RP692-150-2000-S datasheet, PDF

Datasheet> All Categories > Analog mixed-signal IC> filter> RP692-150-2000-S

RP692-150-2000-S: DescriptionPower line filter FILTER DC HI-VOLT HI CURRINVRTR150A2000NF; CategoryAnalog mixed-signal IC filter; File Size3MB，5 Pages; ManufacturerAstrodyne TDI

Download Datasheet Parametric Compare View All

RP692-150-2000-S Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	RP692-150-2000-S	-	-	View	Buy Now

RP692-150-2000-S Overview

Power line filter FILTER DC HI-VOLT HI CURRINVRTR150A2000NF

RP692-150-2000-S Parametric

Parameter Name	Attribute value
Maker	Astrodyne TDI
Reach Compliance Code	compliant
filter type	SINGLE PHASE EMI FILTER
Manufacturer's serial number	RP692
Base Number Matches	1

Preview

Download Datasheet

View All

RP692 Series

RP692

DC TO 2500A &1200V

CHASSIS MOUNT FILTER

INVERTER APPLICATION

ROHS COMPLIANT

RADIUS POWER

Your Power Partner

High Voltage/High Current DC Power Line Filter

SPECIFICATIONS

Max. Operating Voltage

Ambient Temperature

Climatic Category

Hipot Rating (L-G)

Terminals (-T)

1200VDC

-25 to 60C

25/100/21

4700VDC

S: 25/50A (M5)

75A (M6)

100A (M8)

150A (M10)

B: 250A (5x20)

400A (6x25)

600A (8x25)

800/1000A (8x40)

1500A (10x60)

2500A (15x70)

cURus, EN60939

FREQ (MHz)

CM(dB)

DM(dB)

TYPICAL INSERTION LOSS, dB

(50/50ohm)

.15

1.0

Safety Approvals

PART NUMBER/ ORDERING

RP692

-X

-Y

(Amps) (Ycap, nF)

100

150

250

400

600

800

1000

1500

2500

100

1000

2000

-T

Weight

LBS (KG)

Typ.

3.0 (1.4)

5.5 (2.5)

8.5 (3.9)

13.0 (5.9)

17.0 (7.7)

18.0 (8.2)

60.0 (27.2)

SCHEMATIC

Note:

Use any combination of -Y with any -X (Amps) rating

e.g. RP692-25-100-S (25 Amps with 100nF Y-cap)

Reference purposes only.

Specifications are subject to change.

Consult factory to verify specifications.

www.radiuspower.com

Engineering Assistance: engg@radiuspower.com

Sales:sales@radiuspower.com

145
