SOLID STATE DEVICES, INC.
14701 Firestone Blvd * La Mirada, Ca 90638
Phone: (562) 404-7855 * Fax: (562) 404-1773
SDR620CTM & Z
thru
SDR622CTM & Z
40 AMPS
100 - 200 VOLTS
35 nsec
HYPER FAST
COMMOM CATHODE
CENTERTAP RECTIFIER
TO-254 (M)
TO-254Z (Z)
Designer's Data Sheet
FEATURES:
•
•
•
•
•
•
•
•
•
Replaces 1N6657, 1N6658, 1N6659 Devices
Hyper Fast Recovery: 35 nsec Maximum
High Surge Rating
Low Reverse Leakage Current
Low Junction Capacitance
Hermetically Sealed Package
Gold Eutectic Die Attach available
Ultrasonic Aluminum Wire Bonds
TX, TXV and Space Level Screening Available
Available in Following Configurations:
3/
SDR620CTM, SDR620CTZ, SDR620CAM, SDR620CAZ, SDR620DM, SDR620DZ
SDR621CTM, SDR621CTZ, SDR621CAM, SDR621CAZ, SDR621DM, SDR621DZ
SDR622CTM, SDR622CTZ, SDR622CAM, SDR622CAZ, SDR622DM, SDR622DZ
Maximum Ratings
Peak Repetitive Reverse and
DC Blocking Voltage
2/
SDR620CTM & Z
SDR621CTM & Z
SDR622CTM & Z
SYMBOL
V
RRM
V
RWM
V
R
Io
I
FSM
T
OP
& Tstg
VALUE
100
150
200
40
300
-65 TO +200
UNITS
Volts
Amps
Amps
o
Average Rectified Forward Current
(Resistive load, 60Hz, Sine Wave, T
A
= 25
o
C) 1/
Peak Surge Current
(8.3 ms Pulse, Half Sine Wave, T
A
= 25
o
C, per leg) 1/
Operating and Storage Temperature
Maximum Thermal Resistance
Junction to Case, each individual diode
Junction to Case, 1/
NOTES:
1/
2/
3/
Both Legs Tied Together
Higher Voltages Available
Consult Factory for Doubler Specifications
C
R
θJC
1.2
0.8
o
C/W
NOTE:
All specifications are subject to change without notification.
SCD's for these devices should be reviewed by SSDI prior to release.
DATA SHEET #: RC0027E
PM
SDR620CTM & Z
thru
SDR622CTM & Z
Electrical Characteristics (Per Leg)
Instantaneous Forward Voltage Drop
(T
A
= 25
o
C, 300 - 500 µsec Pulse )
I
F
= 10A
I
F
= 20A
SYMBOL
V
F1
V
F2
V
F3
V
F4
I
R1
I
R2
C
J
t
RR
SOLID STATE DEVICES, INC.
14701 Firestone Blvd * La Mirada, Ca 90638
Phone: (562) 404-7855 * Fax: (562) 404-1773
MINIMUM
--
--
--
--
--
--
--
MAXIMUM
1.0
1.2
0.9
1.15
10
1.0
225
35
UNITS
V
DC
V
DC
µA
mA
pF
nsec
Instantaneous Forward Voltage Drop
T
A
= 100
o
C
(I
F
= 10A, 300 - 500 µsec pulse )
T
A
= -55
o
C
Reverse Leakage Current
(Rated V
R,
300µs pulse min.)
Junction Capacitance
(V
R
= 10V
DC
, T
A
= 25
o
C, f = 1MHz)
Reverse Recovery Time
(T
A
= 25
o
C,I
F
= 0.5A, I
R
= 1.0A, I
RR
= 0.25A)
CASE OUTLINE: TO-254 (Sufix M)
Ø.150
.139
.685
.665
.750
.500
T
A
= 25
o
C
T
C
= 100
o
C
CASE OUTLINE: TO-254Z (Sufix Z)
PIN 3
.545
.535
2x .155
.145
PIN 2
PIN 1
3x Ø.045
.035
.545
.535
.270
.240
.155
.140
.050
.040
.800
.790
OPTIONAL LEAD BEND CONFIGURATION
.9
10
.5
10
PIN ASSIGNMENT
CODE
.170
MIN
FUNCTION
Common Cathode
Common Anode
Doubler
PIN 1
Anode
Cathode
Cathode
PIN 2
Cathode
Anode
A/C
PIN 3
Anode
Cathode
Anode
CT
CA
D
.7
10
MN
I
.190
.150
SUFIX MD & ZD
SUFIX MU & ZU
