Metri-Pack Series
S
SE
AL
Available in device and in-line
connections for vehicle applications,
Metri-Pack 150 Series connectors can
meet or exceed the requirements for
most marine, appliance, and industrial
control applications.
Ideally suited for limited space
applications that do not require environ-
mental protection, Metri-Pack 150 Series
products are extremely versatile.
E
N
AL
S
S
E
L
E
A
ED
Available in device and in-line
connections for underhood vehicle
AL
E
D
applications, Metri-Pack 150 Series sealed
connectors can meet or exceed the
150
E
U
D
D
U
requirements for most marine, appliance,
and industrial control applications.
Utilizing triple-rib peripheral silicone
rubber seals, Metri-Pack 150 Series
sealed systems are ideally suited for
critical, low-energy electronic appli-
cations that require protection from
environmental hazards.
150 Metri-Pack Features
•
Connector Position Assurance
(CPA)
•
Terminal Position Assurance
(TPA)
•
14 Amps continuous maximum
current rating
•
Small overall dimensions
•
Low energy, low voltage capability
•
Excellent resistance to temperature,
chemicals and abrasion
•
-40ºC to 125ºC temperature range
150
Metri-Pack Series
U
N
SE
AL
SE
AL
E
U
Unsealed System Application Information
150 SERIES TERMINALS–Tin Plated
O
CABLE RANGE
(
mm
2
):
........ 0.35-1.0
......... 0-14
T
EMPERATURE RISE
( C)
100
80
60
40
20
0
0
5
10
15
20
1.0
0.50
0.80
M
AXIMUM
C
URRENT
(AMPS)
TEMPERATURE RISE ABOVE
AMBIENT (25
o
C ) VS CURRENT*
TEMPERATURE DERATING CURVES*
20
15
10
5
0
25
50
75
100
O
1.0
0.80
0.50
CURRENT RANGE
(
AMPS
):
TEMP RANGE
O
C
:
RESISTANCE
:
........... -40 to 125
.... <10.0 mV/amp
3.5
........ <10m
Ω
@20mV
VOLTAGE DROP
:
CENTERLINE SPACING
(
mm
): ........
125
BLADE WIDTH
(
mm
): .................. 1.5
C
URRENT
(AMPS)
A
MBIENT
T
EMPERATURE
( C )
*The test data are based on single circuits in free space and were generated using a “Lumped
Resistance” model. This model does not account for all of the variables that would be present
in an actual application. For actual product performance, contact your regional support
representative at the number listed below.
Male Terminal
TPA
(Terminal Position
Assurance)
Male Connector
150 MALE CONNECTORS UNSEALED
# Cavities
1
2
2
3
3
4
4
4
6
8
8
10
Connector
12047683
12047663
12052833
12047782
12064759
12047786
12064761
12092163
12064763
12045688
12064767
12064770
Color
Black
Black
Black
Black
Black
Black
Black
Black
Gray
Black
Blue
Natural
Material
PA66 HS IM
PA66 HS IM
PBT
PA66 HS IM
PBT
PA66 HS IM
PBT
PA66 HS IM
PBT
PA66 HS IM
PBT
PBT
TPA
–
12047665
12047665
12047784
12047784
12047787
12047787
12092164
12064765
12045690
12045690
12064772
Part #
12047581
12059894
150 MALE TERMINALS UNSEALED
Cable Range (mm
2
)
1.0-0.80
0.50-0.35
Material
Tin Brass
Tin Brass
Plating
Tin
Tin
SECTION NOTES:
Contact your regional support representative at the number listed below.
• Due to rigid tolerances of connector cavities, it is critical
to meet all crimp dimensions as specified.
• Female connections for device applications,
see page 74.
http://delphi.com/products/connect
North American Region
1-800-PACKARD
European Region
49-202-291-2000
Asia Pacific Region
65-730-9900
South American Region
55-12-378-2002
