Solid State Devices, Inc.
14830 Valley View Blvd * La Mirada, Ca 90638
Phone: (562) 404-7855 * Fax: (562) 404-1773
ssdi@ssdi-power.com * www.ssdi-power.com
SDR6006HF series
60A 35nsec
400 to 600 V
Hyper Fast Rectifier
Features
:
•
•
•
•
•
•
•
Hyper Fast Recovery: 35nsec Maximum
High Surge Rating
Low Reverse Leakage Current
Low Junction Capacitance
Hermetically Sealed, Isolated Package
providing enhanced thermal performance
Eutectic Die Attach
TX, TXV, and S Level Screening iaw MIL-
PRF-19500 Available
DESIGNER’S DATA SHEET
Part Number / Ordering Information
1/
SDR60 __ HF __ __
│ │ │
└
Screening
__
= Not Screened
│ │ │
TX = TX Level
TXV = TXV
│ │ │
S = S Level
│ │ │
│ │ │
│ │
└
Package
N = TO-258
│ │
P = TO-259
│ │
│
└
Configuration hyperfast family
│
│
└
Voltage
04 = 400 V
05 = 500 V
06 = 600 V
Maximum Ratings
Peak Repetitive Reverse Voltage
Average Rectified Forward Current
(Resistive Load, 60 Hz Sine Wave, T
C
= 100 °C)
Peak Surge Current
(8.3 ms Pulse, Half Sine Wave, T
A
= 25 °C)
Operating & Storage Temperature
Maximum Total Thermal Resistance
Junction to Case
TO-258 (N)
TO-259 (P)
Symbol
SDR6004HF
SDR6005HF
SDR6006HF
Total
V
RRM
Io
I
FSM
T
OP
& T
STG
R
θJC
Value
400
500
600
60
750
-65 to +200
1.0
(0.6 typ)
Units
Volts
Amps
Amps
ºC
ºC/W
NOTE:
All specifications are subject to change without notification.
SCD's for these devices should be reviewed by SSDI prior to release.
DATA SHEET #: RC0093A
DOC
Solid State Devices, Inc.
14830 Valley View Blvd * La Mirada, Ca 90638
Phone: (562) 404-7855 * Fax: (562) 404-1773
ssdi@ssdi-power.com * www.ssdi-power.com
SDR6006HF Series
Symbol
I
F
= 20 A
I
F
= 40 A
I
F
= 60 A
T
A
= -55 ºC
T
A
= 100 ºC
T
A
= 25 ºC
T
A
= 100 ºC
V
F1
V
F2
V
F3
Electrical Characteristic
Instantaneous Forward Voltage Drop
(T
A
= 25ºC, 300 – 500
µsec
Pulse)
Instantaneous Forward Voltage Drop
(I
F
= 40A, 300 – 500
µsec
Pulse)
Reverse Leakage Current
(100% of rated V
R
, 300
µs
pulse min.)
Reverse Recovery Time
(I
F
= 0.5A, I
R
= 1A, I
RR
= 0.25A, T
A
= 25ºC)
Junction Capacitance
(V
R
= 10V
DC
, T
A
= 25ºC, f = 1MHz)
NOTES:
1/ For Ordering Information, Price, and Availability Contact Factory.
Available Part Numbers:
SDR6004HFN, SDR6004HFP
SDR6005HFN, SDR6005HFP
SDR6006HFN, SDR6006HFP
TO-258:
Min
––
––
Max
1.25
1.40
1.55
1.50
1.35
100
10,000
35
150
Units
V
DC
V
DC
µA
µA
nsec
pF
V
F3
V
F4
I
R1
I
R2
t
RR
C
J
––
––
––
––
PIN ASSIGNMENT
PACKAGE
TO-258 (N)
TO-259 (P)
TO-259:
Pin 1
Cathode
Cathode
Pin 2
Anode
Anode
Pin 3
Anode
Anode
PIN 1
PIN 2
PIN 3
NOTE:
All specifications are subject to change without notification.
SCD's for these devices should be reviewed by SSDI prior to release.
PIN 1
PIN 2
PIN 3
DATA SHEET #: RC0093A
DOC
