PowerLine LEDs
SOLID STATE ALTERNATIVES TO INCANDESCENT BULBS
FOR INDUSTRIAL PLANTS AND UTILITIES
Available on-line at
www.powerlineleds.com
INTRODUCTION
PowerLine LEDs
This catalog represents our products designed
specifically for the unique needs of the power
generation, transmission and distribution industries.
We offer a comprehensive product line to provide direct
replacement of almost any indicator lamp being used
without modification to existing equipment.
Since many stations have unique requirements, DDP
engineers have also developed many modified versions
of our standard LED lamps.
If you don't find the lamp you need in this catalog, please
call our technical support number: (800) 421-6815 or
e-mail: techsupport@datadisplay.com
Our applications engineers are available for technical
assistance and to provide samples for evaluation. We
look forward to working with you.
www.powerlineleds.com l Tel. 800-421-6815 l Fax 310-640-7639 © 2008 DDP
www.powerlineleds.com
I
INTRODUCTION
Since 1970, DDP has pioneered the development of
LED lamps as replacements for incandescent bulbs.
The advantages that solid-state LEDs offer are
particularly suitable for the utility industry where
numerous lamps provide critical indication in control
panels. Burned-out incandescent bulbs require costly
maintenance and may create safety concerns.
Replacing incandescent bulbs with PowerLine® LED
lamps will provide many years of maintenance-free
operation.
PowerLine LEDs
TABLE OF CONTENTS
Page
Application Notes...........................................................................................1-3
Ordering Information............................................................................................4
Lamp Cross-Reference........................................................................................5
TABLE OF CONTENTS
T-1
3
⁄
4
Sub-Miniature Lamps..................................................................................6
• Flange Base • Groove Base • Wedge Base
T-2 Slide Based Lamps.....................................................................................
7
• Slide Base #3 • Slide Base #5
T-2 120 Volt Lamps................................................................................................8
• 120PC Replacement • 120PSB Replacement
24E / 24X Replacement Lamps and Lenses................................................9-10
• For GE ET-5, ET-6 and Westinghouse Minalite Sockets
1835 and 1819 Replacement Lamps and Lenses
....................................11-12
• For GE ET-16 Socket
www.powerlineleds.com
16mm Pilot Light and LED Lamp.......................................................................13
T- 3
1
⁄
4
Bayonet Based Lamps.............................................................................14
S-6 Lamps...........................................................................................................15
• Screw Base • Double Contact Bayonet Base
Custom LED Annunciator Retrofit Lamps.......................................................16
Limited Warranty.................................................................................................17
II
www.powerlineleds.com l Tel. 800-421-6815 l Fax 310-640-7639 © 2008 DDP
APPLICATION NOTES
PowerLine LEDs
PowerLine® LED lamps are designed as drop-in replacements and offer several advantages over
incandescent bulbs.
PowerLine® LED Lamp
Up to 100,000 hours
Predictable
No
Yes
Low
Low
No
Incandescent Bulb
2,000 hours
Unpredictable
Yes
No
High
High
Yes
The primary benefit of PowerLine® LED technology is the tremendous cost savings for the user by
eliminating replacement costs, lowering power consumption, and reducing operating temperatures.
Long Life
T
he most compelling advantage of using PowerLine® LED lamps is a predictable life. LEDs are
solid-state devices and, by definition, control current without heated filaments. When used within its
design parameters, a PowerLine® LED lamp will operate upwards of 100,000 hours (or 10 years).
Furthermore, LED lifetime is not shortened by turning the lamp on and off.
Led Lamp
Gradual degradation
over 100,000 hours of operation
LIGHT OUTPUT
Incandescent Bulb
catastrophic failure
after 2,000 hours
of operation
*Bulb life varies based on shock, vibration and number of on/off cycles
LIFE (HOURS)
The life of an incandescent bulb is unpredictable - subject to catastrophic failure due to shock, vibration,
or cold filament inrush current. Initial powering of a control panel with numerous incandescent bulbs
will generally result in several failures.
www.powerlineleds.com l Tel. 800-421-6815 l Fax 310-640-7639 © 2008 DDP
www.powerlineleds.com
1
APPLICATION NOTES
Average Life
Failure Mode
Lifetime affected by on/off operation
Resistant to shock and vibration
Operating temperature
Power consumption
Susceptible to cold filament inrush current
