With continued commitment to leading the industry in power
connectors and providing the most complete high quality
interconnect solutions, Amphenol is honored to introduce
a new generation of IEC-309 connectors, the Amphe-309.
This series includes plugs, connectors, receptacles, inlet,
and mechanical interlocks, all of which comply with the
requirements of IEC 603 09-1 & 2, EN 60 309-1 & 2, BS
4343-2 1992, and UL 1682 & 1686.
The Amphe-309 consists of both IP44 and IP67 devices
from 16 A up to 125 A, from a simple plug to customer
specified combination units. The series range covers all
clock positions in use from low profile, watertight, and Heavy
Duty solutions.
Approved and certified by CE, UL, CSA and CCC,
Amphe-309 covers commercial and industrial applications for
international markets, as well as, the North American market.
Features:
•
•
•
•
•
•
•
•
•
•
Plug, receptacle, connector, inlet and mechanical interlock
IP 44, IP 67
16A to 125A, up to 690V
Low voltage <50V available
Low profile, and Heavy Duty options
Various termination options
Cable, surface and panel mounted types with straight
and angled options
UL, CAS, CE, CCC certified
ATEX version available (See Data Sheet EX309 IDS-92)
Custom Amphe-309 cable assemblies
www.amphenol-industrial.com
How To Order:
A309
Number of Wires
2P+E
3P+E
3P+N+E
Amperage
16A
20A
30A
32A
60A
63A
100A
125A
3
16
P
3
W
SC
3
4
5
16
20
30
32
60
63
100
125
P
C
RS
R
BS
B
S
W
1 to 12
SC
PE
SP
MA
LV
MF
Modification
Screw Terminals
Perforating Terminals
Spring Terminals
Mantle Terminals
Extra Low Voltage
Minimized Flange
Protection
IP44
IP67
Type
Plug, straight
Connector Receptacle, straight
Receptacle, surface
Receptacle for Panel Mounting, straight
Inlet, surface
Inlet for Panel Mounting, straight
Clock Keyway position of female Grounding
The voltage is determined by the location of the female ground contact relative to the housing keyway Simply by manufacturing the
device with a ground contact in a certain “clock” position, the device will be rated for a particular voltage system.
International Rating
P+N+E, 2P+E
3P+E
Optional voltage (not stated below)
>50V AC, 300-500Hz
50-250V DC
380V AC 50Hz
440V AC 60Hz
220V AC 50Hz, 380 AC 50Hz
250V AC 60Hz, 440 AC 60Hz
North American Rating
3P+N+E
Female Grounding
Positions
1h
2h
3h
4h
5h
6h
7h
8h
9h
10h
11h
12h
Not applicable
250V DC
125V AC
277V AC
250V AC
480V AC
Not applicable
Not applicable
Not applicable
Not applicable
Not applicable
P+N+E, 2P+E
3P+E
Not applicable
Not applicable
380V AC 50Hz
440V AC 60Hz
Not applicable
3Ø600V AC
Not applicable
3Ø480V AC
Not applicable
3Ø250V AC
Not applicable
Not applicable
125/250V AC
2P+N+E
50-600V AC, 400Hz
Not applicable
Not applicable
3ØY347/600V AC
Not applicable
3ØY277/480V AC
Not applicable
3ØY120/208V AC
Not applicable
Not applicable
Not applicable
3P+N+E
100-130V AC 50/60Hz
277V AC 60Hz
200-250V AC 50/60Hz
600-690V AC 50/60Hz
380-415V AC 50/60Hz
57-75V AC
100-130V AC
347-400V AC 50/60Hz
600-690V AC 50/60Hz
200-240V AC 50/60Hz
346-415V AC 50/60Hz
277-288V AC 50/60Hz
480-500V AC 50/60Hz
Not applicable
120-144V AC 50/60Hz
208-250V AC 50/60Hz
Not applicable
256-265V AC 60Hz
440-460V AC 60Hz
Not applicable
480-500V AC 50/60Hz
250V DC
380-415V AC 50/60Hz
Not applicable
Not applicable
Supply for isolating
transformer
Not applicable
200-250V AC 50/60Hz
>50V AC, 100-300Hz
440-460V AC 60Hz
Supply for isolating
transformer
Applications:
• Domestic Electric
• Construction Sites
• Data Center & Server Industry
• Commercial and Agricultural
Installations
• Outdoor Apparatuses
• Lighting and Audio Power
• Camp Grounds
