SCERX22FBA Product Details
Time Delay Relays
Not EU R oHS or ELV C om plia nt
Quick Links
C heck Pricing & Availability
Search for Tooling
Product Feature Selector
C ontact Us About This Product
SCERX22FBA
(3-1437463-8)
T E I nternal N umber: 3 - 1 4 3 7 4 6 3 - 8
Product Highlights:
l
SC E Specification Grade True Off-Delay Timing Series
l
Input Voltage = 48 VAC
l
Input Voltage = 48 VDC
l
C ontact Arrangement = 2 Form C , DPDT, 2 C /O
l
C ontact Rating = 5A Resistive @ 120/240 VAC
View all Features
A dd to M y P art L is t
Reques t Sample
Find Similar P roduc ts
Active
Buy P roduc t
Documentation & Additional Information
Product Drawings:
l
None Available
Catalog Pages/Data Sheets:
l
None Available
Product Specifications:
l
None Available
Application Specifications:
l
None Available
Instruction Sheets:
l
None Available
CAD Files:
l
None Available
Additional Information:
l
Product Line Information
Related Products:
l
Tooling
Product Features
(Please use the Product Drawing for all design activity)
Product Type Features:
l
Termination Type = 8-Pin Octal Style Plug
Electrical Characteristics:
l
Input Voltage (VAC ) = 48
l
Input Voltage (VDC ) = 48
l
C ontact Rating = 5A Resistive @ 120/240 VAC
Body Related Features:
l
Series
= SC E Specification Grade True Off-Delay Timing
Contact Related Features:
l
Mounting Options = Socket
l
Mode of Operation = True Off-Delay
l
Delay Time = 0.5 seconds to 15 seconds
l
Type of C ontrol = Knob
l
Repeatability, Max. = ± 1%
l
Approved Standards = C E Approved, C SA C ertified, UL Recognized
l
Approx. Dimensions (L x W x H) (mm [in]) = 50.00 x 50.00 x 83.00
[1.970 x 1.970 x 3.270]
Configuration Related Features:
l
C ontact Arrangement
= 2 Form C , DPDT, 2 C /O
l
Multiple Timing Ranges = Without
Industry Standards:
l
RoHS/ELV C ompliance
= Not ELV/RoHS compliant
l
Lead Free Solder Processes
= Not suitable for lead free processing
Conditions for Usage:
l
Temperature Range (?C ) = -30 – +65
Other:
l
Brand = Agastat
