM	FAN AXIAL 254X107MM 115VAC WIRE	FAN AXIAL 120X38MM 230VAC TERM
Voltage - Rated	100 ~ 240VAC	230VAC	115VAC	230VAC
size/dimensions	Square - 92mm long x 92mm high	Square - 120mm length x 120mm height	Round - 254mm diameter	Square - 120mm length x 120mm height
width	25.50mm	38.00mm	107.0mm	25.00mm
airflow	56.0 CFM（1.57m³/min）	106.0 CFM（2.97m³/min）	850.0 CFM（23.80m³/min）	53.0 CFM（1.48m³/min）
static pressure	0.270 inches water column (67.2 Pa)	0.350 inches water column (87.2 Pa)	0.680 inches water column (169.4 Pa)	0.110 inches water column (27.4 Pa)
Bearing type	ball	ball	ball	ball
Fan type	Tube shaft type	Tube shaft type	Tube shaft type	Tube shaft type
characteristic	Automatic restart, electronic commutation (EC)	conformal coating	Permanent split-phase capacitor motor	-
noise	44.0 dB（A）	46.0 dB（A）	65.0 dB（A）	33.0 dB（A）
Power (W)	6.30W	15.00W	125W	14.00W
RPM	3500 RPM	3100 RPM	2750 RPM	2000 RPM
Termination	2 terminals	2 terminals	4 leads	2 terminals
Operating temperature	-40 ~ 158°F（-40 ~ 70°C）	-40 ~ 158°F（-40 ~ 70°C）	-40 ~ 158°F（-40 ~ 70°C）	-40 ~ 158°F（-40 ~ 70°C）
Approval	CE，cUL，TUV，UL	CE，cUL，TUV，UL	CE，cUL，TUV，UL	CE，cUL，TUV，UL
weight	0.234 lbs (106.14g)	1.168 lbs (530g)	5.5 pounds (2.5kg)	0.725 lbs (328.85g)
Rated current	0.060A	0.080A	1.07A	0.060A
Material - Frame	plastic	Polybutylene terephthalate (PBT)	aluminum	aluminum
Material - Blade	plastic	Polybutylene terephthalate (PBT)	Polybutylene terephthalate (PBT)	Polybutylene terephthalate (PBT)
