GS8321Z36AGD-200IV

Description
Static random access memory 1.8/2.5V 1M x 36 36M
Categorystorage    storage
File Size281KB,31 Pages
ManufacturerGSI Technology
Websitehttp://www.gsitechnology.com/
Environmental Compliance
Download Datasheet Parametric View All

GS8321Z36AGD-200IV Online Shopping

Suppliers Part Number Price MOQ In stock
GS8321Z36AGD-200IV - - View Buy Now

GS8321Z36AGD-200IV Overview

Static random access memory 1.8/2.5V 1M x 36 36M

GS8321Z36AGD-200IV Parametric

Parameter NameAttribute value
Is it lead-free?Lead free
Is it Rohs certified?conform to
MakerGSI Technology
Parts packaging codeBGA
package instructionLBGA, BGA165,11X15,40
Contacts165
Reach Compliance Codecompliant
ECCN code3A991.B.2.B
Factory Lead Time8 weeks
Maximum access time6.5 ns
Other featuresALSO OPERATES AT 2.5V SUPPLY, PIPELINED ARCHITECTURE, FLOW THROUGH
Maximum clock frequency (fCLK)200 MHz
I/O typeCOMMON
JESD-30 codeR-PBGA-B165
JESD-609 codee1
length15 mm
memory density37748736 bit
Memory IC TypeZBT SRAM
memory width36
Humidity sensitivity level3
Number of functions1
Number of terminals165
word count1048576 words
character code1000000
Operating modeSYNCHRONOUS
Maximum operating temperature85 °C
Minimum operating temperature-40 °C
organize1MX36
Output characteristics3-STATE
Package body materialPLASTIC/EPOXY
encapsulated codeLBGA
Encapsulate equivalent codeBGA165,11X15,40
Package shapeRECTANGULAR
Package formGRID ARRAY, LOW PROFILE
Parallel/SerialPARALLEL
Peak Reflow Temperature (Celsius)260
power supply1.8/2.5 V
Certification statusNot Qualified
Maximum seat height1.4 mm
Maximum standby current0.04 A
Minimum standby current1.7 V
Maximum slew rate0.205 mA
Maximum supply voltage (Vsup)2 V
Minimum supply voltage (Vsup)1.7 V
Nominal supply voltage (Vsup)1.8 V
surface mountYES
technologyCMOS
Temperature levelINDUSTRIAL
Terminal surfaceTin/Silver/Copper (Sn/Ag/Cu)
Terminal formBALL
Terminal pitch1 mm
Terminal locationBOTTOM
Maximum time at peak reflow temperatureNOT SPECIFIED
width13 mm
GS8321Z18/32/36AD-xxxV
165-Bump BGA
Commercial Temp
Industrial Temp
Features
• User-configurable Pipeline and Flow Through mode
• NBT (No Bus Turn Around) functionality allows zero wait
read-write-read bus utilization
• Fully pin-compatible with both pipelined and flow through
NtRAM™, NoBL™ and ZBT™ SRAMs
• IEEE 1149.1 JTAG-compatible Boundary Scan
• 1.8 V or 2.5 V core power supply
• 1.8 V or 2.5 V I/O supply
• LBO pin for Linear or Interleave Burst mode
• Pin-compatible with 2Mb, 4Mb, 8Mb, and 18Mb devices
• Byte write operation (9-bit Bytes)
• 3 chip enable signals for easy depth expansion
• ZZ pin for automatic power-down
• JEDEC-standard 165-bump BGA package
• RoHS-compliant 165-bump BGA package available
36Mb Pipelined and Flow Through
Synchronous NBT SRAM
333 MHz–150 MHz
1.8 V or 2.5 V V
DD
1.8 V or 2.5 V I/O
Because it is a synchronous device, address, data inputs, and
read/ write control inputs are captured on the rising edge of the
input clock. Burst order control (LBO) must be tied to a power
rail for proper operation. Asynchronous inputs include the
Sleep mode enable, ZZ and Output Enable. Output Enable can
be used to override the synchronous control of the output
drivers and turn the RAM's output drivers off at any time.
Write cycles are internally self-timed and initiated by the rising
edge of the clock input. This feature eliminates complex off-
chip write pulse generation required by asynchronous SRAMs
and simplifies input signal timing.
The GS8321Z18/32/36AD-xxxV may be configured by the
user to operate in Pipeline or Flow Through mode. Operating
as a pipelined synchronous device, in addition to the rising-
edge-triggered registers that capture input signals, the device
incorporates a rising-edge-triggered output register. For read
cycles, pipelined SRAM output data is temporarily stored by
the edge triggered output register during the access cycle and
then released to the output drivers at the next rising edge of
clock.
The GS8321Z18/32/36AD-xxxV is implemented with GSI's
high performance CMOS technology and is available in
JEDEC-standard 165-bump FP-BGA package.
Functional Description
The GS8321Z18/32/36AD-xxxV is a 36Mbit Synchronous
Static SRAM. GSI's NBT SRAMs, like ZBT, NtRAM, NoBL
or other pipelined read/double late write or flow through read/
single late write SRAMs, allow utilization of all available bus
bandwidth by eliminating the need to insert deselect cycles
when the device is switched from read to write cycles.
Parameter Synopsis
t
KQ
tCycle
Curr
(x18)
Curr
(x32/x36)
t
KQ
tCycle
Curr
(x18)
Curr
(x32/x36)
-333
3.0
3.0
365
425
5.0
5.0
270
315
-250
3.0
4.0
290
345
5.5
5.5
245
280
-200
3.0
5.0
250
290
6.5
6.5
210
250
-150
3.8
6.7
215
240
7.5
7.5
200
230
Unit
ns
ns
mA
mA
ns
ns
mA
mA
Pipeline
3-1-1-1
Flow
Through
2-1-1-1
Rev: 1.03 8/2013
1/31
© 2011, GSI Technology
Specifications cited are subject to change without notice. For latest documentation see http://www.gsitechnology.com.
