F336R-1.800MHZ-DM0: DescriptionHCMOS Output Clock Oscillator, 1.8MHz Nom, ROHS COMPLIANT, SMD, 4 PIN; CategoryPassive components oscillator; File Size141KB，2 Pages; ManufacturerFOX [Fox Electronics]; Environmental Compliance

Download Datasheet Parametric Compare View All

F336R-1.800MHZ-DM0 Overview

HCMOS Output Clock Oscillator, 1.8MHz Nom, ROHS COMPLIANT, SMD, 4 PIN

F336R-1.800MHZ-DM0 Parametric

Parameter Name	Attribute value
Is it lead-free?	Lead free
Is it Rohs certified?	conform to
Maker	FOX [Fox Electronics]
package instruction	ROHS COMPLIANT, SMD, 4 PIN
Reach Compliance Code	compliant
ECCN code	EAR99
Is Samacsys	N
Other features	ENABLE/DISABLE FUNCTION; TAPE AND REEL
maximum descent time	6 ns
Frequency Adjustment - Mechanical	NO
frequency stability	25%
JESD-609 code	e4
Installation features	SURFACE MOUNT
Nominal operating frequency	1.8 MHz
Maximum operating temperature	85 °C
Minimum operating temperature	-40 °C
Oscillator type	HCMOS
Output load	15 pF
physical size	3.2mm x 2.5mm x 1.2mm
longest rise time	6 ns
Maximum supply voltage	3.63 V
Minimum supply voltage	2.97 V
Nominal supply voltage	3.3 V
surface mount	YES
maximum symmetry	55/45 %
Terminal surface	Gold (Au)
Base Number Matches	1

Preview

Download Datasheet

View All

HcMOS 3.2x2.5mm 3.3V SMD Oscillator

Model: F330 Series

Page 1 of 2

RoHS compliant / Pb Free

XpressO

®

Equivalent

FXO-HC33

Why XpressO?

Lower Cost, Faster Delivery, Low Jitter!

Rev. 10/21/2008

http://www.foxonline.com/need_a_sample.htm

FEATURES

•

3.3V Operation

HCMOS Output

Standby Function

Tape and Reel

(2,000 pcs. STD)

• PART nUMbER SElEcTiOn

Learn More - Internet Required

Part Number

584-Frequency-xxxxx

585-Frequency-xxxxx

586-Frequency-xxxxx

587-Frequency-xxxxx

588-Frequency-xxxxx

589-Frequency-xxxxx

590-Frequency-xxxxx

Model

Number

F330

F330R

F335

F335R

F336

F336R

F338

Frequency

Stability

1

±100PPM

±50PPM

±25PPM

±25PPM*

±20PPM*

Operating

Temperature (ºC)

-10 ~ +70

-40 ~ +85

-10 ~ +70

-40 ~ +85

-10 ~ +70

-40 ~ +85

-10 ~ +70

Frequency

Range (MHz)

0.625 ~ 75.000

1.800 ~ 50.000

3 .2 ± 0.2

#3

#4

Top

View

Dot denotes

Pin 1

2 .5 ± 0.2

#1

#2

1 .2 M ax

• ElEcTRicAl cHARAcTERiSTicS

PARAMETERS

Frequency Range (F

o

)

Storage Temperature Range (T

stg

)

Supply Voltage

(V

dd

)

Input Current

(I

dd

)

0.625 ~ 20.000 MHz

20.000+ ~ 40.000 MHz

40.000+ ~ 60.000 MHz

60.000+ ~ 75.000 MHz

Output Symmetry (50% V

dd

)

Rise Time (10% ~ 90% V

dd

) (T

r

)

Fall Time (90% ~ 10% V

dd

) (T

f

)

Output Voltage

(V

ol

)

(V

oh

)

Output Current

(I

ol

)

(I

oh

)

Output Load

(HCMOS)

Standby Current

Start-up Time

(T

s

)

Output Disable Time

2

Output Enable Time

2

Reflow Soldering Temp

Moisture Sensitivity Level (MSL)

Termination Finish

1

MAX

(unless otherwise noted)

0.625 ~ 75.000 MHz

-55ºC ~ +125ºC

3.3V ± 10%

7mA

13mA

19mA

24mA

45% ~ 55%

6nS

10% V

dd

90% V

dd

Min

2mA Min

-2mA Min

15pF

10µA

5mS

150nS

5mS

260ºC / 10 Seconds

1

Au

Bottom

View

#1

#4

1 .2

#2

#3

0 .8

0 .7

0 .9

Recommended

Solder Pad Layout

1 .4

1 .2

0 .5

#1

1 .0

All dimensions are in millimeters.

Pin Connections

# 1 E /D

#2 G ND

# 3 O u tp u t

#4 V

DD

Inclusive of 25ºC tolerance, operating temperature range, input voltage change, load change, aging,

shock, and vibration. *Excludes Shock/Vibration

2

An internal pullup resistor from pin 1 to pin 4 allows active output if pin 1 is left open.

Note: A 0.01µF bypass capacitor should be placed between VDD (Pin 4) and GND (Pin 2) to

minimize power supply line noise.

Drawing is for reference to critical specifications defined by size measurements.

Certain non-critical visual attributes, such as side castellations, reference pin shape, etc. may

vary. All specifications subject to change without notice.

• EnAblE / DiSAblE FUncTiOn

INH (Pin 1)

OUTPUT (Pin 3)

OPEN

2

ACTIVE

'1' Level V

ih

≥

70% V

dd

ACTIVE

'0' Level V

il

≤

30% V

dd

High Z

FOXElectronics

5570 Enterprise Parkway Fort Myers, Florida 33905 USA +1.239.693.0099 FAX +1.239.693.1554

http://www.foxonline.com

EMEA

Tel/Fax: +44 .1767.312632 |

Asia

Hong Kong Tel: +852.2854.4285 Fax +852.2854.4282

|

Japan

Tel: +81.3.3374/2079 Fax: +81.3.3374.5221
